If you do not see exactly what you need, please e-mail your requirement to sales@pmi-rf.com so we can propose an instant solution.

Part NumberStatusFrequency MinFrequency MaxInsertion LossPhase Shift RangeSize
PIQ-2G18G-360-16-CD-1Active2 GHz18 GHz16.0 dB max, Measured 14.74 dB360°4.25" x 3.5" x 1.0"
PIQ-85M18G-36020-CD-2Active0.85 GHz18 GHz-3 ± 4 dB360°6.0" x 3.0" x 1.0"
PIQ-2G18G-360-16-CD-1-OPT510Preliminary5 GHz10 GHz16.0 dB max360°4.25" x 3.5" x 1.0"
PIQ-2G18G-360-16-CD-1-OPT815Preliminary8 GHz15 GHz16.0 dB max360°4.25" x 3.5" x 1.0"
PIQ-6G18G-360-20-APreliminary6 GHz18 GHz12.0 dB Typ360°4.25" x 3.50" x 1.00"
PIQ-2G18G-360-16-CD-1-OPT0206Preliminary2 GHz6 GHz13.0 dB max360°4.25" x 3.5" x 1.0"
PS-360-AC-910-7224-IQ-RHPreliminary9 GHz10 GHz12 dB max360°3.25" x 3.25" 0.85"
PIQ-6G18G-360-20-A-2Preliminary6 GHz18 GHz12.0 dB Typ360°4.25" x 3.50" x 1.00"
PIQ-18G40G-360D-10dBPreliminary18 GHz40 GHz16.0 dB max360°3.50" x 2.50" x 0.75"
PIQ-6G18G-360-16-APreliminary6 GHz18 GHz16.0 dB max360°4.25" x 3.50" x 1.00"
PIQ-0R5G2G-360-20-CD-1Active0.5 GHz2 GHz11.0 dB max - Measured 10.54 dB360°5.0" x 5.0" x 1.0"
PS-360-AC-810-7224-IQ-RHActive8.5 GHz10 GHz12 dB max360°3.25" X 3.25" X 0.85"
PIQ-5G15G-360-60Preliminary5 GHz15 GHz17.5 dB max360°3.25" x 3.0" x 1.0"
PIQ-18G40G-360D-10dB-OPT24GPreliminary24 GHz24 GHz16.0 dB max360°3.50" x 2.50" x 0.75"
PIQ-2G12G-12B-SFFPreliminary2 GHz12 GHz10.5 dB typ360°3.25" x 3.25 x 0.84"
PIQ-6G18G-360-20-A-7228Preliminary6 GHz18 GHz12.0 dB max360°3.00 " x 3.00" x 0.96"
PIQ-2G18G-360-16-CD-2Preliminary2 GHz18 GHz18.0 dB max360°4.25" x 3.5" x 1.0"
