| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Center Frequency: | 2.065 GHz |
|---|
| Insertion Loss: | 3 dB |
|---|
| Bandwidth: | 0.095 GHz |
|---|
| Rejection: | -65 dBc @ DC to 1.275 GHz
-65 dBc @ 3.78 to 10.6 GHz |
|---|
| Connectors: | PC Pins |
|---|
| Size: | 1.50" x 0.31" x 0.31" |
|---|
| VSWR in the Pass Band: | 1.5:1 |
|---|
| Insertion Loss (Pass Band): | 3 dB |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -40 °C to +85 °C |
|---|
| Non-Operating Temperature: | -40 °C to +100 °C |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
