General Parameters: |
Status: | Preliminary |
Frequency Min: | 2.5 GHz |
Frequency Max: | 5.0 GHz |
Phase States: | 0° / 180° |
Insertion Loss: | 2.5 dB Typ, 3.0 dB Max |
VSWR: | 2.0:1 |
Control Type: | TTL |
Speed: | 75 ns MAXIMUM ON/OFF |
Input Power: | +20 dBm OPERATING |
Input Power (Survival): | 0.5 WATT CW, 1uS PULSE WIDTH SURVIVAL |
Carrier Suppression: | 20 dB TYPICAL |
Power Supply: | +5 VDC @ 75 mA max, -5 VDC @ 20 mA max |
Size: | 1.0" X 1.0" X 0.5" |
Weight: | < 2 Ounces |
Environmental Ratings: |
Temperature (Operating): | -55ºC to +85ºC |
Temperature (Storage): | -65 ºC to +125 ºC |
Humidity: | MIL-STD-202F, Method 103B Cond. B |
Shock: | MIL-STD-202F, Method 213B Cond. B |
Vibration: | MIL-STD-202F, Method 204D Cond. B |
Altitude: | MIL-STD-202F, Method 105C Cond. B |
Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
