| General Parameters: |
|---|
| Status: | Active |
|---|
| Passband Frequency (GHz): | 0.8 to 10 |
|---|
| Cut-Off Frequency (GHz): | 0.78 |
|---|
| Passband Insertion Loss (dB): | 1 dB |
|---|
| Passband VSWR: | 2.0:1 - Measured 1.36:1 |
|---|
| Rejection: | -40 dBc @ 0.5 GHz - Measured -41.57 |
|---|
| Connectors: | SMA Male / Female |
|---|
| Size: | 1.5" x 0.31" x 0.31" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -40 ºC to +85 ºC |
|---|
| Temperature (Storage): | -40 ºC to +100 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
|---|
