Planar Monolithics (PMI) Isolators and Circulators are designed for a variety of RF/microwave applications in bandwidths up to 50 GHz, including form, fit, function as well as custom designs to offer complete design solutions.
If you do not see exactly what you need, please click here, and send us your requirement(s) or questions so we can propose an instant solution.
| Part Number | Status | Type | Frequency Min (GHz) | Frequency Max (GHz) | Insertion Loss (dB) |
|---|---|---|---|---|---|
| CIR-163M168M-19-100W-NFF Preliminary | Preliminary | Circulator | 0.163 | 0.168 | 0.5 Max |
| ISO-2D85G2D86G-500W-NMF Preliminary | Preliminary | Isolator | 2.85 | 2.86 | 0.3 dB Max |
| ISO-2G8G-14-SFF Preliminary | Preliminary | Isolator | 2 | 8 | 1.8 dB Max |
| ISO-2G6G-13-SFF Preliminary | Preliminary | Isolator | 2 | 6 | 0.8 dB Max (+20 to +70 ˚C), 1.5 dB Max @ 2 to 2.5 GHz (-40 to +20 ˚C), 0.8 dB Max @ 2.5 to 6 GHz (-40 to +20 ˚C) |
| ISO-4G8G-18-SFF Preliminary | Preliminary | Isolator | 4 | 8 | 0.5 dB Max |
| CIR-2D9G3D5G-18-NFF Preliminary | Preliminary | Circulator | 2.9 | 3.5 | 0.5 dB Max |
| 9612HPC333 Preliminary | Preliminary | Circulator | 0.96 | 1.22 | 0.3 dB Max |
| ISO-0D8G2G-12-SFF Preliminary | Preliminary | Isolator | 0.8 | 2 | 1.3 dB Max |
| 2640I885 Preliminary | Preliminary | Isolator | 26.5 | 40 | 1 dB Max |
| 28CJ1212 Active | Active | Circulator | 34 | 36 | 0.3 dB Max |
| CIR-13751425-23-DI Preliminary | Preliminary | Circulator | 13.75 | 14.25 | 0.3 dB Max |
| ISO-13751425-23-DI Preliminary | Preliminary | Isolator | 13.75 | 14.25 | 0.3 dB Max |
| ISO-1011-45-SFF Preliminary | Preliminary | Isolator | 10 | 11 | 0.6 dB Max |
| CIR-10G11G-23-30W-TAB Preliminary | Preliminary | Circulator | 10 | 11 | 0.3 dB Max |
| ISO-334-40-SFF Preliminary | Preliminary | Isolator | 3 | 3.4 | 0.7 dB Max |
| ISO-618-10-SFF Active | Active | Isolator | 6 | 18 | 1.5 dB Max |
| ISO-26-18-SFF Active | Active | Isolator | 2 | 6 | 0.8 dB Max (@ +20 to +70 °C), 1.5 dB Max (2 to 2.5 GHz @ -40 to +20 °C), 0.8 dB Max (2 to 6 GHz @ -40 to +20 °C) |
| ISO-26-18-SMF Active | Active | Isolator | 2 | 6 | 0.8 dB Max (@ +20 to +70 °C), 1.5 dB Max (2 to 2.5 GHz @ -40 to +20 °C), 0.8 dB Max (2.5 to 6 GHz @ -40 to +20 °C) |
| CIR-15G18R2G-20-SFF | Preliminary | Circulator | 15 | 18.2 | 0.4 dB Max |
| CIR-5D4G5D9G-60W-SFF | Preliminary | Circulator | 5.4 | 5.9 | 0.8 dB Max (Tx / Rx) |
| CIR-5G4R5G9R-36-PIN | Preliminary | Circulator | 5.4 | 5.9 | 1 dB Max |
| ISO-1G2G-17-SFF Preliminary | Preliminary | Isolator | 1 | 2 | 0.6 dB Max |
| ISO-140M160M-18-300W-NFF Preliminary | Preliminary | Isolator | 0.14 | 0.16 | 0.6 dB Max |
| CIR-1G1G1M-22-NFF Preliminary | Preliminary | Circulator | 1 | 1.1 | |
| ISO-45G50G-15-24FF Preliminary | Preliminary | Isolator | 45 | 50 | 1.3 dB Max, 0. dB Typ |
| ISO-1218-18-SMF Preliminary | Preliminary | Isolator | 12 | 18 | 0.6 dB Max |
| ISO-618-10-SMF Active | Active | Isolator | 6 | 18 | 1.5 dB Max |
| ISO-1826D5-16-SMF Preliminary | Preliminary | Isolator | 18 | 26.5 | 1.6 dB Max |
| ISO-36-18-SMF Preliminary | Preliminary | Isolator | 3 | 6 | 0.5 dB Max |
| ISO-1218-18-SFF Preliminary | Preliminary | Isolator | 12 | 18 | 0.6 dB Max |
| ISO-108M118M-20-NFF Active | Active | Isolator | 0.108 | 0.118 | 0.6 dB Max |
| CIR-2G4G-16-SFF Preliminary | Preliminary | Circulator | 2 | 4 | 0.6 dB Max |
| ISO-2G4G-18-SFF Preliminary | Preliminary | Isolator | 2 | 4 | 0.6 dB Max |
| ISO-17G22G-0R6-SFF Preliminary | Preliminary | Isolator | 17 | 22 |
