Part NumberStatusFrequency MinFrequency MaxGainGain FlatnessNoise FigureDC Voltage SupplyDC Current DrawOP1dB
LNA-11D95-18D05-20-15-SMFPreliminary11.95 GHz18.05 GHz26.5 dB to 30.5 dB±1.0 dB Max6.5 dB MAX (40°C)
7.0 dB MAX (-20 TO +70°C)
15 V± 0.5 V475 mA Max+20 dBm Min
LNA-26-3D5G6G-3R0-25Preliminary3.5 GHz6.0 GHz26±0.5 dB @ 25 °C, ±2.0 dB Over Temperature
-
3.0 dB Max. @ 25 °C, 5.0 dB Over Temperature+12 to +14 V550 mA max.+25 dBm Min.
LNA-30-6G10G-3R0-25Preliminary6.0 GHz10.0 GHz30±1.5 dB, ±2.0 Over Temperature
-
3.0 dB Max @ 25 °C, 5.0 dB Over Temperature+12 to +14 V550 mA max.+25 dBm Min.
PE2-60-12R018R0-4R0-14-12-SFFPreliminary12 GHz18 GHz60 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15325mA max.14dBm min.
GMPA-1003Preliminary2 GHz4 GHz30 dB min+/- 2.5 dB
-
+15 Vdc @900 mA max900 mA29dBm min
PE2-12-2G4D2G-5R0-17-12-SFFActive2 GHz4.2 GHz12 dB typ.±1.0 dB max.5.0 dB max.12 to +15 VDC230 mA Nominal17 dBm min.
PE2-15-0R40R8-5R0-21-12-SFFPreliminary0.4 GHz0.8 GHz15 dB typ.±0.5 dB max.5.0 dB typ.+12 to +15225mA max.21dBm min.
PE2-15-0R51R0-3R0-26-12-SFFPreliminary0.5 GHz1 GHz15 dB typ.±1.0 dB max.3.0 dB typ.+12 to +15300mA max.26dBm min.
PE2-15-0R51R0-5R0-21-12-SFFPreliminary0.5 GHz1 GHz15 dB typ.±0.5 dB max.5.0 dB typ.+12 to +15225mA max.21dBm min.
PE2-15-10R020R0-4R0-14-12-SFFPreliminary10 GHz20 GHz15 dB typ.1.25 dB max.4.0 dB typ.+12 to +1580mA max.14dBm
PE2-15-10R020R0-4R0-20-12-SFFPreliminary10 GHz20 GHz15 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15225mA max.20dBm min.
PE2-15-12G18G-4R0-18-12-SFFPreliminary12 GHz18 GHz14 dB typ±1.05 dB max.4.0 dB typ., 5.0 dB max+12 to +15VDC230mA nominal+18dBm min
PE2-15-12R018R0-3R5-14-12-SFFPreliminary12 GHz18 GHz15 dB typ.±1.25 dB max.3.5 dB typ.+12 to +1580mA max.14dBm min.
PE2-15-1R02R0-5R0-21-12-SFFPreliminary1 GHz2 GHz15 dB typ.±0.5 dB max.5.0 dB typ.+12 to +15225mA max.21dBm min.
PE2-15-2R04R0-3R8-21-12-SFFPreliminary2 GHz4 GHz15 dB typ.±0.75 dB max.3.8 dB typ.+12 to +15225mA max.21dBm min.
PE2-15-4R08R0-3R0-21-12-SFFPreliminary4 GHz8 GHz15 dB0.75 dB3 dB12 to +15 VDC225 mA19 dBm
PE2-16-0R10R2-3R5-14-12-SFFPreliminary0.1 GHz0.2 GHz16 dB typ.±0.5 dB max.3.5 dB typ.+12 to +15150mA max.14dBm min.
PE2-16-0R20R4-3R5-14-12-SFFPreliminary0.2 GHz0.4 GHz16 dB typ.±0.5 dB max.3.5 dB typ.+12 to +15150mA max.14dBm min.
PE2-16-0R40R8-3R0-14-12-SFFPreliminary0.4 GHz0.8 GHz16 dB typ.±0.5 dB max.3.0 dB typ.+12 to +15150mA max.14dBm min.
PE2-16-0R51R0-3R0-14-12-SFFPreliminary0.5 GHz1 GHz16 dB typ.±0.5 dB max.3.0 dB typ.+12 to +15150mA max.14dBm min.
PE2-16-4R08R0-1R75-12-12-SFFPreliminary4 GHz8 GHz16 dB1 dB1.75 dB12 to +15 VDC80 mA12 dBm
PE2-17-2R04R0-1R4-15-12-SFFPreliminary2 GHz4 GHz17 dB typ.±0.75 dB max.1.4 dB typ.+12 to +1580mA max.15dBm min.
PE2-18-1R02R0-1R4-17-12-SFFPreliminary1 GHz2 GHz18 dB typ.±0.75 dB max.1.4 dB typ.+12 to +1580mA max.17dBm min.
PE2-2023-11G18G-6R0-22-SFF-PGSPreliminary11 GHz18 GHz20 dB typ
-
4.5 dB typ, 6 dB max+12 to +15VDC @ 475mA nominal475 mA max.+22dBm min
PE2-22-0R40R8-1R2-18-12-SFFPreliminary0.4 GHz0.8 GHz22 dB typ.±0.4 dB max.1.2 dB typ.+12 to +15100mA typ.18dBm min.
PE2-22-0R51R0-1R25-18-12-SFFPreliminary0.5 GHz1 GHz22 dB typ.±0.4 dB max.1.25 dB typ.+12 to +15100mA max.18dBm min.
PE2-22-1R02R0-1R5-18-12-SFFPreliminary1 GHz2 GHz22 dB typ.±0.4 dB max.1.5 dB typ.+12 to +15100mA max.18dBm min.
PE2-22-2G4D2G-3R0-19-12-SFFActive2 GHz4.2 GHz21.5 dB typ.±1.0 dB max.3 dB12 to +15 VDC320 mA19 dBm
PE2-27-5D4G5D9G-1R3-20-12-SFFPreliminary5.4 GHz5.9 GHz27 dB min±1.5 dB max1.3 dB typ, 1.5 dB max (Note 1)+12 to +15VDC340mA nominal+20dBm min
PE2-27-5D4G5D9G-1R3-20-12-SMFPreliminary5.4 GHz5.9 GHz27 dB min±1.5 dB max1.3 dB typ, 1.5 dB max (Note 1)+12 to +15VDC340mA nominal+20dBm min
PE2-30-0R10R2-3R5-14-12-SFFPreliminary0.1 GHz0.2 GHz30 dB typ.±0.5 dB max.3.5 dB typ.+12 to +15300mA max.14dBm min.
PE2-30-0R10R2-4R0-21-12-SFFPreliminary0.1 GHz0.2 GHz30 dB typ.±0.5 dB max.4.0 dB typ.+12 to +15375mA max.21dBm min.
PE2-30-0R20R4-3R5-14-12-SFFPreliminary0.2 GHz0.4 GHz30 dB typ.±0.5 dB max.3.5 dB typ.+12 to +15300mA max.14dBm min.
PE2-30-0R20R4-4R0-21-12-SFFPreliminary0.2 GHz0.4 GHz30 dB typ.±0.5 dB max.4.0 dB typ.+12 to +15375mA max.21dBm min.
PE2-30-0R40R8-3R0-14-12-SFFPreliminary0.4 GHz0.8 GHz30 dB typ.±0.5 dB max.3.0 dB typ.+12 to +15300mA max.14dBm min.
PE2-30-0R40R8-4R0-21-12-SFFPreliminary0.4 GHz0.8 GHz30 dB typ.±0.5 dB max.4.0 dB typ.+12 to +15375mA max.21dBm min.
PE2-30-0R51R0-3R0-14-12-SFFPreliminary0.5 GHz1 GHz30 dB typ.±0.5 dB max.3.0 dB typ.+12 to +15300mA max.14dBm min.
PE2-30-0R51R0-3R5-26-12-SFFPreliminary0.5 GHz1 GHz30 dB typ.±1.0 dB max.3.5 dB typ.+12 to +15450mA max.26dBm min.
PE2-30-0R51R0-4R0-21-12-SFFPreliminary0.5 GHz1 GHz30 dB typ.±0.5 dB max.4.0 dB typ.+12 to +15375mA max.21dBm min.
PE2-30-10R020R0-4R0-14-12-SFFPreliminary10 GHz20 GHz30 dB typ.±1.25 dB max.4.0 dB typ.+12 to +15160mA max.14dBm min.
PE2-30-10R020R0-4R5-20-12-SFFPreliminary10 GHz20 GHz30 dB typ.±1.5 dB max.4.5 dB typ.+12 to +15300mA max.20dBm min.
PE2-30-12R018R0-3R5-14-12-SFFPreliminary12 GHz18 GHz30 dB typ.±1.25 dB max.3.5 dB typ.+12 to +15160mA max.14dBm min.
PE2-30-12R018R0-4R0-20-12-SFFPreliminary12 GHz18 GHz30 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15300mA max.20dBm min.
PE2-30-12R024R0-5R0-18-12-SFFPreliminary12 GHz24 GHz30 dB typ.±1.5 dB max.5.0 dB typ.+12 to +15500mA max.18dBm min.
PE2-30-2R04R0-1R5-21-12-SFFActive2 GHz4 GHz30 dB typ.±1.0 dB max.1.5 dB typ.+12 to +15VDC300mA Nominal+21dBm min.
PE2-30-2R04R0-1R5-21-8V-SFFActive2 GHz4 GHz30 dB typ.±1.0 dB max.1.5 dB typ.+8VDC300mA Nominal+21dBm min.
PE2-30-30G40G-3R0-12-292FFPreliminary30 GHz40 GHz30 dB min±2.0 dB typ.2,0 dB typ, 3.0 dB max+12 to +15VDC100mA max+1dBm min
PE2-30-4R08R0-1R75-12-12-SFFPreliminary4 GHz8 GHz30 dB1.25 dB Max.1.75 dB12 to +15 VDC160 mA12 dBm
PE2-30-8R012R0-2R5-15-12-SFFPreliminary8 GHz12 GHz30 dB typ.±0.75 dB max.2.5 dB typ.+12 to +15 VDC150mA max15dBm min.
PE2-35-2R04R0-1R4-15-12-SFFPreliminary2 GHz4 GHz35 dB min.1.0 dB max.1.4 dB typ.+12 to +15160mA max.15dBm min.
PE2-40-8R012R0-2R5-15-12-SFFPreliminary8 GHz12 GHz40 dB typ.±0.75 dB max.2.5 dB typ.+12 to +15150mA max.15dBm min.
PE2-42-12R024R0-5R0-18-12-SFFPreliminary12 GHz24 GHz42 dB typ.±1.75 dB max.5.0 dB typ.+12 to +15700mA max.18dBm min.
PE2-45-10R020R0-4R0-14-12-SFFPreliminary10 GHz20 GHz45 dB typ.±1.5 dB max.4.25 dB typ.+12 to +15250mA max.14dBm min.
PE2-45-10R020R0-4R5-20-12-SFFPreliminary10 GHz20 GHz45 dB typ.±1.5 dB max.4.5 dB typ.+12 to +15385mA max.20dBm min.
PE2-45-12R018R0-4R0-14-12-SFFPreliminary12 GHz18 GHz45 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15250mA max.14dBm min.
PE2-45-12R018R0-4R0-20-12-SFFPreliminary12 GHz18 GHz45 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15385mA max.20dBm min.
PE2-45-2R04R0-1R5-21-12-SFFPreliminary2 GHz4 GHz45 dB typ.±1.25 dB max.1.5 dB typ.+12 to +15385mA max.21dBm min.
PE2-45-4R08R0-1R5-21-12-SFFPreliminary4 GHz8 GHz45 dB1.25 dB Max.1.5 dB12 to +15 VDC385 mA21 dBm min.
PE2-45-4R08R0-1R75-14-12-SFFPreliminary4 GHz8 GHz45 dB1.25 dB Max.1.75 dB12 to +15 VDC240 mA Max.12 dBm
PE2-45-8R012R0-3R0-21-12-SFFPreliminary8 GHz12 GHz45 dB typ.±1.0 dB max.3.0 dB typ.+12 to +15385mA max.21dBm min.
PE2-50-2R04R0-1R4-15-12-SFFPreliminary2 GHz4 GHz50 dB Typ.1.25 dB Max.1.4 dB Typ.12 to +15 VDC240 mA Max.15 dBm Min.
PE2-50-8R012R0-2R5-10-12-SFFPreliminary8 GHz12 GHz50 dB typ.±0.75 dB max.2.5 dB typ.+12 to +15150mA max.10dBm min.
PE2-50-8R012R0-3R5-21-12-SFFPreliminary8 GHz12 GHz50 dB typ.±1.0 dB max.3.5 dB typ.+12 to +15385mA max.21dBm min.
PE2-60-10R020R0-4R0-14-12-SFFPreliminary10 GHz20 GHz60 dB typ.±1.5 dB max.4.25 dB typ.+12 to +15325 mA max.12 dBm min.
PE2-60-10R020R0-4R5-20-12-SFFPreliminary10 GHz20 GHz60 dB typ.±1.5 dB max.4.5 dB typ.+12 to +15475mA max.20dBm min.
PE2-60-12R018R0-4R0-20-12-SFFPreliminary12 GHz18 GHz60 dB typ.±1.5 dB max.4.0 dB typ.+12 to +15475mA max.20dBm min.
PE2-60-2R04R0-1R5-21-12-SFFPreliminary2 GHz4 GHz60 dB typ.±1.25 dB max.1.5 dB typ.+12 to +15475 mA max.21 dBm min.
PE2-60-8R012R0-2R5-15-12-SFFPreliminary8 GHz12 GHz60 dB typ.±1.0 dB max.2.5 dB typ.+12 to +15320mA max.15dBm min.
PE2-60-8R012R0-3R5-21-12-SFFPreliminary8 GHz12 GHz60 dB typ.±1.25 dB max.3.5 dB typ.+12 to +15475mA max.21dBm min.
PEC-35-26R5G40G-24-15-292FFPreliminary26.5 GHz40 GHz35 dB Typ.±3.5 dB typ.
-
+15 VDC Max.5000 mA Max.+24 dBm Typ. Without Isolators
GMA26240-10-22Preliminary26.5 GHz40 GHz22 dB min±2.0 dB max5.0 dB max @ +25C+15V240 mA max+10 dBm min. P-1
GSA224-25-31Preliminary2 GHz4 GHz31 dB typ±1.5 dB max3.0 dB max @ +25C15V420mA+25 dBm min. P-1
PE2-12-30R040R0-5R5-18-12-292FFActive30 GHz40 GHz12 dB Typ.±2.0 dB Max.5.5 dB Typ.+12 to +15300 mA max. - Measured 237 mA18 dBm Min. - Measured 18.1 dB
PE2-14-12G22G-3R0-12-SMFActive12 GHz22 GHz14.5 dB typ.±1.0 dB typ3.0 dB typ., 4.0 dB max - Measured 3.99 dB @ 22.0 GHz+12 to +15VDC100 mA nom - Measured 84 mA10 dBm min. - Measured =10 dBm
PE2-15-0R10R2-6R0-21-12-SFFPreliminary0.1 GHz0.2 GHz15 dB typ.±0.5 dB max.6.0 dB typ.+12 to +15225mA max.21dBm min.
PE2-15-0R20R4-6R0-21-12-SFFPreliminary0.2 GHz0.4 GHz15 dB typ.±0.5 dB max.6.0 dB typ.+12 to +15225mA max.21dBm min.
PE2-25-218-20-12-SFF-OPT6G8GActive2 GHz18 GHz25 dB Min±1.5 dB Max4.5 dB Typ, 5.5 dB Max - Measured 3.2 dB+12 to +15 VDC350 mA Max - Measured 285 mA23 dBm Min - Measured >+23 dBm
PE2-25-7G10G-5R0-20-SFFActive7 GHz10 GHz22 dB min., 25 dB typ±0.5 dB max.5.0 dB max. - Measured 3.35 dB+12 to +15350 mA max. - Measured 236 mA20 dBm min. - Measured >20 dBm
PE2-26-30G40G-7R0-16-292FFPreliminary30 GHz40 GHz26 dB nominal±2.0 dB max7.0 dB typ (By Design)+12 to +15 VDC250 mA nominal+16dBm typ
PE2-30-8R012R0-1R0-2-12-SFFPreliminary8 GHz12 GHz30 dB typ.±2.0 dB max.1.0 dB typ.+12 to +1525mA max.2dBm min.
PE2-30-8R012R0-3R0-21-12-SFFActive8 GHz12 GHz30 dB Typ.±0.75 dB Max.3.0 dB Typ. - Measered 2.6 dB+12 to +15 VDC300 mA Max. - Measured 295 mA21 dBm Min. - Measured +23.8 dBm
PE2-31-2R04R0-3R0-25-15-SFFPreliminary2 GHz4 GHz31 dB typ±1.5 dB max3.0 dB max @ +25C15V420mA max+25 dBm min. P-1
PE2-45-8G12G-2R0-20-12-SFFActive8 GHz12 GHz45 dB nominal±1.5 dB max2.0 dB typ, 2.25 dB max - Measured 2.2 dB+12 to +15 VDC @ 375 mA nom, Measured 321 mA375 mA+20 dBm min - Measured +22.3 dBm
PE2-45-8R012R0-1R0-14-12-SFFActive8 GHz12 GHz45 dB typ.±2.0 dB max.1.0 dB typ. - Measured 1.9 dB+12 to +15200 mA nominal - Measured 384 mA12 dBm min. - Measured +14 dBm
PE2-60-2R04R0-1R5-15-12-SFFPreliminary2 GHz4 GHz60 dB typ.1.25 dB max.1.5 dB typ.+12 to +15325mA max.15dBm min.
PEC-30-2R04R0-1R5-21-8V-SFF-HSActive2 GHz4 GHz30 dB Min±1.0 dB Max.1.5 dB Typ. - Measured 1.56 dB+7.8 to +8.2 VDC @ 380 mA Max - Measured 235 mA @ +8 VDC380 mA+21 dB Min. - Measured +22.7 dBm
PEC-30-30G36G-20-12-292FFPreliminary30 GHz36 GHz30 dB typ.±2.5 dB typ.5.5 dB typ.+12 to +15 VDC300 mA nominal+19 dBm typ. (30.0 to 36.0 GHz)
PE2-12-20R040R0-5R5-18-12-SFFActive20 GHz40 GHz12 dB Typ.±2.0 dB Max.@20 GHz -5.0 dB Max. - Measured 4.5 dB @26.5 GHz – 6.5dB Max - Measured 6.0 dB @33.5 GHz – 8.5dB Max - Measured 8.1 dB @40 GHz – 10.0dB Max - Measured 9.67 dB+12 to +15 VDC250 mA Max. - Measured 237 mA@20 GHz - 20dBm Min. - Measured 21 dBm @40 GHz - 16dBm Min. - Measured 16.5 dBm
PE2-14-12R024R0-5R0-18-12-SFFPreliminary12 GHz24 GHz14 dB typ.±1.5 dB max.5.0 dB typ.+12 to +15250mA max.18dBm min.
PE2-15-8R012R0-3R0-21-12-SFFActive8 GHz12 GHz15 dB typ.±0.75 dB max.3.0 dB typ.+12 to +15 VDC228 mA max.19 dBm min.
PE2-28-20R040R0-5R5-18-12-SFFActive20 GHz40 GHz28 dB typ.±2.5 dB max.5.5 dB typ. - Measured 3.42 dB+12 to +15 VDC350 mA nominal - Measured 237 mA+18 dBm typ., +15 dBm min., Measured 15.2 dBm
PE2-30-1R02R0-1R5-21-12-SFFActive1 GHz2 GHz30 dB typ.±0.5 dB max.1.5 dB typ.+12 to +15300 mA max. - Measured 292 mA21 dBm min. - Measured >+21 dBm
PE2-30-20G20R6G-3R0-10-12-SFFActive20 GHz26.5 GHz30 dB typ.±1.5 dB max.3.0 dB max. - Measured 2.90 dB max.+12 to +15VDC150 mA max. - Measured 66 mA+10 dBm min. - Measured >+10 dBm
PE2-30-4G8G-2R0-10-12-SFFActive4 GHz8 GHz27 dB1 dB2 dB12 to +15 VDC200 mA10 dBm
PE2-60-4R08R0-1R5-21-12-SFFActive4 GHz8 GHz60 dB Typ.±1.25 dB Max.1.5 dB Typ.+12 to +15 VDC475 mA Max.21 dBm Min. - Measured >=21 dBm
PEC2-60-4G8G-1R75-14-12-SFFActive4 GHz8 GHz60 dB typ.±1.25 dB max.1.75 dB max.+12 to +15VDC350mA nominal14dBm min.
PE2-15-8R012R0-2R5-15-12-SFFActive8 GHz12 GHz15 dB typ.±0.75 dB max.2.5 dB typ.+12 to +1580mA max. - Measured 75 mA15 dBm min. - Measured +13 dBm
PE2-25-8G12G-2R5-15-12-SFFActive8 GHz12 GHz25 dB typ.±1.0 dB max.2.50 dB typ. - - Measured 2.36 dB+12 to +15VDC200mA max. - Measured 164mA+15dBm min. - Measured >15dBm
PE2-30-4R08R0-1R5-21-12-SFFActive4 GHz8 GHz30 dB1 dB1.5 dB12 to +15 VDC300 mA max. - Measured 338 mA21 dBm min. - Measured +21 dBm
PE2-35-1R02R0-1R4-17-12-SFFActive1 GHz2 GHz30 dB Typ±0.5 dB Max1.5 dB Typ+12 to +15 VDC300 mA Max21dBm Min
PE2-36-26D540G-5R0-10-12-292FFActive26.5 GHz40 GHz36 dB typ.±3.0 dB max.5.0 dB max.+12 to +15VDC250 mA max. - Measured 175 mA10 dBm min. - Measured =10 dBm
PEC-22-24G40G-4R0-24-292FFActive24 GHz40 GHz22 dB Min±1.5 dB Typ6.0 dB Max - Measured 0 dB+8 VDC500 mA Max - Measured 260 mA24 dBm Min - Measured +21 dB @ 24.0 GHz +22 dB @ 32.0 GHz +20 dB @ 40.0 GHz
PEC-30-24G40G-4R0-24-292FFActive24 GHz40 GHz30 dB Typ±1.5 dB Typ6.0 dB Max - Measured 0 dB+8 VDC650 mA nominal - Measured 400 mA24 dBm Min - Measured +17 dB @ 24.0 GHz +21 dB @ 32.0 GHz +18 dB @ 40.0 GHz
