Narrow Band LNA's

If you do not see exactly what you need, please e-mail your requirement to sales@pmi-rf.com so we can propose an instant solution.

Part NumberStatusFrequency MinFrequency MaxGainGain FlatnessNoise FigureOP1dBDC VoltageDC Current Draw
PE2-32-7G9G-4R0-21-SFFActive7.0 to 9.0GHz9.0GHz+32dB Nom+/-1.25dB Typ4dB Max+21dBm Min+12 to +15VDC300mA Typ.
PEC-27-20M500M-4-25-15-SFFPrreliminary20 MHz500 MHz25 dB MIN/ 30 dB MAX±1.0 dB TYP4.5 dB TYP+25 dBm TYP+15 VDC500 mA
PE2-30-13R5-15-SFFActive13.5 GHz13.5 GHz30 dB min.
-
-
+10 dBm min.+12 to +15 VDC2000 mA max.
PE2-25-0R640R72-5R5-5-15-SFF-TCActive0.64 GHz0.72 GHz25 dB typ.±0.4 dB max.5.5 dB max.+5 dBm min.+12 to +15 VDC150 mA max.
PE2-30-2R53R5-2R0-23-12-SFFActive2.5 GHz3.5 GHz+30 dB typ.±1.0 dB typ.2.0 dB max.2.0 dB max.+12 to +15 VDC350 mA max.
PE2-18-60M-2R5-10-12-PPActive0.055 GHz0.065 GHz18 dB typ.±0.5 dB max.2.5 dB max.+10 dBm min.+12 VDC80 mA
PE2-20-1M20M-5R0-22-12-SFFActive0.001 GHz0.02 GHz+20 dB typ.
-
5 dB max.+24 dBm typ.+12 to +15 VDC125 mA max.
PE2-60-1R51R8-0R4-13-15-SFFActive1.5 GHz1.8 GHz60 dB min.±1.0 dB max.0.4 dB max.+13 dBm+15 VDC250 mA nominal
PEC-20-30M1G-EQ-NFFActive0.02 GHz1.0 GHz20 dB typ., Equalized to Match Supplied GraphGain Equalized per Supplied Graph5.0 dB max.
-
+15 V450 mA max.
PE2-16-5G-2R0-12-SFFActive4.94 GHz4.99 GHz16dB Typ.+/- 0.5dB Max.2.0dB Max.+15dBm Min.+12 to +15VDC80mA Max.
PEC-12-1G-15-NMFActive0.8 GHz1.215 GHz12 dB min., 18 dB max.±1.0 dB max.4.0 dB max.+15 dBm min.+15 VDC100 mA max.
PM2-40-1013-23-15-SFFActive10 GHz13 GHz47dB Typ.+/- 1.5dB Max7.0dB Max.+23dBm Min.+12 to +15VDC350mA Max.
PE2-15-450M-5R0-14-12-SFFActive0.41 GHz0.91 GHz+25 dB typ.±0.5 dB max.5 dB max.+14 dBm min.+12 to +15 VDC200 mA max.
PE2-20-1R01R5-2R0-20-12-SFFActive1.0 GHz1.5 GHz+20 dB typ.±1.0 dB max.2 dB max.+13 dBm min.+12 VDC120 mA max.
PM2-20-1516-20-15-SFFActive15 GHz16 GHz18dB Typ.+/- 1.0dB Max.5.0dB Max.+18dBm Min.+12 to +15VDC+400mA Max.
PE2-47-1826-8-15-SFFActive18.0 GHz26.5 GHz47dB Typ.+/- 3.5dB Max.3.5dB Max.+10dBm Min.+12 to +15VDC200mA Max.
PM2-17-0R12-21-12-SFFPreliminary0.1 GHz2.0 GHz19 dB Typ.+/- 1.0 dB Max7.0 dB Max+0 dBm Min+12 to +15 VDC225 mA Max
PE2-30-0R740R82-5R0-15-15-SFFActive0.74 GHz0.82 GHz30dB Min.+/- 1.0 dB Max.5.0dB Max.+15dBm Min.+12 to +15VDC250mA Max.
PE2-40-811-3R5-15-SFFActive8 GHz11 GHz44dB Typ.+/- 1.0dB Max.3.5dB Max.+15dBm Min.+12 to +15VDC300mA Max.
PE2-18-811-3R5-15-SFFActive8 GHz11 GHz18dB Typ.+/- 1.0dB Max3.0dB Max.17dBm Min.+12 to +15VDC350mA Max.
PE2-24-811-3R5-16-12-SFFActive8 GHz11 GHz26dB Typ.+/- 1.0dB Max.3.5dB Max.+16dBm Min.12 to +15VDC150mA Max.
PE2-33-17D5G22G-2R5-10-12-SFFActive17.5 GHz22.0 GHz33 dB Min.+/- 1.5 dB Max.2.0 dB Typ., 2.5 dB Max.+10 dBm Min.+12 to +15VDC180 mA Max.
PE2-34-36G40G-3R5-8-12-292FFActive36 GHz40 GHz34 dB Min.+/- 1.5 dB Max.3.0 dB Typ., 3.5 dB Max.+8 dBm Min.+12 to +15VDC200 mA Max
PE2-28-12G18G-3R5-13-12-SFFActive12 GHz18 GHz28 dB Min.+/- 1.5 dB Max.3.5 dB Max.+13 dBm Min.+12 to +15VDC200 mA Max.
PE2-30-10D5G10D7G-1R1-10-12-SFFActive10.5 GHz10.7 GHz30 dB Min.+/- 0. 75 dB Max1.1 dB Max.+10 dBm Min.+12 to +15VDC150 mA Max.
PE2-30-18G26G-6R5-14-12-SFFActive18 GHz26 GHz30 dB Typ.+/- 1.5 dB Max.5.0 dB Typ. @ 18 GHz, 6.5 dB Typ. @ 26 GHz+14 dBm Min.+12 to +15VDC400 mA Max.
PM2-12-1315-20-15-SFFActive13 GHz15 GHz12dB Typ.+/- 1.0dB Max.6.0dB Max.+19dBm Min.+12 to +15VDC250mA Max.
PE2-20-9R09R1-5R0-16-15-SFFActive9 GHz9.1 GHz22dB Typ.+/- 0.5dB Max.5.0dB Max.+16dBm Min.+12 to +15VDC200mA Max.
PE2-12-30G40G-5R5-18-15-292FFActive30 GHz40 GHz12 dB Typ.+/-2.0 dB Max.5.5 dB Typ.+18 dBm Min.15 VDC300 mA
PE2-20-1318-5R0-10-12-SFFActive13 GHz18 GHz25dB Typ.+/- 1.0dB Max.5.0dB Max.+10dBm Min.+12 to +15VDC200mA Max.
PE2-27-9R69R8-5R0-10-15-SFFActive9.6 GHz9.8 GHz32dB Typ.+/- 0. 75dB Max.5.0dB Max.+10dBm Min.+12 to +15VDC225mA Max.
PE2-30-13R5-15DBM-15-SFFActive13.5 GHz13.5 GHz30 dB Min.+/- 1.0 dB Max5.0 dB Max+15dBm Min.+12 to +15VDC2000mA Max.
PM2-21-0R640R72-6R0-23-15-SFF-TCActive0.64 GHz0.72 GHz21 dB Min, 25dB Typ.+/- 0.5 dB Max5.0dB Typ, 6.0 dB Max.+23dBm Min.+12 to +15VDC300mA Max.
PE2-20-24G30G-20-12-292SFFActive24 GHz30 GHz20dB Min.+/- 1.5dB Typ.10dB Typ.+18dBm Min.+12 to +15VDC450mA Max.
PE2-20-5R25R4-15-SFFActive5.25 GHz5.35 GHz21dB Typ.+/- 1.0dB Max.4.0dB Max.+13dBm Min.+12 to +15VDC300mA Max.
PE2-14-5G-20-12-SFF-VVGActive4.94 GHz4.99 GHz14.5dB Typ.+/- 0.5dB Max.6.5dB Max.+20dBm Min.+12 to +15VDC400mA Max.
PE2-10-9R09R1-5R0-5-15-SFFActive9.0 GHz9.1 GHz11dB Typ.+/- 0.5dB Max.5.0dB Max.+5dBm Min.12 to +15VDC100mA Max.
PE2-10-8R7G-5R0-16-12-SFFActive8.66 GHz8.86 GHz15dB Typ.+/- 0.5dB Max.3.5dB Max.+16dBm Min.+12VDC to +15VDC210mA Max.
PE2-9R79R9-5R0-15-12-SFFActive9.7 GHz9.9 GHz20dB Typ.+/- 0.5dB Max.5.0dB Max.+15 dBm Min.+12 to +15VDC200mA Max.
PEC-25-1R575-20MHZBW-0-15-SFFActive1.57 GHz1.58 GHz20 to 30 dB+/- 0.5 dB Max.2.0 dB Max0 dBm Min.+15 VDC Max.180 mA
PE2-10-99R2-10-15-SFFActive9.0 GHz9.2 GHz10 dB typ.±0.75 dB max.5.0 dB max.+10 dBm min.+12 to +15 VDC100 mA max.
PE2-22-811-3R5-16-12-SFFActive8 GHz11 GHz23dB Typ.+/- 1.0dB Max.3.5dB Max.+16dBm Min.+12 to +15 VDC150 mA
PEC-47-4R15R3-0R7-13-12-SFFActive4.1 GHz5.3 GHz47 dB Min.+/- 0.5 dB Max.0.7 dB Max.+13 dBm min.+12 to +15 VDC150 mA typ.
PE2-32-56-2-28-SFFActive5.0 GHz6.0 GHz+32 dB typ.±1.25 dB max.1.0 dB typ.+2 dBm min.+28 VDC40 mA max.
PE2-15-1G2G-10LM-15-SFFActive1.0 GHz2.0 GHz+15 dB typ.
-
5.5 dB max.
-
+15 VDC175 mA nominal
LNA-16F-24DB-107NF Option SSPreliminary16.0 GHz16.5 GHz23 to 25 dB, Over Frequency and Temperature.±0.5 dB Maximum1.6 dB Maximum @ Room Temperature (+25°) 1.8 dB Maximum @ +30° 1.9 dB Maximum @ +75° 2.0 dB Maximum @ +85°+10 dBm Minimum+12 VDC150 mA max.
PA-38 OPTION 208Active2.7 GHz2.9 GHz35 dB @ 25 °C±1.5 dB Max1.5 dB Max-9 dBm Min+12 VDC100 mA
PE2-28-1G2G-1R8-22-15-SFFActive1.0 GHz2.0 GHz20 dB min., 30 dB max.±1.5 dB max.1.8 dB max.22 dBm min.+12 VDC300 mA
LNA-3D4G4D2G-22D0-0D5-15-SFFActive3.4 GHz4.2 GHz22 dB min.±0.5 dB max.0.5 dB max.
-
+15 V200 mA max.
PEC-27-20M1G-3R0-25-15-SFFPreliminary0.02 GHz1.0 GHz27 dB±1.0 dB max.3.0 dB max.+25 dBm min.+12 to +15 VDC
-
PE2-15-1R42R5-3R0-10-12-SFFActive1.4 GHz2.5 GHz18 dB typ.±1.0 dB max.3.0 dB max.+10 dBm min.+12 to +15 VDC200 mA
PE2-3033-3R58R5-1R8-10-8-SFF-PGSActive4 GHz8 GHz45 dB typ.±0.75 dB max.4.5 dB max.+15 dBm min.+12 to +15 VDC200 mA
APT3-03100350-0807-D5SActive3.1 GHz3.5 GHz28 ± 0.6 dB±0.2 dB (Over any 40 MHz Segment)0.8 dB max.+7.6 dBm min.+15 VDC150 mA nominal
PE2-15-0R81R5-3R0-10-12-SFFActive0.8 GHz1.5 GHz18 dB typ.±1.0 dB max.3.0 dB max.+10 dBm min.+12 to +15 VDC200 mA max.
PE2-27-56-1R8-10-15-SFFActive5.0 GHz6.0 GHz27 dB typ.±1.25 dB max.1.8 dB max.+10 dBm min.+12 to +15 VDC150 mA max.
PE2-22-5G6G-23-12-SFFActive5.0 GHz6.0 GHz22 dB typ.±1.25 dB max.4.5 dB max.+23 dBm min.+12 to +15 VDC450 mA max.
PE2-25-8G10G-2R0-15-12-SFFActive8.5 GHz9.6 GHz25 ± 1 dB±1 dB max.2.0 dB max.+8 dBm ± 1 dBm+12 VDC ± 5%120 mA typ.
PM2-20-0R852R1-20-12-SFFActive0.85 GHz2.1 GHz21 dB Typ.+/-0.5 dB Max.7.5 dB Max.+20 dBm Min.+12 to +15 VDC350 mA Max.
PE2-28-1718-7R0-23-12-SFFActive17.0 GHz18.0 GHz30 dB typ.±1.0 dB max.7.0 dB max.+23 dBm min.+12 to +15 VDC550 mA max.
PM2-20-0R251R0-20-12-SFFActive0.25 GHz1.0 GHz21 dB Typ.+/- 0.5 dB Max.7.5 dB Max.+20 dBm Min.+12 to +15 VDC350 mA Max.
PE2-23-1R01R5-16-15-SFFActive1.0 GHz1.55 GHz23 dB typ.±1.0 dB max.3.0 dB max.+16 dBm min.+12 to +15 VDC150 mA max.
PE2-24-7R98R4-3R0-5-15-SFFActive7.9 GHz8.4 GHz24 dB typ.±1.0 dB max.3.0 dB max.+5 dBm min.+12 to +15 VDC200 mA max.
PE2-17-9R5G-2R0-8-12-SFFActive9.4 GHz9.55 GHz17 dB typ.±0.5 dB max.2.0 dB max.+8 dBm min.+12 to +15 VDC80 mA max.
PE2-30-4G5G-1R6-10-12-SFFActive4.0 GHz5.0 GHz35 dB typ.±1.0 dB max.1.6 dB max.+10 dBm min.+12 to +15 VDC200 mA max.
PE2-40-24G-3R0-10-12-SFFActive23.5 GHz24.5 GHz46 dB typ.±1.0 dB max.3.0 dB max.+10 dBm min.+12 to +15 VDC200 mA max.
PE2-14-21R522R3-3R5-10-12-SFFActive21.5 GHz22.3 GHz15 dB typ.±0.75 dB max.3.5 dB max.+10 dBm min.+12 to +15 VDC80 mA max.
PE2-16-19R520R5-3R5-13-15-SFFActive19.5 GHz20.5 GHz14 dB typ.±1.0 dB max.3.5 dB max.+10 dBm min.+15 VDC80 mA max.
PE2-30-2E22R3-2R0-10-15-SFFActive2.2 GHz2.3 GHz30 dB min.±0.5 dB max.1.0 dB goal, 2.0 dB max.+10 dBm min.+12 to +15 VDC100 mA goal, 120 mA max.
PE2-25-11D98G-12D08G-2R5-15-12-SFFPreliminary11.98 GHz12.08 GHz25 dB min.±1.0 dB max.2.0 dB typ., 3.0 dB max.+15 dBm min.+12 to +15 VDC200 mA max.
LNA-12-0R5G2G-6-7-12-SFFPreliminary0.5 GHz2.0 GHz12 ± 3 dB
-
6 dB max.+7 dBm min.+12 to +15 VDC400 mA max.
LNA-26-2G3D5G-3R0-25Preliminary2.0 GHz3.5 GHz26±0.5 dB @ 25 °C, ±2.0 dB Over Temperature
-
3.0 dB Max. @ 25 °C, 5.0 dB Over Temperature+25 dBm Min.+12 to +14 V550 mA max.
PEC-28-9G10G-3R0-29-SFFPreliminary9.0 GHz10.0 GHz22 dB Min. @ 25 °C Base Plate Temperature±0.35 dB Typ., ±0.5 dB Max.7.0 dB Max.+29 dBm Min.+10 V/+12 V/+15 V200 mA min./400 mA typ./700 mA max.
PE2-24-8D5G9D5G-4R8-18-SFFPreliminary8.5 GHz9.5 GHz20 dB typ., 16 dB min.±0.75 dB max.4.2 dB typ., 4.8 dB max.+18 dBm min.+12 V min., +18 V max.250 mA typ., 300 mA max.
PE2-30-10G11G-2R75-21-12-SFFPreliminary10 GHz11 GHz30dB typ.±0.5dB max.2.75dB typ.21dBm min.+12 to +15300mA max.
PE2-60-6R07R0-2R0-21-12-SFFPreliminary6 GHz7 GHz60 dB typ.±0.75 dB max.2.0dB typ.21dBm min.+12 to +15425mA max.
LNA-1D2G1D6G-14-10-12-SFFPreliminary1.2 GHz1.6 GHz14 dB Min±1.5 dB Max0.7 dB Max+10 dBm Min+15 V100 mA Max(Bias)
LNA-30-2D7G3G-6R0-44-12-SFFPreliminary2.7 GHz3 GHz30 dB Min1.0 dB PK-PK Max4 dB Goal, 6 dB Typ+43 dBm Min, +44 dBm Typ+12 VDC12 Amps Min, 15 Amps Max
LNA-40-10M300M-1D0-17-5-SFFPreliminary0.01 GHz0.3 GHz40 dB
-
1 to 2.0 dB max. @ 10 MHz to 300 MHz+17 dBm+5 V (+5.5 V max.)170 mA @ Quiescent (No RF), 240 mA @ OP1dB = +25 dBm
PE2-10-7R08R0-3R5-14-12-SFFPreliminary7 GHz8 GHz10dB typ.±0.5dB max.3.5dB typ.14dBm min.+12 to +1565mA max.
PE2-10-8R09R0-3R5-14-12-SFFPreliminary8 GHz9 GHz10dB typ.±0.5dB max.3.5dB typ.14dBm min.+12 to +1565mA max.
PE2-15-0R50R8-4R25-15-12-SFFPreliminary0.5 GHz0.8 GHz15 dB Typ±0.5 dB Max4.25 dB Typ15 dBm Min+12 to +15 VDC65 mA Max
PE2-15-0R50R8-5R5-22-12-SFFPreliminary0.5 GHz0.8 GHz15 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC225 mA Max
PE2-15-10G11G-3R5-21-12-SFFPreliminary10 GHz11 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-11G12G-3R0-14-12-SFFPreliminary11 GHz12 GHz15dB typ.±0.5dB max.3.0dB typ.14dBm min.+12 to +1580mA max.
PE2-15-11G12G-3R5-21-12-SFFPreliminary11 GHz12 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max
PE2-15-12G13G-3R0-14-12-SFFPreliminary12 GHz13 GHz15dB typ.±0.5dB max.3.0dB typ.14dBm min.+12 to +1580mA max.
PE2-15-12G13G-3R5-21-12-SFFPreliminary12 GHz13 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max
PE2-15-14G15G-3R5-14-12-SFFPreliminary14 GHz15 GHz15dB typ.±0.5dB max.3.5dB typ.14dBm min.+12 to +1580mA max.
PE2-15-15G16G-3R5-14-12-SFFPreliminary15 GHz16 GHz15dB typ.±0.5dB max.3.5dB typ.14dBm min.+12 to +1580mA max.
PE2-15-15G16G-3R5-21-12-SFFPreliminary15 GHz16 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-16G17G-3R5-14-12-SFFPreliminary16 GHz17 GHz15dB typ.±0.5dB max.3.5dB typ.14dBm min.+12 to +1580mA max
PE2-15-16G17G-3R75-20-12-SFFPreliminary16 GHz17 GHz15dB typ.±0.5dB max.3.75 dB typ.20 dBm min.+12 to +15 VDC225mA max.
PE2-15-18G19G-3R0-10-12-SFFPreliminary18 GHz19 GHz15dB typ.±0.5dB max.3.0dB typ.10dBm min.+12 to +1550mA max.
PE2-15-19G20G-2R5-10-12-SFFPreliminary19 GHz20 GHz15dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1550mA max.
PE2-15-1R01R5-4R25-15-12-SFFPreliminary1 GHz1.5 GHz15 dB Typ±0.5 dB Max4.25 dB Typ15 dBm Min+12 to +15 VDC65 mA Max
PE2-15-1R01R5-5R5-22-12-SFFPreliminary1 GHz1.5 GHz15 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC225 mA Max
PE2-15-1R52R0-4R0-15-12-SFFPreliminary1.5 GHz2 GHz15dB typ.±0.5dB max.4.0dB typ.15dBm min.+12 to +1565mA max.
PE2-15-20G21G-2R5-10-12-SFFPreliminary20 GHz21 GHz15dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1550mA max.
PE2-15-21G22G-2R5-10-12-SFFPreliminary21 GHz22 GHz15dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1550mA max.
PE2-15-22G23G-2R5-10-12-SFFPreliminary22 GHz23 GHz15dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1550mA max.
PE2-15-23G24G-2R5-10-12-SFFPreliminary23 GHz24 GHz15 dB Typ.±0.5 dB Max.2.5dB typ.10dBm min.+12 to +15 VDC50mA max.
PE2-15-24G25G-2R5-10-12-SFFPreliminary24 GHz25 GHz15 dB typ.±0.5dB max2.5 dB typ.8 dBm min.+12 to +15 VDC70 mA max.
PE2-15-25G26G-2R5-10-12-SFFPreliminary25 GHz26 GHz15dB typ.±0.5 dB Max.2.5dB typ.10dBm min.+12 to +1550mA max.
PE2-15-2R03R0-4R0-21-12-SFFPreliminary2 GHz3 GHz15dB typ.±0.5dB max.4.0dB typ21dBm min.+12 to +15225mA max.
PE2-15-3R04R0-4R0-21-12-SFFPreliminary3 GHz4 GHz15dB typ.±0.5dB max.4.0dB typ.21dBm min.+12 to +15225mA max.
PE2-15-4R05R0-3R5-21-12-SFFPreliminary4 GHz5 GHz15dB typ±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-5R06R0-3R5-21-12-SFFPreliminary5 GHz6 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-6R07R0-3R0-21-12-SFFPreliminary6 GHz7 GHz15dB typ.±0.5dB max.3.0dB typ.21dBm min.+12 to +15225mA max.
PE2-15-7R08R0-3R5-21-12-SFFPreliminary7 GHz8 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-9R010R0-3R5-21-12-SFFPreliminary9 GHz10 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-16-10G11G-2R5-12-12-SFFPreliminary10 GHz11 GHz16dB typ.±0.5dB max.2.5 dB typ.12dBm min.+12 to +1565mA max.
PE2-16-6R07R0-2R0-14-12-SFFPreliminary6 GHz7 GHz16dB typ.±0.5dB max.2.0dB typ.14dBm min.+12 to +1565mA max.
PE2-16-7R08R0-2R5-12-12-SFFPreliminary7 GHz8 GHz16dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +1565mA max.
PE2-16-8R09R0-2R5-12-12-SFFPreliminary8 GHz9 GHz16dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +1565mA max.
PE2-16-9R010R0-2R5-12-12-SFFPreliminary9 GHz10 GHz16dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +1565mA max.
PE2-17-2R03R0-1R8-15-12-SFFPreliminary2 GHz3 GHz17dB typ.±0.5dB max.1.8dB typ.15dBm min.+12 to +1565mA max.
PE2-17-3R04R0-1R8-15-12-SFFPreliminary3 GHz4 GHz17dB typ.±0.5dB max.1.8dB typ.15dBm min.+12 to +1565mA max.
PE2-17-4R05R0-1R8-15-12-SFFPreliminary4 GHz5 GHz17dB typ.±0.5dB max.1.8dB typ.15dBm min.+12 to +1565mA max.
PE2-17-5R06R0-1R8-15-12-SFFPreliminary5 GHz6 GHz17dB typ.±0.5dB max.1.8dB typ.15dBm min.+12 to +1565mA max.
PE2-22-0R81R0-1R2-18-12-SFFPreliminary0.8 GHz1 GHz22 dB Typ±0.25 dB Max1.2 dB Typ18 dBm Min+12 to +15 VDC100 mA Max
PE2-22-18G19G-4R0-10-12-SFFPreliminary18 GHz19 GHz22dB typ.±0.5dB max.4.0dB typ.10dBm min.+12 to +1560mA max.
PE2-22-19G20G-2R5-10-12-SFFPreliminary19 GHz20 GHz22dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1560mA max.
PE2-22-1R01R5-1R5-18-12-SFFPreliminary1 GHz1.5 GHz22 dB Typ±0.25 dB Max1.5 dB Typ18 dBm Min+12 to +15 VDC100 mA Max
PE2-22-1R52R0-1R5-18-12-SFFPreliminary1.5 GHz2 GHz22dB typ.±0.25dB max.1.5dB typ.18dBm min.+12 to +15100mA max.
PE2-22-20G21G-2R5-10-12-SFFPreliminary20 GHz21 GHz22dB typ±0.5dB max.2.5dB typ.10dBm min.+12 to +1560mA max.
PE2-22-21G22G-2R5-10-12-SFFPreliminary21 GHz22 GHz22dB typ±0.5dB max.2.5dB typ.10dBm min.+12 to +1560mA max.
PE2-22-22G23G-2R5-10-12-SFFPreliminary22 GHz23 GHz22dB typ.±0.5dB max.2.5dB typ.10dBm min.+12 to +1560mA max
PE2-22-23G24G-2R5-10-12-SFFPreliminary23 GHz24 GHz22dB typ.±0.5 dB Max.2.5dB typ., 3dB max.10dBm min.+12 to +1580mA nominal
PE2-22-24G25G-2R5-10-12-SFFPreliminary24 GHz25 GHz22dB typ.±0.5dB max2.5 dB typ.8 dBm min.+12 to +15 VDC75 mA nominal
PE2-22-25G26G-2R5-10-12-SFFPreliminary25 GHz26 GHz22dB typ.±0.5 dB Max.2.5dB typ.10dBm min.+12 to +1560mA max
PE2-24-12D5G14D5G-4R0-15-12-SFFPreliminary12.5 GHz14.5 GHz22 dB Min. / 26 dB Max.+/- 1.0dB Max.3.5 dB Max. (0 to +50 Degrees C)+13 dBm Min.+12 to +15 VDC180 mA Max
PE2-24-15D5G17D5G-4R0-15-12-SFFPreliminary15.5 GHz17.5 GHz22 dB Min. / 26 dB Max.+/- 1.0dB Max.4.0 dB Max. (0 to +50 Degrees C)+12 dBm Min.+12 to +15 VDC180 mA Max
PE2-25-9G10G-20-12-SFFPreliminary9 GHz10 GHz25 dB min±0.5dB max.3.0 dB max.+20 dBm min.+12 to +15300mA max.
PE2-28-15G18G-4R0-13-12-SFMPreliminary15 GHz18 GHz26dB typ @ 10.0 to 18.0GHz±0.5dB max.4.0dB typ+13dBm min.+12 to +15VDC200mA max.
PE2-28-15G18G-4R0-13-12-SMMPreliminary15 GHz18 GHz26dB typ @ 10.0 to 18.0GHz±0.5dB max.4.0dB typ+13dBm min.+12 to +15VDC200mA max.
PE2-30-0R50R8-4R5-15-12-SFFPreliminary0.5 GHz0.8 GHz30 dB Typ±0.5 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC140 mA Max
PE2-30-0R50R8-5R5-22-12-SFFPreliminary0.5 GHz0.8 GHz30 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC300 mA Max
PE2-30-0R81R0-5R5-22-12-SFFPreliminary0.8 GHz1 GHz30 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC300 mA Max
PE2-30-10G11G-2R5-12-12-SFFPreliminary10 GHz11 GHz30dB typ.±0.5dB max.2.5 dB typ.12dBm min.+12 to +15140mA max.
PE2-30-11G12G-3R0-14-12-SFFPreliminary11 GHz12 GHz30dB typ.±0.75dB max.3.0dB typ.14dBm min.+12 to +15160mA max.
PE2-30-11G12G-3R5-21-12-SFFPreliminary11 GHz12 GHz30dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15320mA max.
PE2-30-12-1R35-10-12-SFF-BTActive1 GHz2 GHz31dB typ±1.5dB max.1.35dB max+10dBm min+12 to +15VDC140mA max
PE2-30-12G13G-3R0-14-12-SFFPreliminary12 GHz13 GHz30dB typ.±0.75dB max.3.0dB typ.14dBm min.+12 to +15160mA max.
PE2-30-12G13G-3R5-21-12-SFFPreliminary12 GHz13 GHz30dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15320mA max.
PE2-30-13G14G-3R25-14-12-SFFPreliminary13 GHz14 GHz30dB typ.±0.75dB max.3.25dB typ.14dBm min.+12 to +15160mA max.
PE2-30-13G14G-3R5-21-12-SFFPreliminary13 GHz14 GHz30dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15320mA max.
PE2-30-14G15G-3R5-14-12-SFFPreliminary14 GHz15 GHz30dB typ.±0.75dB max.3.5dB typ.14dBm min.+12 to +15160mA max.
PE2-30-14G15G-3R5-21-12-SFFPreliminary14 GHz15 GHz30dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15320mA max.
PE2-30-15G16G-3R5-14-12-SFFPreliminary15 GHz16 GHz30dB typ.±0.75 dB max.3.5dB typ.14dBm min.+12 to +15160mA max.
PE2-30-15G16G-3R5-21-12-SFFPreliminary15 GHz16 GHz30dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15320mA max.
PE2-30-16G17G-3R5-14-12-SFFPreliminary16 GHz17 GHz30dB typ.±0.75dB max.3.5dB typ.14dBm min.+12 to +15160mA max.
PE2-30-16G17G-3R75-20-12-SFFPreliminary16 GHz17 GHz30dB typ.±0.5dB max.3.75 dB typ.20 dBm min.+12 to +15320mA max.
PE2-30-17G18G-4R0-14-12-SFFPreliminary17 GHz18 GHz30dB typ.±0.75dB max.4.0dB typ.14dBm min.+12 to +15160mA max.
PE2-30-17G18G-4R0-20-12-SFFPreliminary17 GHz18 GHz30dB typ.±0.5dB max.4.0dB typ.20 dBm min.+12 to +15320mA max.
PE2-30-18G19G-3R5-10-12-SFFPreliminary18 GHz19 GHz30dB typ.±0.75dB max.3.5dB typ.10dBm min.+12 to +15120mA max.
PE2-30-19G20G-2R5-10-12-SFFActive19 GHz20 GHz30 dB typ.±0.75 dB max.2.5 dB typ. - measured 4.9 dB10 dBm min. - measured 23.15 dB+12 to +15120 mA max. - measured 400 mA
PE2-30-1R01R5-4R5-15-12-SFFPreliminary1 GHz1.5 GHz30 dB Typ±0.5 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC140 mA Max
PE2-30-1R01R5-5R5-22-12-SFFPreliminary1 GHz1.5 GHz30 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC300 mA Max
PE2-30-1R52R0-4R25-15-12-SFFPreliminary1.5 GHz2 GHz30dB typ.±0.5dB max.4.25dB typ.15dBm min.+12 to +15140mA max.
PE2-30-1R52R0-5R0-22-12-SFFPreliminary1.5 GHz2 GHz30dB typ.±0.5dB max.5.0dB typ.22dBm min.+12 to +15300mA max.
PE2-30-20G21G-2R5-10-12-SFFPreliminary20 GHz21 GHz30dB typ.±0.75dB max.2.5dB typ.10dBm min.+12 to +15120 mA nom.
PE2-30-21G22G-2R5-10-12-SFFPreliminary21 GHz22 GHz30dB typ.±0.75dB max.2.5dB typ.10dBm min.+12 to +15120mA max.
PE2-30-22G23G-2R5-10-12-SFFPreliminary22 GHz23 GHz30dB typ.±0.75dB max.2.5dB typ.10dBm min.+12 to +15120mA max.
PE2-30-23G24G-2R5-10-12-SFFPreliminary23 GHz24 GHz30dB typ.±0.75dB max.2.5dB typ.10dBm min.+12 to +15120mA max.
PE2-30-24G25G-2R5-10-12-SFFPreliminary24 GHz25 GHz30dB typ.±0.75 dB max.2.5 dB typ.8 dBm min.+12 to +15 VDC120mA max.
PE2-30-25G26G-2R5-10-12-SFFPreliminary25 GHz26 GHz30dB typ.±0.75dB max.2.5dB typ.10dBm min.+12 to +15120mA max.
PE2-30-2R03R0-2R0-15-12-SFFPreliminary2 GHz3 GHz30dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15140mA max.
PE2-30-2R03R0-2R0-21-12-SFFPreliminary2 GHz3 GHz30dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15300mA max.
PE2-30-3R04R0-2R0-15-12-SFFPreliminary3 GHz4 GHz30dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15140mA max.
PE2-30-3R04R0-2R0-21-12-SFFPreliminary3 GHz4 GHz30dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15300mA max.
PE2-30-4R05R0-2R0-15-12-SFFPreliminary4 GHz5 GHz30dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15140mA max.
PE2-30-4R05R0-2R0-21-12-SFFPreliminary4 GHz5 GHz30dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15300mA Nominal
PE2-30-5R06R0-2R0-15-12-SFFPreliminary5 GHz6 GHz30dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15140mA max.
PE2-30-5R06R0-2R0-21-12-SFFPreliminary5 GHz6 GHz30dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15300mA max.
PE2-30-6R07R0-2R0-14-12-SFFPreliminary6 GHz7 GHz30dB typ.±0.5dB max.2.0dB typ.14dBm min.+12 to +15140mA max.
PE2-30-6R07R0-2R0-21-12-SFFPreliminary6 GHz7 GHz30dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15300mA max.
PE2-30-7R08R0-2R5-12-12-SFFPreliminary7 GHz8 GHz30 dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +15140mA max.
PE2-30-7R08R0-2R5-21-12-SFFPreliminary7 GHz8 GHz30 dB typ.±0.5dB max.2.5dB typ.21dBm min.+12 to +15300mA max.
PE2-30-8R09R0-1R0-2-12-SFFPreliminary8 GHz9 GHz30dB typ.±0.5dB max.1.0dB typ.2dBm min.+12 to +1525mA max.
PE2-30-8R09R0-2R5-12-12-SFFPreliminary8 GHz9 GHz30dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +15140mA max.
PE2-30-8R09R0-2R5-21-12-SFFPreliminary8 GHz9 GHz30dB typ.±0.5dB max.2.5dB typ.21dBm min.+12 to +15300mA max.
PE2-30-9R010R0-1R0-2-12-SFFPreliminary9 GHz10 GHz30dB typ.±0.5dB max.1.0dB typ.2dBm min+12 to +1525mA max.
PE2-30-9R010R0-2R5-12-12-SFFPreliminary9 GHz10 GHz30dB typ.±0.5dB max.2.5dB typ.12dBm min.+12 to +15140mA max.
PE2-40-10G11G-1R25-12-12-SFFPreliminary10 GHz11 GHz40dB typ.±0.75dB max.1.25dB typ.12dBm min.+12 to +15120mA max.
PE2-40-10G11G-2R75-14-12-SFFPreliminary10 GHz11 GHz40dB typ.±0.5dB max.2.75dB typ.14dBm min.+12 to +15140mA max.
PE2-40-11G12G-3R0-14-12-SFFPreliminary11 GHz12 GHz40dB typ.±0.75dB max.3.0dB typ.14dBm min.+12 to +15250mA max.
PE2-40-12G13G-3R0-14-12-SFFPreliminary12 GHz13 GHz40dB typ.±0.75dB max.3.0dB typ.14dBm min.+12 to +15250mA max.
PE2-40-13G14G-3R25-14-12-SFFPreliminary13 GHz14 GHz40dB typ.±0.75dB max.3.25dB typ.14dBm min.+12 to +15250mA max.
PE2-40-14G15G-3R5-14-12-SFFPreliminary14 GHz15 GHz40dB typ.±0.75dB max.3.5dB typ.14dBm min.+12 to +15250mA max.
PE2-40-15G16G-3R5-14-12-SFFPreliminary15 GHz16 GHz40dB typ.±0.75 dB max.3.5dB typ.14dBm min.+12 to +15250mA max.
PE2-40-16G17G-3R5-14-12-SFFPreliminary16 GHz17 GHz40dB typ.±0.75dB max.3.5dB typ.14dBm min.+12 to +15250mA max.
PE2-40-17G18G-4R0-14-12-SFFPreliminary17 GHz18 GHz40dB typ.±0.75dB max.4.0dB typ.14dBm min.+12 to +15250mA max.
PE2-40-2R03R0-2R0-15-12-SFFPreliminary2 GHz3 GHz40dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15225mA max.
PE2-40-3R04R0-2R0-15-12-SFFPreliminary3 GHz4 GHz40dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15225mA max.
PE2-40-4R05R0-2R0-15-12-SFFPreliminary4 GHz5 GHz40dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15225mA max.
PE2-40-5R06R0-2R0-15-12-SFFPreliminary5 GHz6 GHz40dB typ.±0.5dB max.2.0dB typ.15dBm min.+12 to +15225mA max.
PE2-40-6R07R0-2R0-14-12-SFFPreliminary6 GHz7 GHz40dB typ±0.5dB max.2.0dB typ.14dBm min.+12 to +15225mA max.
PE2-40-7R08R0-1R2-12-12-SFFPreliminary7 GHz8 GHz40dB typ.±0.75dB max.1.2dB typ12dBm min.+12 to +15120mA max.
PE2-40-7R08R0-2R5-14-12-SFFPreliminary7 GHz8 GHz40dB typ.±0.5dB max.2.5dB typ.14dBm min.+12 to +15140mA max.
PE2-40-8R09R0-2R5-14-12-SFFPreliminary8 GHz9 GHz40dB typ.±0.5dB max.2.5dB typ.14dBm min.+12 to +15140mA max.
PE2-40-9R010R0-2R5-14-12-SFFPreliminary9 GHz10 GHz40dB typ±0.5dB max.2.5 dB typ.14 dBm min.+12 to +15140mA max.
PE2-42-2G-2R0-15-SFFActive1.4 GHz2.4 GHz42dB min.±1.0dB max.1.8dB typical, 3.0dB max.+22dBm typ., +17dBm min.+12 to +15350mA max.
PE2-45-0R50R08-4R5-15-12-SFFPreliminary0.5 GHz0.8 GHz45 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC200 mA Max
PE2-45-0R50R8-5R5-22-12-SFFPreliminary0.5 GHz0.8 GHz45 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC385 mA Max
PE2-45-0R81R0-4R5-15-12-SFFPreliminary0.8 GHz1 GHz45 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC200 mA Max
PE2-45-0R81R0-5R5-22-12-SFFPreliminary0.8 GHz1 GHz45 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC385 mA Max
PE2-45-11G12G-3R5-21-12-SFFPreliminary11 GHz12 GHz45dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-12G13G-3R5-21-12-SFFPreliminary12 GHz13 GHz45dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-13G14G-3R5-21-12-SFFPreliminary13 GHz14 GHz45dB typ±0.5dB max.3.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-14G15G-3R5-21-12-SFFPreliminary14 GHz15 GHz45dB typ±0.5dB max.3.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-15G16G-3R5-21-12-SFFPreliminary15 GHz16 GHz45dB typ±0.5dB max.3.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-16G17G-3R75-20-12-SFFPreliminary16 GHz17 GHz45dB typ.±0.5dB max.3.75 dB typ.20 dBm min.+12 to +15380mA max.
PE2-45-17G18G-4R0-20-12-SFFPreliminary17 GHz18 GHz45dB typ.±0.5dB max.4.0dB typ.20 dBm min.+12 to +15380mA max.
PE2-45-1R01R5-4R5-15-12-SFFPreliminary1 GHz1.5 GHz45 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC200 mA Max
PE2-45-1R01R5-5R5-22-12-SFFPreliminary1 GHz1.5 GHz45 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC385 mA Max
PE2-45-1R52R0-4R25-15-12-SFFPreliminary1.5 GHz2 GHz45dB typ.±0.75dB max.4.25dB typ.15dBm min.+12 to +15200mA max.
PE2-45-1R52R0-5R0-22-12-SFFPreliminary1.5 GHz2 GHz45dB typ.±0.75dB max.5.0dB typ.22dBm min.+12 to +15385mA max.
PE2-45-2R03R0-2R0-21-12-SFFPreliminary2 GHz3 GHz45dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15380mA max.
PE2-45-3R04R0-2R0-21-12-SFFPreliminary3 GHz4 GHz45dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15380mA max.
PE2-45-4R05R0-2R0-21-12-SFFPreliminary4 GHz5 GHz45dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15380mA max.
PE2-45-5R06R0-2R0-21-12-SFFPreliminary5 GHz6 GHz45dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15380mA max.
PE2-45-6R07R0-2R0-21-12-SFFPreliminary6 GHz7 GHz45dB typ.±0.5dB max.2.0dB typ.21dBm min.+12 to +15380mA max.
PE2-45-7R08R0-1R5-17-12-SFFPreliminary7 GHz8 GHz45dB typ.±0.75dB max.1.5dB typ.17dBm min.+12 to +15250mA max.
PE2-45-7R08R0-2R5-21-12-SFFPreliminary7 GHz8 GHz45dB typ.±0.5dB max.2.5dB typ.21dBm min.+12 to +15380mA max
PE2-45-8R09R0-1R5-17-12-SFFPreliminary8 GHz9 GHz45dB typ.±0.75dB max.1.5dB typ.17dBm min.+12 to +15250mA max.
PE2-45-8R09R0-2R5-21-12-SFFPreliminary8 GHz9 GHz45dB typ.±0.5dB max.2.5dB typ.21dBm min.+12 to +15380mA max.
PE2-45-9R010R0-1R5-17-12-SFFPreliminary9 GHz10 GHz45dB typ.±0.75dB max.1.5dB typ.17dBm min.+12 to +15250mA max
PE2-60-0R50R8-4R5-15-12-SFFPreliminary0.5 GHz0.8 GHz60 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC280 mA Max
PE2-60-0R50R8-5R5-22-12-SFFPreliminary0.5 GHz0.8 GHz60 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC475 mA Max
PE2-60-0R81R0-4R5-15-12-SFFPreliminary0.8 GHz1 GHz60 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC280 mA Max
PE2-60-0R81R0-5R5-22-12-SFFPreliminary0.5 GHz0.8 GHz60 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC475 mA Max
PE2-60-10G11G-2R75-14-12-SFFPreliminary10 GHz11 GHz60dB typ.±0.75dB max.2.75dB typ.14dBm min.+12 to +15300mA max.
PE2-60-10G11G-2R75-21-12-SFFPreliminary10 GHz11 GHz60dB typ.±0.75dB max.2.75dB typ.21dBm min.+12 to +15300mA max.
PE2-60-11G12G-3R25-14-12-SFFPreliminary11 GHz12 GHz60dB typ.±1.0dB max.3.25dB typ.14dBm min.+12 to +15325mA max.
PE2-60-11G12G-3R5-21-12-SFFPreliminary11 GHz12 GHz60dB typ.±0.75dB max.3.5dB typ.21dBm min.+12 to +15475mA max.
PE2-60-12G13G-3R25-14-12-SFFPreliminary12 GHz13 GHz60dB typ.±1.0dB max.3.25dB typ.14dBm min.+12 to +15325mA max.
PE2-60-12G13G-3R5-21-12-SFFPreliminary12 GHz13 GHz60dB typ.±0.75dB max.3.5dB typ.21dBm min.+12 to +15475mA max.
PE2-60-13G14G-3R5-14-12-SFFPreliminary13 GHz14 GHz60dB typ.±1.0dB max.3.5dB typ.14dBm min.+12 to +15325mA max.
PE2-60-13G14G-3R5-21-12-SFFPreliminary13 GHz14 GHz60dB typ.±0.75dB max.3.5dB typ.21dBm min.+12 to +15475mA max.
PE2-60-14G15G-3R5-14-12-SFFPreliminary14 GHz15 GHz60dB typ.±1.0dB max.3.5dB typ.14dBm min.+12 to +15325mA max.
PE2-60-14G15G-3R5-21-12-SFFPreliminary14 GHz15 GHz60dB typ.±0.75dB max.3.5dB typ.21dBm min.+12 to +15475mA max.
PE2-60-15G16G-3R5-14-12-SFFPreliminary15 GHz16 GHz60dB typ.±1.0dB max.3.5dB typ.14dBm min.+12 to +15325mA max.
PE2-60-15G16G-3R5-21-12-SFFPreliminary15 GHz16 GHz60dB typ.±0.75 dB max.3.5dB typ.21dBm min.+12 to +15475mA max.
PE2-60-16G17G-3R5-14-12-SFFPreliminary16 GHz17 GHz60dB typ.±1.0dB max.3.5dB typ.14dBm min.+12 to +15325mA max.
PE2-60-16G17G-3R75-20-12-SFFPreliminary16 GHz17 GHz60dB typ.±0.75dB max.3.75 dB typ.20 dBm min.+12 to +15475mA max.
PE2-60-17G18G-4R0-14-12-SFFPreliminary17 GHz18 GHz60dB typ.±1.0dB max.4.0dB typ.14dBm min.+12 to +15325mA max.
PE2-60-17G18G-4R0-20-12-SFFPreliminary17 GHz18 GHz60dB typ.±0.75dB max.4.0dB typ.20 dBm min.+12 to +15475mA max.
PE2-60-1R01R5-4R5-15-12-SFFPreliminary1 GHz1.5 GHz60 dB Typ±0.75 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC280 mA Max
PE2-60-1R01R5-5R5-22-12-SFFPreliminary1 GHz1.5 GHz60 dB Typ±0.75 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC475 mA Max
PE2-60-1R52R0-4R25-15-12-SFFPreliminary1.5 GHz2 GHz60dB typ.±0.75dB max.4.25dB typ.15dBm min.+12 to +15280mA max.
PE2-60-1R52R0-5R0-22-12-SFFPreliminary1.5 GHz2 GHz60dB typ.±0.75dB max.5.0dB typ.22dBm min.+12 to +15475mA max.
PE2-60-2R03R0-2R0-15-12-SFFPreliminary2 GHz3 GHz60dB typ.±0.75dB max.2.0dB typ.15dBm min.+12 to +15300mA max.
PE2-60-2R03R0-2R0-21-12-SFFPreliminary2 GHz3 GHz60dB typ.±0.75dB max.2.0dB typ.21dBm min.+12 to +15425mA max.
PE2-60-3R04R0-2R0-21-12-SFFPreliminary3 GHz4 GHz60dB typ.±0.75dB max.2.0dB typ.21dBm min.+12 to +15425mA max.
PE2-60-4R05R0-2R0-15-12-SFFPreliminary4 GHz5 GHz60dB typ.±0.75dB max.2.0dB typ.15dBm min.+12 to +15300mA max.
PE2-60-4R05R0-2R0-21-12-SFFPreliminary4 GHz5 GHz60dB typ.±0.75dB max.2.0dB typ.21dBm min.+12 to +15425mA max.
PE2-60-5R06R0-2R0-15-12-SFFPreliminary5 GHz6 GHz60dB typ.±0.75dB max.2.0dB typ.15dBm min.+12 to +15300mA max.
PE2-60-5R06R0-2R0-21-12-SFFPreliminary5 GHz6 GHz60dB typ.±0.75dB max.2.0dB typ.21dBm min.+12 to +15425mA max.
PE2-60-6R07R0-2R0-14-12-SFFPreliminary6 GHz7 GHz60 dB typ.±0.75 dB max.2.0dB typ.12 dBm min.+12 to +15300mA max.
PE2-60-8R09R0-2R5-14-12-SFFPreliminary8 GHz9 GHz60dB typ.±0.75dB max.2.5dB typ.14dBm min.+12 to +15300mA max.
PE2-60-8R09R0-2R5-21-12-SFFPreliminary8 GHz9 GHz60dB typ.±0.75dB max.2.5dB typ.21dBm min.+12 to +15425mA max.
PE2-60-9R010R0-2R5-14-12-SFFPreliminary9 GHz10 GHz60dB typ.±0.75dB max.2.5 dB typ.14dBm min.+12 to +15300mA max.
PE2-60-9R010R0-2R5-21-12-SFFPreliminary9 GHz10 GHz60dB typ.±0.75dB max.2.5 dB typ.21dBm min.+12 to +15425mA max.
PEC-22-41G43G-6R0-24-292FFPreliminary41 GHz43 GHz22dB min.±1.5dB typ.6.0dB max.24dBm min.+8VDC500mA max
PEC-30-100M500M-2R5-15-12-SFFPreliminary0.1 GHz0.5 GHz25 dB Min±3.0 dB Max2.0 dB Typ, 2.5 dB Max+15 dBm Min+15 VDC200 mA Nom
PEC-30-800M3G-2R5-15-12-SFFPreliminary0.8 GHz3.0 GHz25 dB Min±3.0 dB Max2.25 dB Typ, 2.5 dB Max+15 dBm Min+15 VDC200 mA Nom
PEC4-18G22G-1R7-8-23-SFFPreliminary18 GHz22 GHz+23 dB min.±1.5 dB max.1.7 dB max.+8 dBm min.+15 V120 mA nom.
PEC-53-12-10-15-SFF (Rev B)Active1 GHz2 GHz53 dB min±0.75 dB max - measured ±0.69 dB0.7 dB typical - measured 0.80 dB+16 dBm min - measured +17.8 dBm+12 to +15 VDC nominal450 mA max - measured 253 mA
AMP-28G30G-27-10-15-SFFPreliminary28 GHz30 GHz27 dB min.±1.5 dB max2.5 dB max-9 dBm min.+15 V225 mA nominal
GMPA-1001Active0.4 GHz0.5 GHz40 dB Min
-
8.0 dB Max
-
+14 to +15.5 VDC3.2 A Typ., 3.6 A Max.
LNA-10R7G12R75G-12-1R0-5-15-292FFPreliminary10.7 GHz12.75 GHz12 dB Typ0.5 dB PK-PK Typ, 1.5 dB Max55 °K (0.75 dB) Goal, 70 °K (0.94 dB) Max5 dBm Min+8 To +15 VDC15 mA max.
LNA-14D7G15D3G-25-1D5-10-15-SFFPreliminary14.75 GHz15.25 GHz23 dB min., 27 dB max.±0.75dB max.1.5 dB typ. 2.0 dB max.+10 dB min.+15 V100 mA typ.
LNA-14D7G15D3G-25-1D5-10-15-SFF-SPreliminary14.75 GHz15.25 GHz23 dB min., 27 dB max.±0.75 dB max.1.5 dB typ. 2.0 dB max.+10 dB min.+15 V100 mA typ.
LNA-19-560M640M-2D0-0-12-SFFActive0.56 GHz0.64 GHz19 dB Min
-
2.0 dB Maximum - Measured 1.28 dB0 dBm Minimum - Measured 19.05 dBm+12 VDC150 mA
LNA-20-0R4G0R5G-0R6-18-5-SFFPreliminary0.4 GHz0.5 GHz20 dB min.
-
0.6 dB max.18 dBm min.+5 VDC120 mA max.
LNA-25-8R95G9R55G-6R0-33-12-SFFPreliminary8.95 GHz9.55 GHz25 dB Min± 1.5 dB Max4 dB Goal, 6 dB Max33 dBm Min+12 VDC3 A typ.
LNA-28-8R95G9R55G-6R0-36-12-SFFPreliminary8.95 GHz9.55 GHz28 dB Min± 1.5 dB Max4 dB Goal, 6 dB Max36 dBm Min+12 VDC6 A typ.
LNA-31-8R95G9R55G-6R0-39-12-SFFPreliminary8.95 GHz9.55 GHz31 dB Min± 1.5 dB Max4 dB Goal, 6 dB Max39 dBm Min+12 VDC8 A typ.
LNA-3D6G4D2G-50D0-0D56-15-SFFPreliminary3.6 GHz4.2 GHz50 dB Min.±0.5 dB max.0.56 dB max.10 dBm min.+ 15 V200 mA max.
PE2-10-10G11G-4R0-14-12-SFFPreliminary10 GHz11 GHz10dB typ.±0.5dB max.4.0dB typ.14dBm min.+12 to +1565mA max.
PE2-10-11G12G-4R5-14-12-SFFPreliminary11 GHz12 GHz10dB typ.±0.5dB max.4.5dB typ.14dBm min.+12 to +1565mA max.
PE2-10-12G13G-4R5-14-12-SFFPreliminary12 GHz13 GHz10dB typ.±0.5dB max.4.5dB typ.14dBm min.+12 to +1565mA max.
PE2-10-13G14G-4R5-14-12-SFFPreliminary13 GHz14 GHz10dB typ.±0.5dB max.4.5dB typ.14dBm min.+12 to +1565mA max.
PE2-10-14G15G-5R0-14-12-SFFPreliminary14 GHz15 GHz10dB typ.±0.5dB max.5.0dB typ.14dBm min.+12 to +1565mA max
PE2-10-15G16G-5R0-14-12-SFFPreliminary15 GHz16 GHz10dB typ.±0.5dB max.5.0dB typ.14dBm min.+12 to +1565mA max
PE2-10-16G17G-5R0-14-12-SFFPreliminary16 GHz17 GHz10dB typ.±0.5dB max.5.0dB typ.14dBm min.+12 to +1565mA max.
PE2-10-17G18G-5R0-14-12-SFFPreliminary17 GHz18 GHz10dB typ.±0.5dB max.5.0dB typ.14dBm min.+12 to +1565mA max.
PE2-10-2R03R0-4R0-15-12-SFFPreliminary2 GHz3 GHz10dB typ.±0.5dB max.4.0dB typ15dBm min+12 to +1565mA max.
PE2-10-3R04R0-4R0-15-12-SFFPreliminary3 GHz4 GHz10dB typ.±0.5dB max.4.0dB typ.15dBm min.+12 to +1565mA max.
PE2-10-4R05R0-3R5-15-12-SFFPreliminary4 GHz5 GHz10dB typ.±0.5dB max.3.5dB typ.15dBm min.+12 to +1565mA max.
PE2-10-5R06R0-3R5-15-12-SFFPreliminary5 GHz6 GHz10dB typ.±0.5dB max.3.5dB typ.13dBm min.+12 to +1565mA max.
PE2-13-17G24G-5R0-18-12-SFFPreliminary17 GHz24 GHz15dB typ±1.5dB max5.0dB max.18dBm typ, +20dBm goal+12 to +15VDC typ225mA nominal
PE2-15-0R81R0-4R25-15-12-SFFPreliminary0.8 GHz1 GHz15 dB Typ±0.5 dB Max4.25 dB Typ15 dBm Min+12 to +15 VDC65 mA Max
PE2-15-14G15G-3R5-21-12-SFFPreliminary14 GHz15 GHz15dB typ.±0.5dB max.3.5dB typ.21dBm min.+12 to +15225mA max.
PE2-15-17G18G-4R0-14-12-SFFPreliminary17 GHz18 GHz15dB typ.±0.5dB max.4.0dB typ.14dBm min.+12 to +1580mA max.
PE2-15-17G18G-4R0-20-12-SFFPreliminary17 GHz18 GHz15dB typ.±0.5dB max.4.0dB typ.20 dBm min.+12 to +15225mA max.
PE2-15-1R52R0-5R0-22-12-SFFPreliminary1.5 GHz2 GHz15 dB±0.5 dB max.5.0 dB typ.22 dBm+12 to +15 V225 mA
PE2-22-0R50R8-1R2-18-12-SFFPreliminary0.5 GHz0.8 GHz22 dB Typ±0.25 dB Max1.2 dB Typ16 dBm Min+12 to +15 VDC100 mA Max
PE2-23-1G2G-5R0-25-15-SFFPreliminary1 GHz2 GHz20 dB Min, 24 dB Max±0.75 dB Typ5.0 dB Typ, 5.25 dB Max+25 dBm Min+15 VDC525 mA Nom
PE2-24-5G8G-1R2-5-28-SFFPreliminary5 GHz8 GHz24 dB nom., 21 dB min±1.0dB Max1.2 dB Typical, 1.4 dB Max+5 dBm Minimum+28 VDC95 mA nominal
PE2-26-9G10G-3R5-23-12-SFFPreliminary9 GHz10 GHz26 dB typ.±1.0 dB max.3.0 dB max.26 dBm typ., 25 dBm max.+12 to +15 VDC325 mA typ.
PE2-30-9R010R0-2R5-21-12-SFFActive9 GHz10 GHz30dB typ.±0.5dB max.2.5 dB typ. - Measured 3.07 dB21 dBm min. - Measured >21 dBm+12 to +15300 mA max. - Measured 300 mA
PE2-45-9R010R0-2R5-21-12-SFFPreliminary9 GHz10 GHz45dB typ.±0.5dB max.2.5 dB typ. @ +25°C21dBm min.+12 to +15380mA max
PE2-60-3R04R0-2R0-15-12-SFFPreliminary3 GHz4 GHz60dB typ.±0.75dB max.2.0dB typ.15dBm min.+12 to +15300mA max.
PE2-60-7R08R0-2R5-14-12-SFFPreliminary7 GHz8 GHz60 dB typ.±0.75 dB max.2.5 dB typ.12 dBm min.+12 to +15 VDC300 mA max.
PE2-60-7R08R0-2R5-21-12-SFFPreliminary7 GHz8 GHz60 dB typ.±0.75 dB max.2.5 dB typ.19 dBm min.+12 to +15425 mA typ.
PEC-10M1D5G-30-10-13-SFFPreliminary0.01 GHz1.5 GHz40 dB typ., 36 dB min
-
-
+15 dB max @ 1 dB Compression12 V115 mA max.
PEC1-17-1575D42-1-15-SFFPreliminary1.575 GHz1.575 GHz17 dB min.±1.0 dB max.0.8 dB goal, 1 dB max.17 dBm min.+12 to +15 VDC125 mA max.
PEC-15-400M470M-37-12V-SFFActive0.4 GHz0.47 GHz10 dB Min, 15 dB Typ±0.75 dB Typ, ±1.0 dB Max
-
+37 dBm Min, +38 dBm Typ+11.5 V Min, +12 V Typ, +13 V Max1600 mA Typ, 1900 mA Max
PEC-25-0R8G2D5G-2R5-20-SFF-LPNPreliminary0.8 GHz2.5 GHz25 dB Nom±1.5 dB Max2.5 dB Typ+20 dBm Min+12 to +15 VDC220 mA nominal
PEC-25-135M165M-1R0-18-12-SFFPreliminary0.135 GHz0.165 GHz25 dB Nom, 22 dB Min±0.5 dB Max1.0 dB Max+18 dBm Typ+12 to +15 VDC75 mA nominal
PEC-25-5D245D76-1R1-13-SFFPreliminary5.24 GHz5.76 GHz24dB min, 28dB max.±1.0dB max.1.1dB max, 1.0dB typ+13dBm min @ 1.dB PT+15VDC150 mA typ.
PEC-25-70M330M-2-20-5-SFFPreliminary0.07 GHz0.33 GHz20 dB min., 25 dB typ.
-
2.0 dB typ.20 dBm min.+5 VDC (±5%)100 mA
PEC-28-10M3G-1R9-13-12-SFFPreliminary0.01 GHz3 GHz30 dB typ.±0.75 dB typ, ±1.0 dB max.1.6 dB typ., 1.9 dB max.10 dBm min., 13 dBm typ.+12 to +15 VDC120 mA max.
PEC-9770M10270M-12-17R5-15-SFFPreliminary9.77 GHz10.27 GHz
-
-
12 dB max.+17.5 dBm nominal (Transferred to the Specified Load with Input Power Applied)+ 15 VDC ±1%0.4 ADC max.
PPA-13D75G14D5G-45-37-7-SFFActive13.75 GHz14.5 GHz45 dB Min±1.0 dB Typ7.0 dB Max. - Measured 6.18 dB37 dBm Min. - Measured 37.41 dB+8 to +9 VDC6 A Typ. Measured: <-20 dBm:3.83 A, -20 to -15 dBm:4.42 A, >-15 dBm:5.73 A
LNA-19-8M12M-3D0-20-12-SFFActive0.008 GHz0.012 GHz19 dB Min. 20 dB Typ.
-
4.5 dB Max. - Measured 2.77 dB20 dBm Min. - Measured 23.04 dBm+12 VDC150 mA typ.
LNA-25-2D7G3D3G-1D5-10-12-SFFActive2.7 GHz3.3 GHz25 dB Min. 26 dB Typ.
-
1.5 dB Max. - Measured 1.4 dB10 dBm Min. - Measured 23.37 dBm+12 VDC230 mA typ.
LNA-2D7G3D1G-29-0D6-16D5-15-SFMPreliminary2.7 GHz3.1 GHz28 to 30 dB±1.0 dB max.0.6 dB max. 0.53 dB typ. (0.005 dB/°C)+13 dBm min, +16.5 dBm typ.+8 to +11.5 V125 mA max.
LNA-2D7G3D1G-29-0D7-16D5-15-SFMPreliminary2.7 GHz3.1 GHz28 to 30 dB±1.0 dB max0.65 dB max+13 dBm min, +16.5 dBm typ+8 to +15 V125 mA max.
PE13-18-30G40G-4R0-8-12-292FFPreliminary30 GHz40 GHz18dB nominal±3.0dB max4.0dB typ (See Note 1)+8dBm typ+12 to +15VDC100 mA nominal
PE2-10-9R010R0-4R0-14-12-SFFPreliminary9 GHz10 GHz10dB typ.±0.5dB max.4.0dB typ.14dBm min.+12 to +15 VDC65mA max.
PE2-15-0R81R0-5R5-22-12-SFFPreliminary0.8 GHz1 GHz15 dB Typ±0.5 dB Max5.5 dB Typ22 dBm Min+12 to +15 VDC225 mA Max
PE2-15-13G14G-3R5-21-12-SFFActive13 GHz14 GHz15dB typ.±0.5dB max.3.5dB max.19dBm min.+12 to +15250mA typ.
PE2-15-8R09R0-3R5-21-12-SFFActive8 GHz9 GHz15dB typ.±0.5dB max.3.5dB typ.21 dBm min. - Measured 22 dBm+12 to +15225 mA max. - Measured 225 mA
PE2-30-10G11G-1R0-2-12-SFFActive10 GHz11 GHz30dB typ.±0.5dB max.1.0dB typ.2 dBm min. - Measured >=+2 dBm+12 to +1525 mA max. - Measured 28 mA
PE2-40-8R09R0-1R2-12-12-SFFActive8 GHz9 GHz40dB typ.±0.75dB max.1.2dB typ.12dBm min.+12 to +15120mA max
PE2-40-9R010R0-1R2-12-12-SFFActive9 GHz10 GHz40dB typ±0.75dB max.1.2dB typ.12 dBm min. - Measured 12 dBm+12 to +15120 mA max. - Measured 120 mA
LNA-11-520M580M-3D0-30-12-SFFActive0.52 GHz0.58 GHz11 dB min. 12 dB typ.
-
4.0 dB max. - Measured 3.46 dB30 dBm min. - Measured 30 dBm+12 VDC400 mA typ.
PA-25002700-35-CD-SFFActive2.500 GHz2.700 GHz31.5 dB min., 34.5 dB max.±0.5 dB typ., ±0.75 dB max5.0 dB typ., 8.0 dB max.+35 dBm min., +36 dBm typ.+11.5 V to 13.0 V2500 mA typ., 3000 mA max.
PA-40-17D521D5-5R0-36-12-292FFActive17.5 GHz21.5 GHz37dB min, 40dB typ±1.5dB typ, ±1.75dB typ5.0dB typ, 8.0dB max+36dBm min, +37dBm typ+9 to +12VDC @ 3.5A typ, 5.0 max3.5 A typ., 5.0 A max.
PE2-30-7R08R0-1R0-2-12-SFFActive7 GHz8 GHz30 dB typ.±0.5dB max.1.0 dB typ.2 dBm min.+12 to +1525 mA max
PE2-34-1R251R75-12-SFF-1Active1.25 GHz1.75 GHz34dB min±0.25dB Typical, ±1.5dB max.4.98dB Typical, 8.0dB max0dBm min+7 to +12 VDC200 mA max. @ +10 dBm CW Input
PEC-37-9G10G-3R0-27-SFFActive9 GHz10 GHz34 dB Min, 40 dB Max±0.35 dB Typ, ±0.5 dB Max2.5 dB Typ, 3.0 dB Max+27 dBm Min, +28 dBm Typ+10 VDC /+12 VDC / +15 VDC300 mA Min / 400 mA Typ / 700 mA Max
PEC-53-12-10-15-SFFActive1 GHz2 GHz53 dB min±0.75 dB max - measured ±0.69 dB3.5 dB max - measured 0.8 dB+5 dBm min - measured +17.8 dBm+12 to +15 VDC nominal450 mA max - measured 253 mA
LNA-38-4M96M-4D3-25-15-SFFActive4 MHz96 MHz38 dB Max, 40 dB Typ
-
4.3 dB Max - Measred 3.77 dB+25 dBm Min, +27 dBm Typ - Measured 30 dBm+12 to +20 VDC450 mA Max
PE2-45-10G11G-1R5-17-12-SFFActive10 GHz11 GHz45dB typ.±0.75dB max.1.5dB typ17dBm typ.+12 to +15250mA max.
GMPA-1002Active1 GHz1.5 GHz45 dB min.
-
12.0 dB max.
-
+27 to +29 VDC7 A typ., 9 A max.
PE2-28-15G18G-4R0-13-12-SFFActive15 GHz18 GHz26dB Typ @ 10.0 to 18.0 GHz±0.5 dB Max4.0 dB Typ - Measured 3.21 dB+13 dBm Min - Measured +14.5 dBm+12 to +15 VDC200 mA Max - Measured 139 mA
PE2-10-6R07R0-3R5-14-12-SFFPreliminary6 GHz7 GHz10dB min.±0.5dB max.3.5dB typ.12dBm min.+12 to +1585mA typ.
PE2-30-0R81R0-4R5-15-12-SFFPreliminary0.8 GHz1 GHz30 dB Typ±0.5 dB Max4.5 dB Typ15 dBm Min+12 to +15 VDC180 mA Nom
