| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Range (GHz): | 0.01 to 12.4 GHz |
|---|
| Frequency Min (GHz): | 0.01 GHz |
|---|
| Frequency Max (GHz): | 12.4 GHz |
|---|
| VSWR In/Out: | 1.5:1 Max |
|---|
| Frequency Flatness (dB): | ±1.0 dB Typ |
|---|
| Max Input Power: | 100 mW (+20 dBm) Max |
|---|
| Sensitivity: | 0.5 ± 0.05 mV/µW |
|---|
| Polarity: | Negative |
|---|
| Flatness: | ±0.5 dB |
|---|
| Capacitance: | 30 pf |
|---|
| Connectors In/Out: | SMA (M)/SMA (F) |
|---|
| Finish: | Albaloy plated |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -54 °C to +110 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Con.d G (50g, 11 ms) |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. D (20 g, 10 - 2000 MHz) |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
