Select PMI products are available from stock that can be shipped from PMI directly or one of its authorized distributors to you the same day.

Stock can be checked using the “Buy Now” Button on select product specification sheets or select from the available Stock Items (pmi-rf.com) listing below.

Data shown below may not be for the same serial number that you receive. Actual data per serial number is available upon request.

Actual quantity On-Hand subject to change. Please contact us to verify actual stock.

Frequency Discriminators & IFM

Part NumberAvailabilitySizeFrequency MaxFrequency MinStatus
FD-0518-10-812Buy Now2.00" x 1.80" x 0.50"12 GHz8 GHzActive

Limiters - RF / Microwave / mmWave

Part NumberAvailabilityInput PowerInput/Output VSWRInsertion LossFrequency MaxFrequency MinStatus
LM-218-14-200W-SMF *Buy Now1 W CW2.0:1 max.2.0 dB max. @ Pin = -10 dBm18.0 GHz2.0 GHzActive
LM-6G18G-15-10W-SFF *Buy Now10 W CW (Peak)1.8:12.5 dB Typ @ 0 dBm18 GHz6 GHzActive
LM-1G2G-19-200W-SFFBuy Now+53 dBm CW Max (200 W)
+55 dBm Peak 3 µs Pulse, 10% Duty Cycle (320 W)
2:1 max.1.3 dB Max2.0 GHz1.0 GHzActive
LM-1G18G-16-4W-SMFBuy Now4W CW, 100W Peak (1 us Pulse Width, 0.1% Duty Cycle)2.0:1 Max2.3 dB18.0 GHz1.0 GHzActive
LM-218-14-200W-SMF-HERM *Buy Now1 W CW2.0:1 max2.0 dB Maximum18 GHz2 GHzActive
LM-300M1G-21-360W-SFFBuy Now+54 dBm CW Max (250 W)
Peak Power 360 W, Pulse 2 ms, 10% Duty Cycle
2:1 Max
-
1.0 GHz0.3 GHzActive
LM-10M37G-15DBM-10W-AGALBuy Now50 Watts Peak Max (0.02 to 12 GHz)
40 Watts Peak Max (18 GHz)
(1 µs Pw, 1% Duty Cycle)
1.8:1 Max0.01 to 8 GHz: 1.00 dB Max
8 to 18 GHz: 2.00 dB Max
18 to 30 GHz: 2.70 dB Max
30 to 37 GHz: 4.30 dB Max
37.0 GHz0.01 GHzActive
LM-10M12G-20-10W-SFFBuy Now+40 dBm CW Max
Peak Power 100 W,
Pulse 1 µs 1% Duty Cycle
2:1 Max2 dB Max12.0 GHz0.01 GHzActive
LM-0518-10-1W-SHS-1-F *Buy Now1 Watt CW, 100 Watts Peak, 1 µs Pulse,
0.1% Duty Cycle, Derated to 20% at 125 ºC
2.0:1 Max2.0 dB Max, 1.5 dB Typ18 GHz0.5 GHzActive
LM-10M50G-20DBM-1W-24FFBuy Now10 Watts Peak Max (0.02 to 1 GHz)
6 Watts Peak Max (4 GHz to 8 GHz)
4 Watts Peak Max (12 GHz to 18 GHz)
(Pw 1 µs, 1 % Duty Cycle)
2.01 Max0.01 to 18 GHz = 1.50 dB Max
18 to 40 GHz = 2.30 dB Max
40 to 50 GHz = 2.50 dB Max
50.0 GHz0.01 GHzActive
LM-1G18G-15-3W-500WP-SFFBuy Now3 W CW2.0:1 Max2.5 dB18.0 GHz1.0 GHzActive
LM-10M6G-15-2D5W-SFFBuy Now2.5 W (+34 dBm) CW Max
Peak Power 3 W (+35 dBm),
Pulse 1 µs 1% Duty Cycle
1.8:1 Max2 dB Max6.0 GHz (Usable to 10.0 GHz)0.01 GHzActive
LM-20M80M-10-20WBuy NowCW In-Band 5 to 10 Watts, CW Out of Band 20 Watts max2.0:1 max1.5dB max, 0.5dB typ0.08 GHz0.025 GHzActive
LM-150M5G-200CW-2KWPK-AGALBuy Now200 Watts CW (+53 dBm) Typ
2 kW Peak Power (+63 dBm) Typ
(25 µs PW, 5% Duty Cycle)
1.70:1 Max2.00 dB Max (0.15 to 0.3 GHz)
1.50 dB Max (0.3 to 5 GHz)
5 GHz0.15 GHzActive
LM-50M4G-16-1W-SFFBuy Now1 W (+30 dBm) CW Max (Usable to 4 W Max)
Peak Power 32 W Peak (+45 dBm),
Pulse 1 µs, Duty Cycle 0.1%
1.80:1 Max1.7 dB Max4.0 GHz (Usable to 11.0 GHz)0.05 GHzActive
LM-18G40G-18-1W-292FF *Buy Now1 Watt CW Max2.1:14.0 dB Max40 GHz18 GHzActive
LM-2G4G-15-100W-SFFBuy Now4 W CW Min @ 85°C.
1000 W Peak Min @ 85°C
(1 µs Pulse Width, 0.1% Duty Cycle)
2:1 Max1.5 dB Max4.0 GHz2.0 GHzActive
LM-161605-10W1-HPRBuy Now160W peak, 40W Average17dB typ1.5 dB Max16.5 GHz16 GHzActive
LM-6D7G7D9G-30W-SFFBuy Now30 Watts CW Max - See Graph1.5:1 max1.1 dB Max7.9 GHz6.7 GHzActive
LM-2G18G-18-20W-1KWP-SFFBuy Now+43 dBm CW Max2.01 Max (@ -10 dBm Input Power)2.6 dB Max (@ -10 dBm Input Power)18.0 GHz2.0 GHzActive
LM-10M50G-18DBM-4W-24FFBuy Now20 Watts Max
(Pw 1 µs, 1% Duty Cycle) Tested up to 18 GHz
(Pw 10 µs, 1% Duty Cycle) Tested up to 8 GHz
16 Watts Max at 18 GHz ( Pw 10 µs, 1% Duty Cycle)
2.0:1 Max0.01 to 18 GHz: 1.50 dB Max
18 to 40 GHz: 2.20 dB Max
40 to 50 GHz: 3.40 dB Max
50 GHz0.01 GHzActive
LM-2G8G-13-5W-SFF *Buy Now5 Watts CW Max2.0:1 max1 dB Typ8 GHz2 GHzActive
LM-10M35G-15DBM-4W-292FFBuy Now25 to 4 Watts CW2.0:11.3 - 4.0 dB35.0 GHz0.01 GHzActive
LM-0518-10-1W-SHS-2-M-1218 *Buy Now100 W (Peak)2.0:1 Max2.0 dB Max, 1.5 dB Typ18 GHz12 GHzActive
LM-10M40G-15DBM-4W-AGALBuy Now4 - 25 Watts2.0:11 to 3.20 dB40 GHz0.01 GHzActive

Gain & Loss Equalizers

Part NumberAvailabilitySizeVSWRMaximum Input PowerFrequency MaxFrequency MinStatus
EQL-17D6G21D6G-2DB-292MFBuy Now1.10" x 0.67" x 0.22"2.0:1 Max - Measured 1.66:10.5 Watts CW21.6 GHz17.6 GHzActive

Integrated MIC/MMIC Assemblies (IMAs)

Part NumberAvailabilityItem No.Product DescriptionStatus
EWDM-6G18G-65-70MVBuy Now51PMI Model No. EWDM-6G18G-65-70MV is a CW immune EW detector module operating over the 6.0 to 18.0 GHz frequency range. This module features an internal switch used to switch between the "Bit In" and RF In" with input blanking on both ports. In addition, two amplified RF outputs are provided a 7 dB gain channel and a 33 dB gain channel. The video output is designed to drive a 150 ft. cable, while maintaining high speed, and excellent accuracy.Active
PL-ENET-18BIT-0V5V-2X*Buy Now85PMI Model No. PL-ENET-18BIT-0V5V-2X is a Dual Microprocessor Module that can control attached devices I/O control port. It features two Ethernet ports to communicate with the controlling computer, and two 25 pin D-Sub connectors to communicate with the desired device. It features a red LED lit push button switch to toggle power on or off.Active
PEC-1D575G-1AFS-SFFBuy Now76PMI Model No. PEC-1D575G-1AFS-SFF is a multi-function, integrated module provides amplification and filtering within the GPS L1 frequency band of 1575.42MHz. Two input channels are switchable to a common output. This product is designed to handle exposure to extreme environmental conditions including airborne and launch rocket environments.Active
PMOD-IFCPL-60M-AMP-3UBuy Now45PMI Model No. PMOD-IFCPL-60M-AMP-3U is an IF Coupler Module on a 3U Open VPX card. The operating frequency is 60 MHz. A test signal and 3 RF signals are input allowing for 3 output signalsActive
PEC-20M3G-8T-SFGM-LVBuy Now11PMI has has designed and manufactured various switch matrix assemblies by using PMI standard or custom Solid-State Switches and power dividers all assembled into a single integrated module. An example of this work is described below. PMI has designed and produced the following Single Pole, Eight Throw Switch that operates over the 20MHz to 3.0Ghz Frequency Range. A complete Product Feature along with electrical and mechanical specifications can be seen by clicking on the following image. Based upon various options, both a low band and high band assembly was produced. By utilizing the same switch, but with different power dividers PMI was able to offer a a low band switch matrix covering 20MHz to 500MHz and a high band switch matrix covering 1.0GHz to 3.0GHz. Other frequency ranges and configurations are available.Active
RFFD-618-730049Buy Now79PMI Model No. RFFD-618-730049 is a 6 to 18 GHz low pass filter combined with a Schottky Biased Detector including a reverse voltage protection diode. A duplicate detector and protection diode is included for DC offset voltage compensation.Active
PL-MCU-ENET-TTL-MAH*Buy Now38PMI Model No. PL-MCU-ENET-TTL-MAH is an Ethernet Microcontroller Test Box which allows for an ethernet command to be sent up to 18 paralell TTL output bits. This controller can be used with may PMI products that required paralell digital commands, such as switches, attenuators, phase shifters and IQ Modulators.Active
PEC-18-2D35G-1R75-9-SFF-BPF-HS-LMBuy Now73PMI Model PEC-18-2D35G-1R75-9-SFF-BPF-HS-LM is an integrated module combining an input limiter, low noise amplifier, band pass filter, RF blanking switch and limiting output stage. The frequency passed is 2350 MHz with a 1dB bandwidth of 150 MHz. This model has a typical gain of 18 dB. The output power is limited to +2dBm maximum while the input can handle up to +30dBm CW.Active
PSL-13D414D2-CD-PPBuy Now28PMI Model Number PSL-13D414D2-CD-PP is a switch limiter operating in the 13.4 to 14.2 GHz frequency range. A +10 mA bias will turn the switch off while a -10 mA bias will turn the switch into the insertion loss state. The integrated limiter will handle 20 W having a 2 µs pulse width.Active

Monopulse Comparators

Part NumberAvailabilityIsolationInsertion LossPhase BalanceFrequency MaxFrequency MinStatus
PMC-33D5-6D8-SFFBuy Now23 dB min.0.8 dB Typ (If input signals at ports A, B, C and D are equal Amplitude or Power and Inphase with an output at Port AZS)
6.8 dB Max (If input signals at port A, B, C, or D and all other ports are terminated to 50 Ohms with an output at ports EL?, AZ, AQ, or AZ?)
±53.5 GHz3.0 GHzActive
PMC-24-7D5-SFFBuy Now18 dB Min0.8 dB Max (If input signals at ports A, B, C and D are equal Amplitude or Power & Inphase with an output at Port AZS)
7.5 dB Max (If input signals at port A, B, C, or D and all other ports are terminated to 50 Ohms with an output at ports EL?, AZS, AQ, or AZ?
±10°4.0 GHz2.0 GHzActive
PD-CD-001-1Buy Now20 dB Min, 30 dB Typ8.0 dB Max±7.0° Max - Measured 4°9.9 GHz9.3 GHzActive
PMC-9D5G10D1G-7D6-SFFBuy Now20 dB Min7.6 dB Max±5° Max10.1 GHz9.5 GHzActive
PMC-33D7-6D8-SFFBuy Now24 dB Min0.8 dB Max (If input signals at ports A, B, C and D are equal Amplitude or Power & Inphase with an output at Port AZS)
6.8 dB Max (If input signals at port A, B, C, or D and all other ports are terminated to 50 Ohms with an output at ports EL?, AZS, AQ, or AZ?)
±7°3.7 GHz3.0 GHzActive

Power Dividers/Combiners (Passive & Active)

Part NumberAvailabilityInsertion LossIsolationFrequency MaxFrequency MinTypeStatus
APD-4-800M2D5G-SFF-30WBuy Now<=0.7 dB20 dB Min2.5 GHz0.8 GHz4-WayActive
APD-4-122-292FFBuy Now3.0 dB Max (1.0 to 18.0 GHz)
3.5 dB Max (18.0 to 22.0 GHz)
12 dB typ. (1.0 to 2.0 GHz)
18 dB typ. (2.0 to 22.0 GHz)
22.0 GHz1.0 GHz4-WayActive
APD-8-800M2D5G-SFF-30W *Buy Now<=1.2 dB20 dB Min2.5 GHz0.8 GHz8-WayActive
APD-4-3D13D5-40W-SFFBuy Now<= 0.45dB>= 23dB3.5 GHz3.1 GHz4-WayActive
APD-8-500M2G-SFF-30WBuy Now<=1.5 dB20 dB Min2 GHz0.5 GHz8-WayActive
APD-4-2G26G-292FF-1WBuy Now2.25 dB Max15 dB Min26 GHz2 GHz4-WayActive
APD-8-10M-12VBuy Now4 dB ± 1.5 dB Max25 dB Typ0.01 GHz0.01 GHz8-WayActive
APD-3-800M2D5G-NFF-50W *Buy Now<=0.6 dB20 dB Min2.5 GHz0.8 GHz3-WayActive
APD-4-500M2G-SFF-30W *Buy Now<=1.0 dB20 dB Min2 GHz0.5 GHz4-WayActive
APD-16-0R523G-292FFBuy Now0.5 to 1 GHz - 2.0 dB Max
1 to 2 GHz - 3.0 dB Max
2 to 8 GHz - 3.0 dB Max
8 to 18 GHz - 5.0 dB Max
18 to 22 GHz - 7.0 dB Max
22 to 23 GHz - 7.5 dB Max
0.5 to 1 GHz - 10 dB Typ
1 to 2 GHz - 10 dB Typ
2 to 8 GHz - 20 dB Typ
8 to 18 GHz - 20 dB Typ
18 to 22 GHz - 15 dB Typ
22 to 23 GHz - 10 dB Typ
23.0 GHz0.5 Ghz16-WayActive
APD-2-218-M-BBBuy Now2.2 dB Max16 dB Typ18 GHz2 GHz2-WayActive
APD-8-0R523G-292FFBuy Now0.5 to 1 GHz – 2.0 dB Max
1 to 2 GHz – 2.0 dB Max
2 to 8 GHz - 2.0 dB Max
8 to 18 GHz - 3.2 dB Max
22 to 23 GHz - 7.0 dB Max
0.5 to 1 GHz – 10 dB Typ
1 to 2 GHz – 10 dB Typ
2 to 8 GHz - 20 dB Typ
8 to 18 GHz - 20 dB Typ
18 to 22 GHz - 15 dB Typ
22 to 23 GHz - 10 dB Typ
23.0 GHz0.5 GHz8-WayActive
APD-2-500M2G-SFF-30W *Buy Now<=0.5 dB20 dB Min2 GHz0.5 GHz2-WayActive
APD-2-800M2D5G-NFF-50W *Buy Now<=0.4 dB22 dB Min2.5 GHz0.8 GHz2-WayActive
APD-2-0518-YR1Buy Now1.8 dB typ16.5 dB Typ18 GHz0.5 GHz2-WayActive
RFOC-811-QRC-2-PDBuy Now0.6 dB Max18 dB Min13 GHz6 GHz2-WayActive
APD-8-100M-28VBuy Now4 dB ±1.5 dB Max25 dB Typ0.1 GHz0.1 GHz8-WayActive

Switch Filter Banks

Part NumberAvailabilityDC Current (mA)DC VoltageControl TypeSwitching SpeedInsertion LossFrequency MaxFrequency MinNo of Filter ChannelsStatus
2SFB3000-6G-CD-SFFBuy Now70 mA+5 VDC
-5 VDC
CMOS50 ms7 dB6.0 GHz0.5 GHz2Active
5SFB-DC26G-CD-SFFBuy Now150, 1005, -15TTL500 ns10 dB26.0 GHz0.1 GHz5Active
2SFB-8G26G-CD-SFF Rev CBuy Now100 mA Max+5 V ± 5%TTL/CMOS100 ns5.5 dB26.5 GHz8.0 GHz2Active
4SFB400-1000-CD-SFF-HSBuy Now250, 1505, -5TTL1 us7 dB1.07 GHz0.43 GHz4Active

Ultra-Broadband Low Noise Amplifiers

Part NumberAvailabilityOP1dBDC Current DrawDC Voltage SupplyNoise FigureGainFrequency MaxFrequency MinStatus
PEAFS3-14-10M22G-292FFBuy Now+14 dBm Typ (10 MHz to 18 GHz)
+13 dBm Typ (18 to 22 GHz)
50 mA+3.3 VDC @ 50 mA Max3.0 dB Typ (20 MHz to 0.5 GHz)
2.5 dB Typ (0.5 to 18 GHz)
3.4 dB Typ (18 to 22 GHz)
+14 dB Typ22 GHz10 MHzActive
PEC-30-0R2520R0-5R0-22-12-SFF *Buy Now22 dBm Min - Measured 24.05 dBm400 mA Typ+12 to +15 VDC @ 400 mA Typ - Measured 372 mA5.5 dB Max - Measured 5.0 dB26.5 dB20 GHz0.25 GHzActive

Broadband & Multioctave Amplifiers

Part NumberAvailabilityDC Current DrawDC Voltage SupplyOP1dBNoise FigureGainFrequency MaxFrequency MinStatus
PE2-35-1G13G-2R5-10-12-SFFBuy Now250 mA max.+12 VDC @ 250 mA max.12 dBm min. - Measured 15 dBm min.2.5 dB max.35 dB min.13 GHz1 GHzActive
PEC3-33-218-20-15-SFF-HS-EBuy Now350 mA Typ, 450 mA Max - Measured 440 mA+15 VDC+20 dBm Min - Measured +20 dBm4.0 dB Typ+33 dB Min18 GHz2 GHzActive

Half-Octave & Octave Band LNA's

Part NumberAvailabilityOP1dBDC Current DrawDC Voltage SupplyNoise FigureGain FlatnessGainFrequency MaxFrequency MinStatus
PEC-30-24G40G-4R0-24-292FFBuy Now24 dBm Min - Measured +17 dB @ 24.0 GHz +21 dB @ 32.0 GHz +18 dB @ 40.0 GHz650 mA nominal - Measured 400 mA+8 VDC6.0 dB Max - Measured 0 dB±1.5 dB Typ30 dB Typ40 GHz24 GHzActive
PEC-22-24G40G-4R0-24-292FFBuy Now24 dBm Min - Measured +21 dB @ 24.0 GHz +22 dB @ 32.0 GHz +20 dB @ 40.0 GHz500 mA Max - Measured 260 mA+8 VDC6.0 dB Max - Measured 0 dB±1.5 dB Typ22 dB Min40 GHz24 GHzActive

Limiting Amplifiers

Part NumberAvailabilityDC Current DrawDC Voltage SupplyOutput PowerNoise FigureInput VSWRInput PowerFrequency MaxFrequency MinStatus
PEC-85-0R32R5-15LM-12-SFFBuy Now485 mA Typ12 VDC+15 dBm ±2.5 dBm5.0 dB Typ - Measured 4.44 dB2.0:1 Max Output 1.78:1-65 to +10 dBm (Limiting)2.5 GHz0.3 GHzActive
PEC3-40-2G6G-15LM-SFF-HSBuy Now350 mA Max10.8 to +13.2 VDC+15 dBm Min5.5 dB Max @ +25 ºC,
6.0 dB Max @ +85C
2.0:1 Max-15 to +17 dBm6.25 GHz1.85 GHzActive
PEC2-2G18G-21DBM-LM-SFFBuy Now700 mA Max - Measured 567 mA15 VDC+21.0 dBm to +25 dBm Nom -
Measured -21.33 dBm Min, to 27.32 dBm Max
5 dB Max - Measured 4.26 dB2.0:1 Max-45 to +10 dBm CW18 GHz2 GHzActive
PEC-60-160M-40M-7-13-1515-SFFFBuy Now33 mA, 40 mA+15 VDC
-15 VDC
+13 dBm Min7 dB Max1.5:1 Max
-
180 MHz140 MHzActive

Low Cost Amplifiers

Part NumberAvailabilityDC Current DrawDC Voltage SupplyOP1dBNoise FigureGain FlatnessGainFrequency MaxFrequency MinStatus
PLN-32-68-2-LCABuy Now41 mA+12 to +15 VDC+2 dBm typ.1.0 dB typ.±1.25 dB typ.32 dB typ.8 GHz6 GHzActive
PUB-15-30M20G-20-LCA *Buy Now180 mA+12 to +15 VDC - Measured +12 VDC to +15 VDC @ 188 mA20 dBm - Measured 20 dBm3.0 dB±2.5 dB15 dB20 GHz0.03 GHzActive
PLN-25-812-10-LCABuy Now75 mA Typ - Measured 72mA+12 VDC10 dBm Typ - Measured >10dB1.8 dB Typ±1.0 dB Typ25 dB Typ12 GHz8 GHzActive

Narrow Band LNA's

Part NumberAvailabilityDC Current DrawDC VoltageOP1dBNoise FigureGain FlatnessGainFrequency MaxFrequency MinStatus
PE2-30-7R08R0-1R0-2-12-SFFBuy Now25 mA max+12 to +152 dBm min.1.0 dB typ.±0.5dB max.30 dB typ.8 GHz7 GHzActive
PA-25002700-35-CD-SFFBuy Now2500 mA typ., 3000 mA max.+11.5 V to 13.0 V+35 dBm min., +36 dBm typ.5.0 dB typ., 8.0 dB max.±0.5 dB typ., ±0.75 dB max31.5 dB min., 34.5 dB max.2.700 GHz2.500 GHzActive
PEC-15-400M470M-37-12V-SFFBuy Now1600 mA Typ, 1900 mA Max+11.5 V Min, +12 V Typ, +13 V Max+37 dBm Min, +38 dBm Typ
-
±0.75 dB Typ, ±1.0 dB Max10 dB Min, 15 dB Typ0.47 GHz0.4 GHzActive
APT3-03100350-0807-D5SBuy Now150 mA nominal+15 VDC+7.6 dBm min.0.8 dB max.±0.2 dB (Over any 40 MHz Segment)28 ± 0.6 dB3.5 GHz3.1 GHzActive

PMI's A Series Amplifiers

Part NumberAvailabilityP1dB OutGainFrequency MaxFrequency MinStatus
A-2R7G3R1G-30G-R5N-13P-PN-LBuy Now+13 dBm min.29±1 dB (Temp. +10 to +50°C)3.1 GHz2.7 GHzPreliminary

Test Bench & Lab Use Amplifiers

Part NumberAvailabilityDC Voltage SupplyAC Voltage SupplyOP1dBNoise FigureGain FlatnessGainFrequency MaxFrequency MinStatus
PTB-60-2040-5R0-10-100VAC-292FF *Buy NowN/A90 to 100 VAC+10 dBm Min - Measured 11.1 dBm5.0 dB Typ - Measured 5.2 dB±3.0 dB Max+60 dB Typ40 GHz20 GHzActive
PTB-42-1G40G-12-292FF-DC12-100VAC *Buy Now+12 VDC90 to 100 VAC+22 dBm Typ (1.0 to 18.0 GHz),
+18 dBm Typ (18.0 to 40.0 GHz)
5.0 dB Typ, Mid-Band - Measured 4.64 dB±2.5 dB Max+40 dB Typ40 GHz1 GHzActive
PTB-42-1G40G-12-292FF-DC12-220VAC *Buy Now+12 VDC220 to 230 VAC+22 dBm Typ (1.0 to 18.0 GHz), +18 dBm Typ (18.0 to 40.0 GHz)5.0 dB Typ, Mid-Band - Measured 4.64 dB±2.5 dB Max+40 dB Typ40 GHz1 GHzActive
PTB-30-2040-5R0-10-100VAC-292FF *Buy NowN/A90 to 100 VAC+10 dBm Min - Measured 11.4 dBm5.0 dB Typ - Measured 5.6 dB±2.0 dB Max+30 dB Typ40 GHz20 GHzActive
PTB-42-1G40G-12-292FF-DC12 *Buy Now+12 VDC - Measured +12 VDC120 VAC - Measured 120 VAC+22 dBm Typ (1-18 GHz) - Measured +21.5 dBm Max, +19.5 dBm Min.
+18 dBm Typ (18-40 GHz) - Measured +21 dBm Max, +16 dBm Min
5.0 dB Typ mid-band - Measured 4.64 dB±2.5 dB Typ40 dB Typ40 GHz1 GHzActive
PTB-30-2040-5R0-10-220VAC-292FF *Buy NowN/A220 to 230 VAC+10 dBm Min5.0 dB Typ±2.0 dB Max+30 dB Typ40 GHz20 GHzActive
PTB-60-120-5R0-10-115-VAC-SFF Rev. B *Buy NowN/A115 VAC, 60 Hz, (Supplied with fuse and 6 foot power cord)+10 dBm Min - Measured +10.3 dBm5.0 dB Max - Measured 3.8 dB±3.0 dB Typ60 dB Typ20 GHz1 GHzActive
PTB-60-120-5R0-10-220VAC-SFF *Buy NowN/A220 to 230 VAC+10 dBm min. - Measured +13 dBm5.0 dB typ. - Measured 4.7 dB±3.0 dB max+60 dB typ20 GHz1 GHzActive
PTB-60-120-5R0-10-100VAC-SFF *Buy NowN/A90 to 100 VAC+10 dBm Min - Measured +10.7 dB5.0 dB Typ - Measured 4.6 dB±3.0 dB Max+60 dB Typ20 GHz1 GHzActive
PTB-60-2040-5R0-10-220VAC-292FF *Buy NowN/A220 to 230 VAC+10 dBm Min - Measured 11.0 dBm5.0 dB Typ - Measured 5.4 dB±3.0 dB Max+60 dB Typ40 GHz20 GHzActive
PTB-30-2040-5R0-10-115VAC-292FF *Buy NowN/A115 VAC, 60 Hz, * Supplied with fuse and 6 foot power cord+10 dB Min - Measured 10.8 dBm5.0 dB Typ - Measured 6.14 dB±2.0 dB Max+30 dB Typ40 GHz20 GHzActive

Digitally Controlled Attenuators

Part NumberAvailabilityDigital ControlAttenuation RangeInsertion LossFrequency MaxFrequency MinStatus
DTA-18G40G-30-CD-2 *Buy Now10 Bit30 dB6.0 dB Typ40 GHz18 GHzActive
DTA-0R5G18G-60-CD-1 *Buy Now10 Bit60 dB4.8 dB Max18 GHz0.5 GHzActive
DTA-30M6G-60-CD-1 *Buy Now8-BIT Binary TTL60 dB4.0 dB Max6 GHz0.03 GHzActive
PDVAT-0518-60-8-93-10M18Buy Now8 Bit TTL 0.25dB Minimum Attenuation Step
-
5.25 dB max18 GHz0.01 GHzActive
DTA-100M40G-30-CD-1 *Buy Now5 Bit30 dB5.0 dB Typ40 GHz0.1 GHzActive
PEC-7R720R3-15-SFF-SABuy Now
-
-
4.0 dB max20.3 GHz7.7 GHzActive
PSAT-2500-11B-CD-1Buy Now11 Bit60 dB Min10 dB Max2.61 GHz2.39 GHzActive
PAT-3D1G3D5G-CD-SFFBuy Now
-
30 dB ±1.0 dB1.1 dB max.3.5 GHz3.1 GHzActive
DTA-22G28G-50-CD-1Buy Now11 Bit1 to 51.175 dB2.2 dB Max27.5 GHz22.5 GHzActive
DTA-100M18G-30-CD-1 *Buy Now5 Bit30 dB5.0 dB typ18 GHz0.1 GHzActive

Analog Controlled Attenuators

Part NumberAvailabilityControl TypeAttenuationInsertion LossFrequency MaxFrequency MinStatus
PVVAN-4080-60-MP *Buy NowVoltage60 dB2.5 dB8 GHz4 GHzActive
PVA-500M18G-60-SFF *Buy NowVoltage60 dB4.5 dB18 GHz0.5 GHzActive
PVVAN-8018-60-MP *Buy NowVoltage60 dB3.7 dB18 GHz8 GHzActive
PVVAN-6012-60-MP *Buy NowVoltage60 dB2.8 dB12 GHz6 GHzActive
PVVAN-2040-60-MP *Buy NowVoltage60 dB2.0 dB4 GHz2 GHzActive
PVVAN-0R4G6G-40-MP-1 *Buy NowVoltage40 dB2.8 dB6 GHz0.4 GHzActive

Connectorized DLVA's and ERDLVA's

Part NumberAvailabilityLog RangeLog SlopeSizeTSSFrequency MaxFrequency MinStatus
SDLVA-218-71-70MVBuy Now-66 to +5 dBm70mV/dB3.5 " x 2.5 " x 0.5"-72dBm18 GHz2 GHzActive
DLVA-6G18G-50 *Buy Now-70 to 0 dBm25 mV/dB (±10%) - Measured 25 mV/dB3.2 " x 2.05 " x 0.4"-72 dB Min18 GHz6 GHzActive
PLVA-218-50-618 *Buy Now-40 dBm to +0 dBm (Useful Range up to +5 dBm)50 mV/dB - Measured 50.6 mV/dB2.20" x 1.50" x 0.40"-40 dBm Min18 GHz6 GHzActive
PLVA-218-50-9G10GBuy Now-40dBm to +0dBm (Useful Range up to +5dBm)50mV/dB2.20" x 1.50" x 0.40"-42dBm min.10 GHz9 GHzActive
EWDM-6G18G-65-70MVBuy Now-65 to 0 dBm70 mV/dB nominal4.2” x 2.9” x 0.8”-71 dBm Max18 GHz6 GHzActive
CVR-FXF6-50-CWBuy Now
-
-
-
-
-
-
Active
DLVA-Y7Y13R5-50-60MVBuy Now
-
-
-
-
-
-
Active
DLVA-6D5G18G-70-JMAKG2Buy Now-70 to 0 dBm25 mV/dB (±10%) @ 50 Ohm Load3.2 " x 2.05 " x 0.4"-72 dB min.18 GHz6.5 GHzActive

Surface Mount SDLVA's

Part NumberAvailabilityVideo LoadLogging RangeFrequency MaxFrequency MinStatus
SLVAC-06135-MA08Buy Now100 Ohms-65 to +5 dBm1.35 GHz0.6 GHzActive

Connectorized SDLVA's

Part NumberAvailabilityDynamic RangeTSSLog SlopeSizeVSWRFrequency MaxFrequency MinStatus
SDLVA-2020-70-0518 *Buy Now-65 to +5 dBm-65 dBm Minimum (8 to 18 GHz)20 mV/dB (±10% Tolerance)3.00" x 3.5" x 0.5"3.0:118 GHz0.5 GHzActive
SDLVA-418-65-16MV-12DBMBuy Now-55 to +10 dBm-64 dBm Max16.7 ± 1.3 mV/dB4.24" x 0.994" x 0.38"2.0:1 Max18 GHz4 GHzActive
SDLVA-100M3G-70-MAHBuy Now-65 to +5 dBm min.-68 dBm Min, -70 dBm Typ10mV/dB into a 50 ohm Load (±1mV) Max2.30" x 2.20" x 0.36"2.0:1 Max3 GHz0.1 GHzActive
SDLVA-315M362M-65-CD-1Buy Now-65 to 0 dBm-73 dBm Min (Video In) - Measured -80 dBm50 mV/dB (±1.5 mV/dB) 100 Ohm Load3.75" x 1.5" x 0.5"1.5:1 Max0.362 GHz0.315 GHzActive
SDLVA-8G18G-70dB-100RBuy Now-70 to 0 dBm-73 dB typ., -71 dB max.25 mV/ dB typ. 100 Ohm Load - Measured 25.1 mV/dB3.2" x 1.8" x 0.42.0:1 max18 GHz8 GHzActive
SDLVA-2G6G-70-CD-1 *Buy Now-65 dBm to 5 dBm
-
40 mV/dB Nominal3.75" x 1.50" x 0.50"
-
6 GHz2 GHzActive
SDLVA-500M4G-CD-1 *Buy Now-70 to 0 dBm-73 dB Typ., -71 dB Max - Measured -73 dBm25 mV/dB Typ 50 Ohm Load - Measured 24.7 mV/dB3.2" x 1.8" x 0.42.0:14 GHz0.5 GHzActive
SDLVA-2D5G4D9G-60-50MVBuy Now-60 to 0 dBm-70 dBm min.50.5 ± 5% mV/dB - Measured 49.8 - 51.5 mV/dB1.0" x 2.3" x 0.4"2.0:14.9 GHz2.5 GHzActive
SDLVA-0R71R3-75-CD-1Buy Now>75 dB-70 dBm Typ40 mV/dB Nom3.75" x 1.50" x 0.50"1.8:1 Max1.3 GHz0.7 GHzActive

Bandpass Cavity Filters

Part NumberAvailabilityBandwidthInsertion LossCenter FrequencyStatus
BPF3D875-2D25-CD-SFFBuy Now2250 MHz2.0 dB max. - Measured 1.6 dB3875 MHzActive
7CL1R3-100-CD-SFMBuy Now100 MHz @ 1dB1.0 dB P-P max.1300 MHzActive
7CL1340-155-CD-NFFBuy Now155 MHz0.5 dB max.1340 MHzActive
7CL7D86G-960-CD-SFFBuy Now960 MHz5 dB7860 MHzActive
7CL9D66G-960-CD-SFFBuy Now960 MHz min.5 dB max. - Measured 0.63 dB9660 MHzActive
6CL9227D5M-180-CD-SFFBuy Now180 MHz typ - Measured 182.97 MHz1.0 dB typ - Measured 1.91 dB9227.5 MHz - Measured 9227.8 MHzActive
7CL8250-500-CD-SSBuy Now500 MHz0.8 dB8250 MHzPreliminary

Band Reject Notch Filters

Part NumberAvailabilityPassband Insertion LossNotch BandwidthCenter Frequency, FoStatus
5BR5R65G-2R5G-CD-SFFBuy Now1.0dB500MHz5650MHzActive

Dielectric Resonator Oscillators

Part NumberAvailabilityHarmonics & Sub-HarmonicsSpuriousOutput PowerOutput Frequency (fo)Status
DRO-9D7G-CD-1Buy Now-20dBc min-55dBc min+16dBm max, +11dBm min9.7 GHzActive

Digitally Tuned Oscillator

Part NumberAvailabilityFrequency DriftFrequency AccuracyFrequency MaxFrequency MinFrequency RangeStatus
DTO-6G18G-CD-1Buy Now±0.1 MHz/ºC Max. - Measured ±0.1 MHz/ºC±5 MHz Max. @ +25ºC - Measured ±4.80 MHz18 GHz6 GHz6.0 to 18.0 GHzActive
DTO-6G19G-CD-1Buy Now±0.1 MHz/C Max. - Measured ±0.1 MHz±0.1% Max. @ +25C - Measured ±0.09%19 GHz6 GHz6.0 to 19.0 GHzActive

Frequency Synthesizer

Part NumberAvailabilityPower Output LevelFrequency Step Size, Nominal (LSB)Frequency MaxFrequency MinFrequency RangeStatus
PFS-618-CD-1Buy Now+10 dBm Min - Measured 12.91 ± 1.41 dBm100 kHz18 GHz6 GHz6.0 to 18.0 GHzActive

PLDRO's

Part NumberAvailabilityLoad VSWRFrequency StabilityOutput Frequency (fo)Status
PIA-25-CD-1-EXTBuy Now1.4:1 Typ.±3 ppm25.0 GHzActive

I/Q Vector Modulators

Part NumberAvailabilitySizePhase Shift RangeInsertion LossFrequency MaxFrequency MinStatus
PIQ-2G18G-360-16-CD-1Buy Now4.25" x 3.5" x 1.0"360°17.0 dB Typ, 18.0 dB Max - Measured 14.74 dB18 GHz2 GHzActive

Single Sideband Modulators

Part NumberAvailabilityRF Frequency RangeSizeIF Modulation Frequency RangeConversion lossFrequency MaxFrequency MinStatus
PSM-50M1G-CD-1Buy Now50 MHz to 1.0 GHz6.0"L x 3.5"W x 1.0"HDC to 10 MHz10 dBm Max (See Note 1)1.0 GHz0.05 GHzActive
PSM-0R5G2R5G-CD-1Buy Now500 MHz to 2.5 GHz2.5"L x 2.0"W x 0.5"HDC to 500 MHz13.5 dBm Max (See Note 1)2.5 GHz0.5 GHzActive

Digital Phase Shifters

Part NumberAvailabilityPhase Shift RangeInsertion LossControl BitsFrequency MaxFrequency MinStatus
PS-360-8D5G11G-8-SFF-LVT-15D *Buy Now360°10 dB Typi8-Bit TTL11 GHz8.5 GHzActive
PS-200M10G-8B-SFFBuy Now360° Typ10.5 dB Typ8-Bit TTL10 GHz0.2 GHzActive
PS-360-3237-5-292FFBuy Now348.75°8.0dB Max5-Bit TTL37 GHz32 GHzActive
PS-2D2G-360-CD-1Buy Now360°13dB Typ9-Bit TTL2.2 GHz2.17 GHzActive
PS-360-3237-8-292FF *Buy Now358.59°13.0 dB Typ8-Bit TTL37 GHz32 GHzActive
PS-360-DC-3 OPTION 618-15D *Buy Now360° typ12.0 dB Max8-Bit TTL18 GHz6 GHzActive
PS-500M2G-8B-SFF *Buy Now360° - Measured 358.6°13 dB Max8-Bit TTL2 GHz0.5 GHzActive
PS-360-2433D5-6-SFF-1Buy Now360°5dB Typ6-Bit TTL2.433 GHz2.433 GHzActive
PS-360-DC-3 OPTION 618-15D-10BITBuy Now360° Typ12.0 dB max10-Bit TTL18 GHz6 GHzActive

Analog Phase Shifters

Part NumberAvailabilityControl VoltagePhase Shift RangeFrequency MaxFrequency MinFrequency RangeStatus
PS-5G18G-400-A-SFF *Buy Now0 to +10 VDC400°18 GHz5 GHz5 - 18 GHzActive

Bi-Phase Modulators

Part NumberAvailabilityControl TypeVSWRInsertion LossPhase StatesFrequency MaxFrequency MinStatus
PS-90-4080 *Buy NowTTL2.0:1 Typ2.5 dB typ, 3.0 dB max0° / 180°8.0 GHz4.0 GHzActive
BPM-26D5G40G-180-292FF *Buy NowTTL2.0:1 Max, 1.5:1 goal5.5 dB Typ0° / 180º40.0 GHz26.5 GHzActive
PS-90-1020 *Buy NowTTL2.0:13.0 dB Typ, 6.0 dB Max0° / 180°2 GHz1 GHzActive
PS-90-2040 *Buy NowTTL2.0:12.5 dB typ, 3.0 dB max0° / 180°4 GHz2 GHzActive
PS-90-0510 *Buy NowTTL2.0:12.5 dB Typ, 3.0 dB Max0° / 180°1 GHz0.5 GHzActive
BPM-1840-180-292FFBuy NowTTL2.0:1 goal, 3.0:1 Max8 dB Typ0° / 180º40.0 GHz18.0 GHzActive
BPM-2G18G-180-SFF-MB *Buy NowTTL1.50:1 Max5.5 dB Max0° / 180º18.0 GHz2.0 GHzActive
PS-90-6012-HS15NS *Buy NowTTL2.0:1 Typ, 2.5:1 Max2.5 dB Typ, 3.0 dB Max0° / 180°12 GHz6 GHzActive
BPM-1G2G-1-SFFBuy NowTTL2.0:18.8 dB Max.0° / 180°2 GHz1 GHzActive
BPM-2G6G-1 *Buy NowTTL1.8:1 Max2.5 dB Max0° / 180º6 GHz2 GHzActive
PS-90-8018 *Buy NowTTL2.0:13.0 dB typ., 3.5 dB max.0° / 180°18 GHz8 GHzActive

Single Pole - Single Throw (SPST)

Part NumberAvailabilityInput PowerInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinStatus
P1T-4G8G-75-R-SFF *Buy Now+30 dBm Max (Survival), +20 dBm Max (Operating)1.5 dB typ - Measured 1.302 dB75 dB min - Measured 94 dBAbsorptive8 GHz4 GHzActive
P1T-DC40G-65-T-292FF-1NS-OPT18G-50OHMBuy Now+17 dBm CW max4.5 dB Typ - Measured 3.75 dB, 5.0 dB Max60 dB Typ - Measured 62.21 dB 55 dB MinAbsorptive18 GHzDCActive
P1T-0R5G18G-55-R-SFF-PN *Buy Now+20 dBm CW max3.0 dB typ - Measured 2.56 dB55 dB min - Measured 62.43 dBReflective18 GHz0.5 GHzActive
P1T-1G18G-65-T-SFF *Buy Now+30 dBm Max (Survival),
+20 dBm Max (Operating)
3 dB Max - Measured 2.88 dB65 dB Min - Measured 81.0 dBAbsorptive18 GHz1 GHzActive
P1T-10M1G-80-R-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)1.0 dB typ. - Measured 0.64 dB80 dB typ. - Measured 81.74 dBReflective1 GHz0.01 GHzActive
P1T-1G2G-85-T-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)0.9 dB typ. - Measured 0.58 dB80 dB min - Measured 88.79 dBAbsorptive2 GHz1 GHzActive
P1T-500M40G-55-T-292FF *Buy Now+20dBm CW max5.5 dB max. - Measured 5.13 dB74 dB typ, 55 dB min. - Measured 74.96 dBAbsorptive40 GHz0.5 GHzActive
P1T-4G8G-75-T-SFF *Buy Now+30 dBm Max (Survival), +20 dBm Max (Operating)1.8 dB Max75 dB MinAbsorptive8 GHz4 GHzActive
P1T-1G2G-85-R-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)0.75 dB typ. - measured 0.26 dB80 dB min - measured 81 dBReflective2 GHz1 GHzActive
P1T-8G12G-70-R-SFF *Buy Now+30 dBm Max (Survival), +20 dBm Max (Operating)1.8 dB Typ - Measured 1.13 dB70 dB Min - Measured 82.44 dBReflective12 GHz8 GHzActive
P1T-500M40G-55-R-292FF *Buy Now+20 dBm CW Max5.0 dB Typ - Measured 4.01 dB55 dB Min - Measured 55.54 dBReflective40 GHz0.5 GHzActive
P1T-12G18G-65-R-SFF *Buy Now+30 dBm Max (Survival), +20 dBm Max (Operating)2.5 dB Typ - Measured 2.32 dB65 dB Min - Measured 73.23 dBReflective18 GHz12 GHzActive
P1T-1G18G-65-R-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)2.5 dB typ - Measured 2.04 dB65 dB min - Measured 70.95 dBReflective18 GHz1 GHzActive
P1T-8G12G-70-T-SFF *Buy Now+30 dBm Max (Survival), +20 dBm Max (Operating)2.2 dB Max - Measured 1.9 dB70 dB Min - Measured 91 dBAbsorptive12 GHz8 GHzActive
P1T-0R5G18G-55-T-SFF-PN *Buy Now+20dBm CW max3.5 dB max - Measured 2.45 dB55 dB min - Measured 73.56 dBAbsorptive18 GHz0.5 GHzActive
P1T-2G4G-75-T-SFF *Buy Now+30 dBm Max (Survival),
+20 dBm Max (Operating)
1.1 dB Max - Measured 0.9 dB75 dB Min - Measured 95 dBAbsorptive4 GHz2 GHzActive
P1T-2G4G-75-R-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)0.85 dB typ. - Measured 0.59 dB75 dB min - Measured 88.91 dBReflective4 GHz2 GHzActive
P1T-12G18G-65-T-SFF *Buy Now+30 dBm Max (Survival),
+20 dBm Max (Operating)
2.8 dB Max - Measured 2.6 dB65 dB Min - Measured 88 dBAbsorptive18 GHz12 GHzActive
P1T-10M1G-80-T-SFF *Buy Now+30 dBm max (Survival), +20 dBm max (Operating)1.3 dB max - Measured 0.65 dB80 dB typ. - Measured 86.02 dBAbsorptive1 GHz0.01 GHzActive

Single Pole - Two Throw (SP2T)

Part NumberAvailabilitySwitching SpeedInput PowerInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinStatus
PEC-2D35G-20W-SFF-SPDTBuy Now100 ns goal, 350 ns max.20 W max. (Hot switching without damage2.5 dB typ., 3.0 dB max.40 dB min.Reflective2.5 GHz2.2 GHzActive
P2T-100M44-50-T-292FF-PHBuy NowRise and Fall Time: 10 ns Max
0% to 90% of RF Output)
On and Off Time: 20 ns Max
(50% Vctl to 90% of RF Output)
RF Settling Time: 60 ns Typ
(50% Vctl to 0.1 dB of Final RF Output),
70 ns Typ (50% Vctl to 0.05 dB of Final RF Output)
27 dBm @ +85 °C
24 dBm Hot Switching
2.5 dB Max (0.1 to 18.0 GHz)
3.8 dB Max (18.0 to 35.0 GHz)
6.0 dB Max (35.0 to 44.0 GHz)
54 dB Typ (0.1 to 18.0 GHz)
50 dB Typ (18.0 to 35.0 GHz)
46 dB Typ (35.0 to 44.0 GHz)
Absorptive44.0 GHz0.1 GHzActive
PEC-2D35G-100W-SFF-SPDTBuy Now100 ns goal, 350 ns Max. - Measured 150 ns100 W Max. (Hot Switching without damage)2.5 dB Typ., 3.0 dB Max. - Measured 2.06 dB40 dB Min. - Measured 63 dBReflective2.5 GHz2.2 GHzActive
P2T-2G4G-75-T-SFF-PN *Buy Now100 ns Max - Measured 73 ns1 Watt CW Max1.2 dB - Measured 1.15 dB75 dBm Min - Measured 87.15 dBAbsorptive4 GHz2 GHzActive
P2T-12G18G-70-R-SFF *Buy Now100 ns max - measured 25 ns+30 dBm max (Survival), +20 dBm max (Operating)2.5 dB typ - measured 2.2 dB70 dB min - measured 72 dBReflective18 GHz12 GHzActive
P2T-0R5G8G-45-R-SFF-50W-SMBuy Now1 µs Max, 100 ns Typ - Measured 69 ns50 Watts0.90 dB Typ @ 0.5 to 1.0 GHz,
Measured 0.91 dB Max (J1-J2), 0.86 dB Max (J1-J3),
2.65 dB Typ @ 6.0 to 8.0 GHz
Measured 2.65 Max (J1-J2), 2.48 dB Max (J1-J3)
49 dB Typ @ 0.5 to 1.0 GHz,
Measured 49.42 dB Min (J1-J2), 48.58 dB Min (J1-J3),
33 dB Typ @ 6.0 to 8.0 GHz
Measured 33.88 dB Min (J1-J2), 33.42 dB Min (J1-J3)
Reflective8.0 GHz0.5 GHzActive
P2T-10M1G-80-R-SFF *Buy Now200 ns max. - Measured 125 ns+30dBm max (Survival), +20dBm max (Operating)1.1 dB typ. - Measured 0.71 dB1.5:1 typ. - Measured 1.2:1Reflective1 GHz0.01 GHzActive
P2T-500M40G-60-R-55-292FF *Buy NowRise: 15 ns max - Measured 3 ns, Fall: 15 ns max - Measured 3 ns, Delay On: 50 ns max - Measured 25 ns, Delay Off: 50 ns mas - Measured 25 ns+20 dBm CW max.5.5 dB typ. - Measured 4.22 dB55 dB min. - Measured 55.43 dBReflective40 GHz0.5 GHzActive
P2T-6G18G-40-R-570-TFF-1D6KWBuy Now1.25 µs Max, 1.1 µs Typ (50% TTL to 90% RF & 50% TTL to 10% RF) - Measured 1.11 us125.89 Watts2.2 dB Max @ band edges for 20% bandwidth and typically 1.75 dB goal. For mid-band of 80% of the bandwidth 2.0 dB Max, and typically 1.5 dB goal. - Measured 2.13 dB40 dB - Measured 41.01 dBReflective18 GHz6 GHzActive
P2T-500M20G-50-T-5-12-SFF-I-SPBuy Now50 ns max - Measured 37 ns typ+23 dBm CW max2.8 dB max - Measured 2.52 dB50 dB min - Measured 53.88 dBAbsorptive20.0 GHz0.5 GHZActive
P2T-8G11G-90-T-SFFBuy Now50 ns max. - Measured 15 to 20 ns+20dBm CW (Operating)2.5 dB typ., 3.5 dB max. - Measured 2.1 dB90 dB min. - Measured 104 dBAbsorptive11 GHz8 GHzActive
P2T-0R5G18G-55-R-SFF-PN *Buy Now100 ns max - Measured 72.6 ns+20 dBm CW max55 dB min - Measured 78.02 dB3.25 dB typ - Measured 1.85 dBReflective18 GHz0.5 GHzActive
P2T-8G12G-70-T-SFF *Buy Now100 nsec max - Measured 49.6 ns+30 dBm max (Survival), +20 dBm max (Operating)2.2 dB max - Measured 1.78 dB70 dBm min - Measured 91.9 dBAbsorptive12 GHz8 GHzActive
P2T-8G18G-45-R-SFF-HIP20WBuy NowRise Time: 75 ns typ.
Fall Time: 25 ns typ.
Delay On: 150 ns typ.
Delay Off: 100 ns typ.
Hot Switching: 10 W CW max.
20W CW Max, PRF 0.001 GHz Max , 10W CW Max (Hot Switching)2.5 dB max., 2.0 dB typ. - Measured 1.95 dB45 dB min. - Measured 46.03 dBReflective18 GHz8 GHzActive
P2T-12G18G-70-T-SFF *Buy Now100 ns max - Measured 49.6 ns+30 dBm max (Survival), +20 dBm max (Operating)3.5 dB max - Measured 3.07 dB70 dB min - Measured 79.8 dBAbsorptive18 GHz12 GHzActive
P2T-8G12G-70-R-SFF *Buy Now100 ns max - Measured 75 ns+30 dBm max (Survival), +20 dBm max (Operating)1.9 dB typ - Measured 1.66 dB70 dBm min - Measured 77.74 dBReflective12 GHz8 GHzActive
P2T-2G18G-60-T-SFF-PM-IBuy Now100 ns Max+30 dBm Max (Survival),
+20 dBm Max (Operating)
3.0 dB Max60 dB MinAbsorptive18.0 GHz2.0 GHzActive
P2T-10M1G-80-T-SFF *Buy Now200 ns max - Measured 180 ns+30 dBm max (Survival), +20 dBm max (Operating)1.3 dB max - Measured 1.19 dB80 dB typ - Measured 81.10 dBAbsorptive1 GHz0.01 GHzActive
P2T-1G18G-65-T-SFF *Buy Now100 ns Max - Measured 49.6 ns+30 dBm Max (Survival), +20 dBm Max (Operating)3.5 dB Max - Measured 3.14 dB65 dB Typ - Measured 80.8 dBAbsorptive18 GHz1 GHzActive
P2T-0R5G18G-55-T-SFF-PNBuy Now100 ns max. - Measured ‹30 ns+20dBm CW max3.75 dB max. - Measured 2.61 dB55 dB min. - Measured 93.22 dBAbsorptive18 GHz0.5 GHzActive
P2T-500M40G-60-T-55-292FF *Buy Now50 nsec max. - Measured 40 ns+20 dBm CW max. - Measured +20 dBm CW6.0 dB max. - Measured 5.19 dB55 dB min. - Measured 70.87 dBAbsorptive40 GHz0.5 GHzActive
P2T-9K30G-60-R-SFFBuy Now1 us typ.+24 dBm Max (+18dBm Hot Switching Max)1.1 dB Typ (9 kHz - 10 GHz) Measured 1.73 dB 1.4 dB Typ (10 GHz - 20 GHz) Measured 2.49 dB 2.0 dB Typ (20 GHz - 30 GHz) Measured 3.18 dB65 dB Typ (9 kHz - 10 GHz) Measured 57.19 dB 60 dB Typ (10 GHz - 20 GHz) Measured 50.44 dB 60 dB Typ (20 GHz - 30 GHz) Measured 48.75 dBAbsorptive30.0 GHz9.0 kHzActive
P2T-1G1R1G-25-R-SFF-100WBuy Now250 ns Typ - Measured 176 ns (50% TTL to 10% / 90% RF)100 Watts - Measured at 125.89 W CW0.8 dB Max - Measured 0.49 dB25 dB Min - Measured 40.09 dBReflective1.1 GHz1 GHzActive
P2T-1G18G-65-R-SFF *Buy Now100 ns max - Measured 31.6 dB+30 dBm max (Survival), +20 dBm max (Operating)2.5 dB typ - Measured 2.42 dB65 dB typ - Measured 74.15 dBReflective18 GHz1 GHzActive
P2T-4G8G-70-T-SFF *Buy Now100 ns Max - Measured 49.6 ns+30 dBm Max (Survival), +20 dBm Max (Operating)1.9 dB Max - Measured 1.78 dB70 dBm Min - Measured 119 dBAbsorptive8 GHz4 GHzActive
P2T-4G8G-70-R-SFF *Buy Now100 ns max - Measured 29 ns+30 dBm Max (Survival), +20 dBm Max (Operating)1.6 dB Typ - Measured 1.4 dB70 dBm Min - Measured 119 dBReflective8 GHz4 GHzActive
P2T-2G4G-75-R-SFF-PN *Buy Now100 ns max - Measured 72.6 ns+30 dBm max (Operating)0.9 dB typ - Measured 0.88 dB75 dB min - Measured 85.4 dBReflective4 GHz2 GHzActive

Single Pole - Three Throw (SP3T)

Part NumberAvailabilitySwitching SpeedInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinFrequencyStatus
P3T-0R5G18G-55-T-SFF-PN-OPT218Buy Now100 ns Max3.8 dB Max55 dB MinAbsorptive18 GHz2 GHz2.0 to 18.0 GHzActive
P3T-2G18G-70-T-SFFBuy Now150 ns3 dB Max70 dB MinAbsorptive18 GHz2 GHz2.0 to 18.0 GHzActive
P3T-8G12G-70-T-SFF *Buy Now100 ns Max - Measured 23 ns2.8 dB Max - Measured 1.9 dB70 dB Min - Measured 90 dBAbsorptive12 GHz8 GHz8.0 to 12.0 GHzActive
P3T-10M1G-60-T-SFF *Buy Now200 ns max - Measured 60 ns1.4 dB max - Measured 1.34 dB60 dB min - Measured 62.92 dBAbsorptive1 GHz0.01 GHz0.010 to 1.0 GHzActive
P3T-12G18G-70-T-SFF *Buy Now100 ns Max - Measured 49.6 ns3.75 dB Max - Measured 3.0 dB70 dB Min - Measured 73.22 dBAbsorptive18 GHz12 GHz12.0 to 18.0 GHzActive
P3T-1G2G-60-T-SFF *Buy Now100 ns max - measured 21 ns1.25 dB max - measured 0.76 dB60 dB min - measured 87 dBAbsorptive2 GHz1 GHz1.0 to 2.0 GHzActive
P3T-8G12G-70-R-SFF *Buy Now100 ns max - Measured 29.4 ns2.4 dB typ - Measured 1.63 dB70 dB min - Measured 76.83 dBReflective12 GHz8 GHz8.0 to 12.0 GHzActive
P3T-2G4G-75-R-SFF *Buy Now100 ns max - Measured 49.6 ns1.2 dB typ - Measured 1.19 dB75 dB typ - Measured 89.4 dBReflective4 GHz2 GHz2.0 to 4.0 GHzActive
P3T-1G2G-60-R-SFF *Buy Now100 ns max - Measured 49.6 ns1.0 dB typ - Measured 0.49 dB60 dB min - Measured 80 dBReflective2 GHz1 GHz1.0 to 2.0 GHzActive
P3T-10M1G-60-R-SFF *Buy Now200 ns max - Measured 49.6 ns1.0 dB typ - Measured 0.49 dB60 dB min - Measured 80.0 dBReflective1 GHz0.01 GHz0.010 to 1.0 GHzActive
P3T-500M40G-60-R-55-292FF *Buy NowRise: 15 ns typ, Fall: 15 ns typ, Delay On: 50 ns typ - Measured 43 ns, Delay Off: 50 ns typ5.5 dB typ - Measured 3.64 dB55 dB min - Measured 57.3 dBAbsorptive40 GHz0.5 GHz0.5 to 40.0 GHzActive
P3T-1G18G-65-R-SFF *Buy Now100 ns max - Measured 27.5 ns2.75 dB typ - Measured 2.39 dB65 dB typ - Measured 73.66 dBReflective18 GHz1 GHz1.0 to 18.0 GHzActive
P3T-1G18G-65-T-SFF *Buy Now100 ns Max - Measured 49.6 ns3.75 dB Max - Measured 3.17 dB65 dB Typ - Measured 64.4 dBAbsorptive18 GHz1 GHz1.0 to 18.0 GHzActive
P3T-2G4G-75-T-SFF *Buy Now100 ns Max - Measured 50 ns1.5 dB Max - Measured 1.3 dB75 dB Typ - Measured 77 dBAbsorptive4 GHz2 GHz2.0 to 4.0 GHzActive
P3T-4G8G-75-R-SFF *Buy Now100 ns max - Measured 23 ns2.0 dB typ - Measured 1.4 dB75 dB typ - Measured 88 dBReflective8 GHz4 GHz4.0 to 8.0 GHzActive
P3T-0R5G18G-55-T-SFF-PN *Buy Now100 ns Max - Measured 49.6 ns3.8 dB Max - Measured 2.17 dB55 dB Min - Measured 69.4 dBAbsorptive18 GHz0.5 GHz0.5 to 18.0 GHzActive
P3T-4G8G-75-T-SFF *Buy Now100 ns Max - Measured 55 ns2.5 dB Max - Measured 1.6 dB75 dB Typ - Measured 87 dBAbsorptive8 GHz4 GHz4.0 to 8.0 GHzActive

Single Pole - Four Throw (SP4T)

Part NumberAvailabilitySwitching SpeedInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinFrequencyStatus
SWN-1170-4DT-SPBuy NowRise/Fall Time: 15 ns max.
Delay On/Off: 100 ns max.
3.75dB typ70dB minAbsorptive18 GHz0.5 GHz0.5 to 18.0 GHzActive
P4T-8G12G-70-R-SFF *Buy Now100 ns max - Measured 34 ns2.2 dB typ - Measured 2.05 dB70 dB min - Measured 85.3 dBReflective12 GHz8 GHz8.0 to 12.0 GHzActive
P4T-4G8G-70-R-SFF *Buy Now100ns max - Measured 50.5 ns1.8 dB typ - Measured 1.79 dB70 dB min - Measured 88.1 dBReflective8 GHz4 GHz4.0 to 8.0 GHzActive
P4T-500M40G-60-R-55-292FF-SP *Buy NowRise/Fall Time: 15 ns max.
Delay On/Off: 50 ns max.
7.5 dB max. - Measured 4.7 dB55 dB min. - Measured 64.7 dBReflective40 GHz0.5 GHz0.5 to 40.0 GHzActive
P4T-12G18G-70-T-SFF *Buy Now100 ns Max - Measured 48.5 ns3.75 dB Max - Measured 3.34 dB70 dB Min - Measured 77.93 dBAbsorptive18 GHz12 GHz12.0 to 18.0 GHzActive
P4T-2G6G-70-R-SFF *Buy Now50 ns Typ - Measured 39.2 ns2.0 dB Typ - Measured 1.41 dB70 dB Min - Measured 91.11 dBReflective6 GHz2 GHz2.0 to 6.0 GHzActive
P4T-0R1G20G-80-T-SFFBuy Now300 ns Max5.0 dB Max80 dB MinAbsorptive20 GHz0.1 GHz0.1 to 20.0 GHzActive
P4T-8G12G-70-T-SFF *Buy Now100 ns max - Measured 49.6 ns2.6 dB max - Measured 2.42 dB70 dB min - Measured 75.55 dBAbsorptive12 GHz8 GHz8.0 to 12.0 GHzActive
P4T-500M40G-60-T-55-292FF-SP Rev. B *Buy NowRise: 15ns Max
Fall: 15ns Max
Delay On: 50ns Max
Delay Off: 50ns Max
8.0 dB Max - Measured 6.56 dB60 dB Min - Measured 74.66 dBAbsorptive40 GHz0.5 GHz0.5 to 40.0 GHzActive
P4T-100M50G-100-R-RDBuy Now50 ns Max5.0 dB (0.1 to 18.0 GHz) Typ, 8.0 dB (18.0 to 40.0 GHz) Typ, 14.0 dB (40.0 to 50.0 GHz) Typ70 dB (0.1 to 1.0 GHz) Typ, 100 dB (1 to 40.0 GHz) Typ, 80 dB (40.0 to 50.0 GHz) TypReflective50 GHz0.1 GHz0.1 to 50.0 GHzActive
P4T-0R5G18G-55-R-SFF-PN *Buy Now100 ns Max - Measured 69.8 ns3.2 dB Max - Measured 2.6 dB55 dB Min - Measured 67.32 dBReflective18 GHz0.5 GHz0.5 to 18.0 GHzActive
P4T-0R5G18G-55-T-SFF-PN *Buy Now100 ns Max - Measured 69.8 ns3.8 dB Max - Measured 2.85 dB55 dB Min - Measured 75.71 dBAbsorptive18 GHz0.5 GHz0.5 to 18.0 GHzActive
P4T-2G4G-75-R-SFF *Buy Now100 ns max - Measured 38 ns1.1 dB typ - Measured 1.09 dB75 dB min - Measured 91.4 dBReflective4 GHz2 GHz2.0 to 4.0 GHzActive
P4T-1G2G-60-T-SFF *Buy Now100ns max1.2dB max60dB minAbsorptive2 GHz1 GHz1.0 to 2.0 GHzActive
P4T-1G2G-60-R-SFF *Buy Now100 ns max - Measured 42.5 ns1.0 dB typ - Measured - 0.95 dB60 dB min - Measured 94.1 dBReflective2 GHz1 GHz1.0 to 2.0 GHzActive
P4T-10M1G-60-T-SFF *Buy Now200 ns max. - Measured 166 ns1.5dB max. - Measured 1.59 dB @ 0.01 to 0.2 GHz, 0.76 dB @ 0.2 to 1.0 GHz60 dB min. - Measured 86.64 dBAbsorptive1 GHz0.01 GHz0.01 to 1.0 GHzActive
P4T-6G12G-70-R-SFF *Buy Now50 ns typ - Measured 49.6 ns2.5 dB typ - Measured 1.97 dB70 dB min - Measured 74.64 dBReflective12 GHz6 GHz6.0 to 12.0 GHzActive
P4T-12G18G-60-5-5-SFFBuy Now50nsec max.3.0dB typical60dB min.Absorptive18 GHz12 GHz12.0 to 18.0 GHzActive
P4T-1G18G-70-R-SFF *Buy Now100 ns max - Measured 49.6 ns3.0 dB max - Measured 2.86 dB70 dB min - Measured 78.3 dBReflective18 GHz1 GHz1.0 to 18.0 GHzActive
P4T-1G18G-70-T-SFF *Buy Now100 ns Max - Measured 52 ns3.75 dB Max - Measured 3.46 dB70 dB Min - Measured 71 dBAbsorptive18 GHz1 GHz1.0 to 18.0 GHzActive
P4T-4G8G-70-T-SFF *Buy Now100 ns max - Measured 49.6 ns2.2 dB max - Measured 1.95 dB70 dB min - Measured 80.88 dBAbsorptive8 GHz4 GHz4.0 to 8.0 GHzActive
P4T-2G4G-75-T-SFF *Buy Now100 ns max - Measured 44 ns1.5 dB max - Measured 1.47 dB75 dB min - Measured 93.9 dBAbsorptive4 GHz2 GHz2.0 to 4.0 GHzActive
P4T-10M1G-60-R-SFF *Buy Now200 ns Max - Measured <175 ns1.2 dB Typ - Measured 1.1 dB60 dB Min - Measured 75 dBReflective1 GHz0.01 GHz0.010 to 1.0 GHzActive

Single Pole - Six Throw (SP6T)

Part NumberAvailabilitySwitching SpeedInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinFrequencyStatus
P6T-2G20G-55-T-SFFBuy NowRISE: 30 ns Max 10% to 90%
FALL: 30 ns Max 90% to 10%
4.5 dB Max55 dB MinAbsorptive20.0 GHz2.0 GHz2.0 to 20.0 GHzActive

Single Pole - Eight Throw (SP8T)

Part NumberAvailabilitySwitching SpeedInsertion LossIsolationReflective / AbsorptiveFrequency MaxFrequency MinFrequencyStatus
P8T-0R5G18G-60-R-SFF-PN*Buy Now100 nsec max. - Measured 42 ns4.0 dB tp. - Measured 3.57 dB55 dB min. - Measured 56.84 dBReflective18 GHz0.5 GHz0.5 to 18.0 GHzActive
P8T-2G18G-60-T-SFF-NSIBuy Now100 ns Max2.5 dB Max (2.0 to 6.0 GHz)
3.5 dB Max (6.0 to 12.0 GHz)
4.5 dB Max (12.0 to 18.0 GHz)
60 dB MinAbsorptive18.0 GHz2.0 GHz2.0 to 18.0 GHzActive
P8T-500M40G-50-T-55-292FF *Buy Now50 ns Typ. - Measured 25.9 ns10 dB typ. - Measured 9.0 dB45 dB Min - Measured 49.84 dBAbsorptive40 GHz0.5 GHz0.5 to 40.0 GHzActive
P8T-200M18-60-R-SFF-GRBuy Now100 ns Max0.2-6 GHz - 2.5dB Max
6-12 GHz - 3.0dB Max
12-18 GHz - 4.0dB Max
60 dB MinReflective18 GHz200 MHz200 MHz TO 18 GHzActive
P8T-200M18-60-T-SFF-NSIBuy Now100 ns Max0.2-6 GHz: 2.5 dB Max
6-12 GHz: 3.5 dB Max
12-18 GHz: 4.5 dB Max
60 dB MinAbsorptive18 GHz200 MHz200 MHz TO 18 GHzActive
P8T-500M40G-50-R-55-292FF *Buy Now50 ns Typ.10 dB Max60 dB MinReflective40 GHz0.5 GHz0.5 to 40.0 GHzActive
P8T-0R5G18G-60-T-SFF-PN *Buy Now100 ns max - Measured 42 ns4.5 dB max - Measured 4.06 dB55 dB min - Measured 56.09 dBAbsorptive18 GHz0.5 GHz0.5 to 18.0 GHzActive

Two Pole - Two Throw (XFER / DPDT)

Part NumberAvailabilitySwitching SpeedReflective / AbsorptiveIsolationInsertion LossFrequency MaxFrequency MinFrequencyStatus
PXS-4G8G-75-T-SFF *Buy Now100 ns max - Measured 49.6 nsAbsorptive75 dB min - Measured 81.42 dB1.9 dB max - Measured 1.42 dB8 GHz4 GHz4.0 to 8.0 GHzActive
PXS-12G18G-65-T-SFF *Buy Now100 ns max - Measured 60 nsAbsorptive65 dB min - Measured 77.0 dB3.0 dB max - Measured 2.65 dB18 GHz12 GHz12.0 to 18.0 GHzActive
PXS-1G2G-80-T-SFF *Buy Now100 ns max - Measured 30 nsAbsorptive80 dB min. - Measured 97.82 dB1.0 dB max - Measured 0.76 dB2 GHz1 GHz1.0 to 2.0 GHzActive
PXS-10M1G-80-T-SFF *Buy Now100 ns max. - Measured 213 nsAbsorptive80dB min1.3dB max1 GHz0.01 GHz0.01 to 1.0 GHzActive
PXS-1G18G-65-T-SFF *Buy Now100 ns max - Measured 49.6 nsAbsorptive65 dB min - Measured 70.2 dB3.1 dB max - Measured 2.72 dB18 GHz1 GHz1.0 to 18.0 GHzActive
PXS-2G4G-75-T-SFF *Buy Now100 ns max - Measured 38.8 nsAbsorptive75 dB min - Measured 98.14 dB1.2 dB max - Measured 0.98 dB4 GHz2 GHz2.0 to 4.0 GHzActive
PXS-8G12G-70-T-SFF *Buy Now100 nsec max - Measured 60 nsAbsorptive70 dB min - Measured 85.4 dB2.2 dB max - Measured 1.72 dB12 GHz8 GHz8.0 to 12.0 GHzActive

T/R Switch Modules

Part NumberAvailabilitySwitching SpeedInsertion LossIsolationControl SignalFrequency MaxFrequency MinFrequencyStatus
PSM-1G1R1G-TRSW-2500WBuy Now250 ns typ. (50% TTL to 10% & 90% RF), Measured 422 ns0.8 dB Typ, 1.0 dB Max. (J1-J2, Tx Mode), 0.8 dB Typ, 1.0 dB Max. (J1-J3, Tx Mode), Measured 0.81 dB, 0.6 dB Typ, 0.8 dB Max. (J2-J4, Rx Mode), 0.6 dB Typ, 0.8 dB Max. (J3-J5, Rx Mode), Measured 0.49 dB25 dB min. (J2-J3) - Measured 27.25 dB, 60 dB min. (J2-J4) - Measured 54.09 dB, 60 dB min. (J3-J5) - Measured 54.09 dBTTL Logic1.1 GHz1 GHz1.0 to 1.1 GHzActive

Diode Detectors

Part NumberAvailabilityFrequency FlatnessVSWR In/OutFrequency MaxFrequency MinStatus
DD-20-218-5PF-1-N-FM-OPT0518Buy Now±1.5 dB Max., ±1.0 dB Typ. - Measured ±0.895 dB3.5:1 max18 GHz0.5 GHzActive

Threshold Detectors

Part NumberAvailabilitySizeDetected Output TypeThresholdFrequency MaxFrequency MinStatus
TD-30T-SHS-218 *Buy Now0.8 x 0.62 x 0.4 InchesTTLFixed18 GHz2 GHzActive
TD-16G40G-20-292F *Buy Now1.00" x 0.62" x 0.22"TTLAdjustable40 GHz16 GHzActive
TD-30T-SHS-218-30DBAMP *Buy Now2.5 x 2.0 x 0.5 InchesTTLAdjustable18 GHz2 GHzActive

Isolators

Part NumberAvailabilityIsolationFrequency MaxFrequency MinFrequency RangeStatus
ISO-108M118M-20-NFFBuy Now20 dB min.118 MHz108 MHz108 to 118 MHzActive

Mixers

Part NumberAvailabilitySize (Excluding Connectors)ConnectorsFrequency MaxFrequency MinFrequency RangeStatus
DBMX-618RF-418LO-DC4IF-20-SFFBuy Now0.80" x 0.59" x 0.41"SMA (F)20.0 GHz6.0 GHz6.0 to 20.0 GHzActive
IRMX-8G12G-50-33-SFFBuy Now2.00" x 1.35" x 0.58"
50.80 mm x 34.29 mm x 14.78
SMA Female12 GHz8 GHz8.0 to 12.0 GHzActive

Quadrature Hybrid Couplers

Part NumberAvailabilityIsolationPhase BalanceAmplitude BalanceFrequency MaxFrequency MinStatus
QC-7G18G-SFF-30W *Buy Now18 dB min - Measured 20.14 dB<±5° - Measured ±1.72°<±0.5 dB - Measured ±0.48 dB18 GHz7 GHzActive

180 Degree, Ring-Line Hybrid Couplers

Part NumberAvailabilityInsertion LossPhase BalanceAmplitude BalanceIsolationInput PowerFrequency MaxFrequency MinStatus
PCH-180-3D13D5-SFFBuy Now0.4 dB Typ±3° Typ±0.3 dB Typ20 dB Typ50 Watts3.5 GHz3.1 GHzActive
PCH-180-5R6G5R8G-SFFIn Stock0.5 dB Max±3° Max±0.3 dB Max20 dB Min50 Watts5.8 GHz5.6 GHzActive

Directional Couplers

Part NumberAvailabilityDirectivityCouplingFrequency MaxFrequency MinStatus
PDC-800M2D5G-30C-NFF-60W *Buy Now20 dB min30<=±1.0 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-10C-NFF-60W *Buy Now20 dB min10<=±0.8 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-20C-NFF-60W *Buy Now20 dB min20<=±1.0 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-30C-SFF-50W *Buy Now20 dB Min30 < ±1.0 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-6C-SFF-50W *Buy Now20 dB min6<±1.0 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-10C-SFF-50W *Buy Now20 dB min10±1.0 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-6C-NFF-60W *Buy Now20 dB min6<=±0.5 dB2.5 GHz0.8 GHzActive
PDC-800M2D5G-20C-SFF-50W *Buy Now20 dB min20±1.0 dB2.5 GHz0.8 GHzActive

USB Style Amplifiers

Part NumberAvailabilityGain FlatnessGainFrequencyStatus
AMP-12-50M40G-USB *Buy Now±2.5 dB Typ - Measured ±0.45 dB12 dB Typ - Measured 12.53 dB Typ0.05 to 40.0 GHzActive
AMP-12-50M18G-USB *Buy Now±2.5 dB Typ - Measured ±0.41 dB12 dB Typ - Measured 13.22 dB Typ0.05 to 18.0GHzActive

USB Style Attenuators

Part NumberAvailabilityInsertion LossAttenuation RangeFrequencyStatus
ATN-30-100M40G-USB *Buy Now5 dB Typ up to 20.0 GHz - Measured <5 dB 8 dB typ. up to 40.0 GHz - Measured 6.4 dB30 dB - Measured 30 dB0.1 to 40.0 GHzActive
ATN-30-100M18G-USB *Buy Now5.0 dB Typ - Measured 4.9 dB30 dB - Measured 30 dB0.1 to 18.0 GHzActive

USB Style Switches

Part NumberAvailabilityPower & Control TypeOperating Input Power (dBm)Reflective / AbsorptiveStatus
P2T-500M18G-USB *Buy NowUSB 2.020AbsorptiveActive
P2T-500M40G-USB *Buy NowUSB 2.020AbsorptiveActive
