General Parameters: |
Status: | Active |
Center Frequency: | 17 GHz |
Insertion Loss: | 2 dB Max |
Bandwidth: | 3 GHz |
Weight: | 1 oz Typ |
Connectors: | SMA Female |
Size: | 2.05" x 0.625" x 0.40" |
Rejection from 4 to 12 GHz: | 70 dBc |
Environmental Ratings: |
Temperature: | -55 °C to 85 °C (Operating), -65 °C to 125 °C (Storage) |
Humidity: | MIL-STD-202F, Method 103B Cond. B |
Shock: | MIL-STD-202F, Method 213B Cond. B |
Vibration: | MIL-STD-202F, Method 204D Cond. B |
Altitude: | MIL-STD-202F, Method 105C Cond. B |
Temperature Cycle: | MIL-STD-202F, Method 107 |
Salt Fog: | MIL-STD-202F, Method 107D Cond. A |
Fungus: | MIL-STD-810C, Method 508.2 |
