6CL15D06G-600-CD-SFF

Model 6CL15D06G-600-CD-SFF is a a band pass filter centered at 15060MHz. The nominal bandwidth is 600MHz.

Product Specifications

General Parameters:
Status: Active
Center Frequency: 15060 MHz
Insertion Loss: 1.5 dB
Bandwidth: 600 MHz
VSWR: 1.5:1
Rejection: -70dBc @ 13.86 and 16.26GHz
Connectors In/Out: SMA (F/F)
Size: 0.805"L x 0.478"W x 0.463"H
Environmental Ratings:
Temperature: -40ºC to +85 ºC Operating, -40ºC to +100 ºC Non-Operating
Humidity: MIL-STD-202F, Method 103B Cond. B
Shock: MIL-STD-202F, Method 213B Cond. B
Vibration: MIL-STD-202F, Method 204D Cond. B
Altitude: MIL-STD-202F, Method 105C Cond. B
Temperature Cycle: MIL-STD-202F, Method 107D Cond. A
