| General Parameters: |
|---|
| Status: | Active |
|---|
| Center Frequency: | 16 GHz |
|---|
| Insertion Loss: | -4 dB Max |
|---|
| Bandwidth: | 0.3 GHz @ 3 dB |
|---|
| Weight: | 1 oz Typ |
|---|
| VSWR: | 1.5:1 Max |
|---|
| Rejection: | -40 dB |
|---|
| Connectors: | SMA Female |
|---|
| Size: | 2.25" x 0.40" x 0.50" |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -55 °C to 85 °C (Operating),
-65 °C to 125 °C (Storage) |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202F, Method 107 |
|---|
| Salt Fog: | MIL-STD-202F, Method 107D Cond. A |
|---|
| Fungus: | MIL-STD-810C, Method 508.2 |
|---|
