8CL17G5-1D47G-CD-SFF

PMI Model Number 8CL17G5-1D47G-CD-SFF is a Combline filter with SMA female connectors in and out. All filters will be machined and silver plated to provide the highest possible Q.

Product Specifications

General Parameters:
Status: Active
Center Frequency: 17500 MHz
Insertion Loss: 1.5 dB Max.
Bandwidth: 1470 MHz @ 3dB
Weight: 1 Oz. Typ
VSWR: 1.5:1 Max.
Rejection: 8 Pole Response
Connectors: SMA Female
Size: 2.20" x 0.50" x 0.50"
Environmental Ratings:
Temperature: -55°C to 85°C (Operating), -65°C to 125°C (Storage)
Humidity: MIL-STD-202F, Method 103B Cond. B
Shock: MIL-STD-202F, Method 213B Cond. B
Vibration: MIL-STD-202F, Method 204D Cond. B
Altitude: MIL-STD-202F, Method 105C Cond. B
Temperature Cycle: MIL-STD-202F, Method 107
Salt Fog: MIL-STD-202F, Method 107D Cond. A
Fungus: MIL-STD-810C, Method 508.2
