| General Parameters: |
|---|
| Status: | Active |
|---|
| Passband Frequency (GHz): | 1 to 20 |
|---|
| Cut-Off Frequency (GHz): | 1 |
|---|
| Passband Insertion Loss (dB): | 4 dB Max (@ 1 GHz)
2 dB Max (2 to 18 GHz)
3 dB Max (18 to 20 GHz) |
|---|
| Passband VSWR: | 2.0:1 Max |
|---|
| Rejection: | 60 dB Min @ 0.5 GHz |
|---|
| Operating Input Power: | 1 W CW |
|---|
| Connectors: | SMA Female/Male - removable |
|---|
| Housing: | PE2 |
|---|
| Weight: | 1 oz Typ |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature (Operating): | -55 °C to +85 °C |
|---|
| Temperature (Storage): | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
