LM-1K2G-5CW-SFF-HERM-SM

PMI Model No. LM-1K2G-5CW-SFF-HERM-SM is a 0.001 to 2.0 GHz, RF Limiter that is capable of handling 5W CW of input power and provides a maximum leakage of +20 dBm (100 mW) maximum. This model has a low insertion loss of 0.8 dB in a hermetically sealed package.

Product Specifications

General Parameters:
Status: Preliminary
Frequency: 0.001 to 2.0 GHz
Frequency Min: 0.001 GHz
Frequency Max: 2 GHz
Insertion Loss: 0.8 dB max.
Input/Output VSWR: 1.3:1 max
VSWR (Measured): 1.3:1 max @ 0 dBm Input
Input Power: 5 W CW min.
Maximum Flat Leakage: 0.001 to 1.0 GHz - 17 dBm (50 mW) max., 1.0 to 2.0 GHz - 20 dBm (100 mW) max.
Limiting Threshold: 7 dBm min, 1 dB Compression
Impedance: 50 Ohms
Size: 0.53" x 0.65" x 0.22", 13.513 mm x 16.510 mm x 5.664 mm (Excluding Connectors)
Finish: Gold Plated/ Hermetically Sealed
Internal Visual: MIL-STD-883, Method 2017
Burn In: MIL-STD-883, Method 1015, Cond. 125 ºC
Seal Fine & Gross: MIL-STD-883, Method 1014, Cond. A| & C|
Non-Destructive Bond Pull: MIL-STD-883, Method 2023
Constant Acceleration: MIL-STD-883, Method 2001, Cond. A (Y| Axis)
External Visual: MIL-STD-883, Method 2009
Environmental Ratings:
Operating Temperature: -55 ºC to +85 ºC
Non-Operating Temperature: -65 ºC to +95 ºC
Stabilization Bake: MIL-STD-883, Method 1008 Cond. B
Thermal Cycle: MIL-STD-883, Method 1010 Cond. B
