| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 2 to 18 |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 18 |
|---|
| Insertion Loss (dB): | 2 dB Max @ Pin = -10 dBm |
|---|
| Input/Output VSWR: | 2.0:1 Max |
|---|
| Peak Power: | 200 W, 1 µs with 0.1% Duty Cycle |
|---|
| Average Power: | 1 W CW |
|---|
| Input Power: | 1 W CW |
|---|
| RF Leakage (dBm): | +14 Max @ 1 W CW |
|---|
| Recovery Time: | 100 ns Max @ Pin = 27 dBm |
|---|
| Low Limiting Threshold: | +6 dBm Typ |
|---|
| P1dB Limiting Threshold (dBm): | +6 Typ |
|---|
| Connectors In/Out: | SMA (M) / SMA (F) |
|---|
| Size: | 0.75" x 1.00" x 0.30" |
|---|
| Finish: | Painted Blue |
|---|
| Weight: | 1.5 oz Typ |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55 °C to +125 °C |
|---|
| Non-Operating Temperature: | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. C |
|---|
| Shock: | MIL-STD-202F, Method 213 Cond. C |
|---|
| Thermal Shock: | MIL-STD-202F, Method 107D Cond. A |
|---|
| Fungus: | MIL-STD-202F, Method 508.5 |
|---|
| Salt Spray: | MIL-STD-202F, Method 101D+EST, Cond. B |
|---|
