| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency: | 11.0 to 14.0 GHz |
|---|
| Frequency Min: | 11 GHz |
|---|
| Frequency Max: | 14 GHz |
|---|
| Input Power: | 20 Watts (43 dBm) |
|---|
| Flat Leakage: | 7 dBm typ. |
|---|
| Pulse width: | 1 ms |
|---|
| Duty Cycle: | 0.2 |
|---|
| Connectors In/Out: | SMA (M/F) |
|---|
| Size: | 0.75 X 1.00 X 0.30 |
|---|
| Weight: | 1.5 oz. typ. |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40ºC to +85 ºC |
|---|
| Non-Operating Temperature: | -65 ºC to +125 ºC |
|---|
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
|---|
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
|---|
| Shock: | MIL-STD-202F, Method 213B Cond. C |
|---|
| Thermal Shock: | MIL-STD-202F, Method 107D Cond. A |
|---|
| Fungus: | MIL-STD-810F, Method 508.5 |
|---|
| Salt Spray: | MIL-STD-202F, Method 101D+EST Cond. B |
|---|
