LP2400-3G-SFF Active
Lowpass Filter
PMI Model LP2400-3G-SFF is a Lowpass Filter that offers extremely high Q with broadband performance and typical insertion loss of 3.5 dB. Ideal for eliminating broadband harmonics and spurs. Low Pass Filter has a cutoff frequency of 2.4 GHz and a typical return loss of 10 dB. This model has SMA female connectors and a size of 2.00" x 1.00" x 0.50".
Product Specifications
| General Parameters: | |
|---|---|
| Status: | Active |
| Passband (GHz): | DC to 2.4 |
| Cut-Off Frequency (GHz): | 2.4 |
| Passband Insertion Loss: | 3.5 dB |
| Return Loss: | 10 dB |
| Rejection: | 13 dB Typ @ 3 GHz, 51 dB Typ @ 3.5 GHz, 60 dB Typ @ 3.8 GHz, 40 dB Typ up to 18 GHz |
| Connectors In/Out: | SMA Female |
| Size: | 2.0" x 1.0" x 0.5" |
| Finish: | Gray Epoxy Polimide Coating IAW MIL-C-22750, Type I Over Epoxy Polimide Primer IAW MIL-P23377, Type I, Class 1 or 3 |
| Export Classification (ECCN): | EAR99 |
| Environmental Ratings: | |
| Temperature: | -40 °C to 70 °C |
| Non-Operating: | -40 °C to 100 °C |
