LPF100-140-NFF-50W Active
High Power Lowpass filter
Additional Documents
Quantic PMI Model LPF100-140-NFF-50W is a High Power, Lowpass filter having a cut-off frequency of 0.1 GHz with a low insertion loss of 1 dB maximum and over 80 dB of rejection at 0.14 GHz. The filter is designed for 50 ohms impedance and can handle input power levels up to 50 watts CW. Package size is 2.0" x 6.0" x 1.25" with Type N female connectors in and out.
Product Specifications
| General Parameters: | |
|---|---|
| Status: | Active |
| Passband (GHz): | DC to 0.1 |
| Cut-Off Frequency (GHz): | 0.1 |
| Passband Insertion Loss: | 1.0 dB Typ |
| Passband VSWR: | 2.0:1 Typ |
| Rejection: | -80 dB Min @ 0.14 GHz |
| Power Handling: | 50 W CW |
| Impedance: | 50 Ohm |
| Connectors In/Out: | N Type Female |
| Size: | 2.0" x 6.0" x 1.25" |
| Export Classification (ECCN): | EAR99 |
| Environmental Ratings: | |
| Temperature: | -55 °C to +85 °C |
| Non-Operating: | -65 °C to +125 °C |
| Humidity: | MIL-STD-202, Method 103B Cond. B |
| Shock: | MIL-STD-202, Method 213B Cond. B |
| Vibration: | MIL-STD-202, Method 204D Cond. B |
| Altitude: | MIL-STD-202, Method 105C Cond. B |
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
