MSDLVA-2020-70 OPTIONS 48, SE Active
SE Successive Detection Log Video Amplifier (SDLVA)
Additional Documents
Quantic PMI Model MSDLVA-2020-70 Options 48, SE Successive Detection Log Video Amplifier (SDLVA) operates over the 4 to 8 GHz range. These units are a true SDLVA and have a dynamic range of 80 dB, and TSS -70 dBm. These units are designed using innovative GaAs technology which provides stunning performance and reliability in a compact package measuring 4.60" x 0.98" x 0.24", making it an optimum solution for high-speed channelized receiver applications. These units offer a typical fast rise time of<25 ns, and a settling time of <40 ns as well as a recovery time of 150 ns.
Product Specifications
| General Parameters: | |
|---|---|
| Status: | Active |
| CW Immune (Yes/No): | No |
| Frequency Min (GHz): | 4 |
| Frequency Max (GHz): | 8 |
| TSS (dBm): | -70 Max, -73 Typ |
| Log Slope (mV/dB): | 50 |
| Log Range (dBm): | -65 to +15 |
| Log Linearity: | ±2.0 dB Max |
| Rise Time: | 25 ns |
| Recovery Time: | 150 ns |
| Settling Time: | 40 ns |
| Power Supply: | +12 VDC @ 400 mA Max -12 VDC @ 150 mA Max |
| Frequency Flatness: | ±1.0 dB Max |
| VSWR: | 2.0:1 Max, 1.6:1 Typ |
| Video Load (Ohms): | 100 |
| Pulse Range: | 50 ns to CW |
| Dynamic Range: | 80 dB |
| Log Video Output Slope: | 50 mV/dB (Not Critical) |
| Tangential Sensitivity: | -70 dBm Max, -73 dBm Typ |
| Size: | 4.60" x 0.98" x 0.24" |
| Export Classification (ECCN): | EAR99 |
| Environmental Ratings: | |
| Operating Temperature: | -54 ºC to +85 ºC Operating |
| Non-Operating Temperature: | -65 ºC to +100 ºC Non-Operating |
| Temperature Cycle: | MIL-STD-202F, Method 107D Cond. A |
| Humidity: | MIL-STD-202F, Method 103B Cond. B |
| Shock: | MIL-STD-202F, Method 213B Cond. B |
| Vibration: | MIL-STD-202F, Method 204D Cond. B |
| Altitude: | MIL-STD-202F, Method 105C Cond. B |
