| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 18 |
|---|
| Gain (dB): | 42 dB Min
56 dB Max |
|---|
| Psat: | 2 W Min @ 0 dBm Input Power |
|---|
| Input Power: | 20 dBm CW Max |
|---|
| Input VSWR: | 2.0:1 Max |
|---|
| Output VSWR: | 2.4:1 Max |
|---|
| Noise Figure: | 5 dB Max |
|---|
| Gain Flatness: | ±3.5 dB |
|---|
| Current Supply: | 800 mA Max (No RF Signal),
1.6 A Max (Psat) |
|---|
| DC Supply Voltage: | +24 VDC |
|---|
| DC Connectors: | Solder Pin |
|---|
| RF Connectors In/Out: | SMA Female |
|---|
| Size (Excluding Connectors): | 2.88" x 2.50" x 0.67" |
|---|
| Finish: | Gold Plated |
|---|
| Export Classification (ECCN): | 3A001.b.4.a |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55 °C to +85 °C |
|---|
| Non-Operating Temperature: | -65 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND. |
|---|
| Vibration: | MIL-STD-202F, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202F, METHOD 107D COND. A |
|---|
