PA-618-25G-6NF-34PS-24V-SFF Active

High Power Amplifier

PA-618-25G-6NF-34PS-24V-SFF
  • PA-618-25G-6NF-34PS-24V-SFF
  • PA-618-25G-6NF-34PS-24V-SFF
  • PA-618-25G-6NF-34PS-24V-SFF
Product Feature

Quantic PMI Model PA-618-25G-6NF-34PS-24V-SFF is a 29.5 dBm High Power Amplifier with operating frequency of 6 to 18 GHz, gain 21 dB, P1dB 30 dB Package size is 1.50" x 2.00" x 0.40" and has SMA female connectors.

Product Specifications

General Parameters:
Status: Active
Frequency Min (GHz): 6
Frequency Max (GHz): 18
Gain (dB): 21 dB
Psat: 34 dBm Typ
Input Power: 27 dBm Max
VSWR: 2.0:1 Max
Output Power at 1 dB Compression: 30 dBm Typ
Noise Figure: 5 dB Typ
8 dB Max
Current Supply: 700 mA at Psat
Supply Current Quiescent (No RF): 440 mA
DC Supply Voltage: +24 VDC
DC Connectors: SMA Female
Size (Excluding Connectors): 1.50" x 2.00" x 0.40"
Finish: Gold Plated
Export Classification (ECCN): EAR99
