| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Min (GHz): | 0.05 |
|---|
| Frequency Max (GHz): | 0.5 |
|---|
| Gain (dB): | 40 Min |
|---|
| Psat: | 34 dBm Min |
|---|
| Input Power: | 0 dBm Max |
|---|
| Input VSWR: | 1.5:1 |
|---|
| Output VSWR: | 1.5:1 |
|---|
| Noise Figure: | 4 dB |
|---|
| Current Supply: | Iq 800 mA, Ipsat 900 mA |
|---|
| Spurious: | <-60 dBc |
|---|
| Residual Phase Noise (Additive): | -125 dBc/Hz Max @ 10 Hz
-130 dBc/Hz Max @ 100 Hz
-145 dBc/Hz Max @ 1 kHz
-150 dBc/Hz Max @ 10 kHz
-160 dBc/Hz Max @ 100 kHz
-170 dBc/Hz Max @ 1 MHz
-170 dBc/Hz Max @ 10 MHz |
|---|
| DC Supply Voltage: | +15 VDC (+18 VDC Max) |
|---|
| RF Connectors In/Out: | SMA Female |
|---|
| Size (Excluding Connectors): | 3.55" x 1.89" x 0.6" |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 °C to +85 °C |
|---|
| Non-Operating Temperature: | -55 °C to +125 °C |
|---|
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
|---|
| Shock: | MIL-STD-202, METHOD 213B COND. B |
|---|
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
|---|
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
|---|
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
|---|
