PAT-3D1G3D5G-CD-SFF-NF Active
Bi-Directional Variable Attenuator
PMI Model PAT-3D1G3D5G-CD-SFF-NF is a Bi-Directional Variable Attenuator that operates between 3.1 to 3.5 GHz. At the low loss state the insertion loss is better than 1.1 dB and in the attenuation state there is 30 dB of loss. housing size is 5.87" x 2.5" x 1.4" with a MIL-C Connector - MS3124E12-10P for power/logic control, a type N connect at the RF IN and SMA female at the RF OUT connector.
Product Specifications
| General Parameters: | |
|---|---|
| Status: | Active |
| Frequency Range (GHz): | 3.1 to 3.5 |
| Frequency Min (GHz): | 3.1 |
| Frequency Max (GHz): | 3.5 |
| Attenuation Range (dB): | 30 ± 1 dB |
| Attenuation Flatness (dB): | 0.2 dB over any 10 MHz |
| Insertion Loss (dB): | 1.1 dB Max |
| Insertion Loss (Measured): | 0.8 dB |
| Minimum Attenuation Step: | 30 dB |
| VSWR: | 1.25:1 |
| Operating Input Power: | 10 dBm |
| Survival Power: | 0.5 W Peak, 256 µs PW, 0.06% DC |
| Digital Control: | 2 BIT |
| DC Connector: | MIL-C Connector - MS3124E12-10P |
| Connectors: | N-Type Male (IN) SMA Female (OUT) |
| Size: | 5.87" x 2.5" x 1.4" |
| Finish: | Blue Paint |
| Export Classification (ECCN): | EAR99 |
| Environmental Ratings: | |
| Operating Temperature: | -55 °C to +85 °C |
| Non-Operating Temperature: | -65 °C to +125 °C |
| Humidity: | MIL-STD-202, METHOD 103B COND. B |
| Shock: | MIL-STD-202, METHOD 213B COND. B |
| Vibration: | MIL-STD-202, METHOD 204D COND. B |
| Altitude: | MIL-STD-202, METHOD 105C COND. B |
| Temperature Cycle: | MIL-STD-202, METHOD 107D COND. A |
