| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 2 to 8 |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 8 |
|---|
| Gain (dB): | 13 ± 1.5 dB Max |
|---|
| Gain Flatness: | ±0.75 dB Max |
|---|
| Noise Figure (dB): | 5 dB Typ, 6 dB Max (2 to 3 GHz),
4.5 dB Typ, 5 dB Max (3 to 5 GHz),
3.5 dB Typ, 4.5 dB Max (5 to 8 GHz) |
|---|
| OP1dB (dBm): | 26 dBm Min,
27.5 dBm Typ |
|---|
| Psat (dBm): | 29 dBm Typ |
|---|
| VSWR In/Out: | 2.0:1 Max |
|---|
| DC Voltage (VDC): | +11.3 V Fixed, No Internal Voltage Regulation or Reverse Protection |
|---|
| DC Current (mA): | Iq = 360 mA Typ |
|---|
| Impedance: | 50 Ohm |
|---|
| Input Power: | 27 dBm CW Max |
|---|
| Connectors: | SMA Male (IN) Female (OUT) - removable |
|---|
| Finish: | Gold Plated |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Temperature: | -55 °C to +85 °C (Operating)
-65 °C to + 125 °C (Storage) |
|---|
| Humidity: | MIL-STD-202F, METHOD 103B COND B |
|---|
| Shock: | MIL-STD-202F, METHOD 213B COND C |
|---|
| Vibration: | MIL-STD-202F, METHOD 204D COND B |
|---|
| Altitude: | MIL-STD-202F, METHOD 105C COND B |
|---|
| Temperature Cycle: | MIL-STD-202F, METHOD 107D COND A |
|---|
