| General Parameters: |
|---|
| Status: | Active |
|---|
| Output Frequency - fo (GHz): | 6.5 |
|---|
| Frequency Stability: | Same as Reference |
|---|
| Load VSWR: | 1.5:1 Max |
|---|
| Output Power (dBm): | 13 dBm Min |
|---|
| Spurious: | -75 dBc Max |
|---|
| Phase Noise: | -116 dBc/Hz Max @ 1 kHz
-123 dBc/Hz Max @ 10 kHz
-123 dBc/Hz Max @ 100 kHz
-135 dBc/Hz Max @ 1 MHz |
|---|
| Harmonics: | -20 dBc Max |
|---|
| External Reference: | 100 MHz |
|---|
| Reference Input Power: | 0 ± 3 dBm |
|---|
| Lock Detector: | TTL High = Lock |
|---|
| DC Power: | +12 VDC @ 300 mA Max |
|---|
| Reference Phase Noise: | -130 dBc/Hz Max @ 100 Hz
-155 dBc/Hz Max @ 1 kHz
-165 dBc/Hz Max @ 10 kHz
-165 dBc/Hz Max @ 100 kHz |
|---|
| Power and Phase Lock Connector: | Solder Pins |
|---|
| Connectors: | SMA Female |
|---|
| Size: | 2.25" x 2.25" x 0.62" |
|---|
| Finish: | Nickel Plated |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -40 °C to +70 °C |
|---|
| Non-Operating Temperature: | -55 °C to +125 °C |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Humidity: | MIL-STD-202, Method 103B Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
