PTB-30-0R54-5R0-20-115VAC-SFF
Active
Portable Amplifier
Quantic PMI Model PTB-30-0R54-5R0-20-115VAC-SFF is a Portable Amplifier that operates over the 0.5 to 4 GHz, frequency range that provides 30 dB of gain typically with a minimum OP1dB of 20 dBm. Features include an on/off switch located on the front panel and operates on a 110 to 115 VAC 60 Hz voltage supply. Unit has SMA female connectors.
Product Specifications
| General Parameters: |
|---|
| Status: | Active |
|---|
| Frequency Range (GHz): | 0.5 to 4 |
|---|
| Frequency Min (GHz): | 0.5 |
|---|
| Frequency Max (GHz): | 4 |
|---|
| Gain (dB): | 30 dB |
|---|
| Gain Flatness (dB): | ±1.5 dB Max |
|---|
| Noise Figure (dB): | 5 dB Max |
|---|
| OP1dB (dBm): | 20 dBm Min |
|---|
| VSWR In/Out: | 2.0:1 |
|---|
| AC Voltage Supply: | 110 to 115 VAC 60 Hz |
|---|
| DC Voltage Supply: | N/A |
|---|
| RF Connectors (In/Out): | SMA Female |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
