| General Parameters: |
|---|
| Status: | Preliminary |
|---|
| Frequency Min (GHz): | 2 |
|---|
| Frequency Max (GHz): | 4 |
|---|
| Amplitude Balance (dB): | ±0.5 max |
|---|
| Phase Balance (°): | ±2 max |
|---|
| Insertion Loss (dB): | 0.35 dB max. |
|---|
| Isolation (dB): | 20 min |
|---|
| Power Handling: | Average: 50 W max.
Peak: 1 kW max. |
|---|
| VSWR: | 1.25:1 max. |
|---|
| Nominal Split: | 3.01 dB |
|---|
| Impedance: | 50 Ohms |
|---|
| Connectors (In/Out): | SMA (F) |
|---|
| Finish: | Painted Blue |
|---|
| Export Classification (ECCN): | EAR99 |
|---|
| Environmental Ratings: |
|---|
| Operating Temperature: | -55°C to +85°C |
|---|
| Non-Operating Temperature: | -65°C to +125°C |
|---|
| Humidity: | Up to 95%, Non-Condensing |
|---|
| Shock: | MIL-STD-202, Method 213B Cond. B |
|---|
| Vibration: | MIL-STD-202, Method 204D Cond. B |
|---|
| Altitude: | MIL-STD-202, Method 105C Cond. B |
|---|
| Temperature Cycle: | MIL-STD-202, Method 107D Cond. A |
|---|
