14SFB-30M3G-19IN2U Preliminary
14-Channel Switch Filter Bank
Quantic PMI Model 14SFB-30M3G-19IN2U is a 14-Channel Switched Filter Bank with a frequency range from 0.03 to 3 GHz and uses internal switches that are electro-mechanically controlled. Housed in a 2U, 19" x 13.7" Rack mount chassis with 9 Pin micro-D connector for power/control and SMA female connectors on the front panel.
Product Specifications
| General Parameters: | |
|---|---|
| Status: | Active |
| No of Filter Channels: | 14 |
| Operating Frequency (GHz): | 0.03 to 3 |
| Frequency Min (GHz): | 0.03 |
| Frequency Max (GHz): | 3 |
| Isolation (dB): | 60 dB Typ |
| Insertion Loss (dB): | 8 dB Typ 10 dB Max |
| Switching Speed: | 15 ms Typ, 20 ms Max |
| Control Type: | 4 Bit TTL |
| DC Voltage: | +12 V @ 1 A |
| VSWR: | 1.6:1 Typ, 1.8:1 Max |
| Impedance: | 50 Ohm |
| Input Power: | 40 dBm |
| Connectors: | RF: SMA Female DC: 9 pin Micro D |
| Size: | 19" In 2U |
| Finish: | Blue Powder Coat |
| Export Classification (ECCN): | EAR99 |
| Environmental Ratings: | |
| Operating Temperature: | -40 °C to +75 °C |
| Non-Operating Temperature: | -55 °C to +125 °C |
