Part NumberStatusFrequencyFrequency MinFrequency MaxReflective / AbsorptiveIsolationInsertion LossSwitching Speed
P3T-89-45-R-SFFActive8.0 to 9.0 GHz8.0 GHz9.0 GHzReflective45 dB Min2.5 dB Typ, 2.7 dB Max100 ns Max
P2T-500M40G-30-R-55-292FMActive0.5 to 40.0 GHz0.5 GHz40.0 GHzReflective30 dB typ.4.0 dB typ.Rise: 15 ns max.
Fall: 15 ns max.
Delay On: 50 ns max.
Delay Off: 50 ns max.
P3T-0R5G18G-55-R-SFF-PNActive0.5 to 18.0 GHz0.5 GHz18 GHzReflective55 dB min.3.2 dB typ.100 ns max.
P3T-0R5G18G-55-R-SFF-PN-HERMPreliminary0.5 to 18.0 GHz0.5 GHz18 GHzReflective55 dB min.3.2 dB typ.100 ns max.
P3T-9R5G10G-55-R-SFFActive9.5 to 10.0 GHz9.5 GHz10 GHzReflective55 dB Typ1.5 dB Max1.0 µs Max
P3T-2G8G-70-T-SFF-1Preliminary2.0 to 8.0 GHz2 GHz8 GHzAbsorptive70 dB2.1 dBRise/Fall Time: 20 ns
On/Off Time: 180 ns max.
P3T-2G8G-70-T-SFF-2Active2.0 to 8.0 GHz2 GHz8 GHzAbsorptive70 dB min.2.1 dB max.180 ns max.
P3T-0R5G4G-60-T-SFF-SPActive0.5 to 4.0 GHz0.5 GHz4 GHzAbsorptive60 dB min.2.5 dB max. (0.6 to 2.5 GHz)
3.0 dB max. (0.5 to 4.0 GHz)
On/Off - 50 ns max.
Rise/Fall - 15 ns max.
P3T-0R3G4G-60-T-SFFPreliminary0.5 to 4.0 GHz0.5 GHz4 GHzAbsorptive60dB min.2.5dB max.50nsec Typical, 100nsec Max. On / Off, 15nsec Typical. Rise / Fall
P3T-0R5G18G-60-T-SFF-50NS-JWPreliminary0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive55dB min.3.75dB max.50ns max On/Off, 15ns max Rise/Fall
P3T-0R5G4G-60-T-SFF-27DBMPreliminary0.5 to 4.0 GHz0.5 GHz4 GHzAbsorptive60 dB min2.5 dB max (0.6 - 2.5GHz), 3.0 dB max (0.5 - 4.0GHz)On/Off - 50ns maxRise/Fall - 15ns max
P3T-0R5G4G-60-T-SFF-DECPreliminary0.5 to 4.0 GHz0.5 GHz4 GHzAbsorptive60dB min2.5dB max (0.6 - 2.5GHz), 3.0dB max (0.5 - 4.0GHz)50nsec max. On/Off & 15nsec Max. Rise/Fall
P3T-10G16G-55-55-SFFPreliminary10.0 to 16.0 GHz10 GHz16 GHzReflective55 dB min.3.0 dB max.20 ns max.
P3T-12G18G-45-T-3B-GPOMMPreliminary12.0 to 18.0 GHz12 GHz18 GHzAbsorptive45dB min4.0dB max, 2.8dB typ200ns max, 75ns typ
P3T-12G18G-70-R-SFFActive12.0 to 18.0 GHz12 GHz18 GHzReflective70 dB min - Measured 77 dB2.75 dB max - Measured 2.5 dB100 ns max - Measured 28 ns
P3T-1G16G-80-T-SFF-INDPreliminary2.0 to 18.0 GHz2 GHz18 GHzAbsorptive60dB min.3.2dB max.50nsec Typical, 100nsec Max. On / Off, 10nsec Typical Rise / Fall
P3T-1G2G-60-R-SFF-OPT0R91D56Preliminary0.9 to 1.5 GHz0.9 GHz1.5 GHzReflective60 dB min1.0 dB typ100 ns max
P3T-1G2G-60-T-SFF-OPT0R9G1R5GPreliminary0.9 to 1.5 GHz0.9 GHz1.5 GHzAbsorptive60 dB min1.25 dB max100 ns max
P3T-2G18G-60-T-SFF-INDPreliminary2.0 to 18.0GHz2 GHz18 GHzAbsorptive60dB min.3.2dB max.50nsec Typical, 100nsec Max.
P3T-2G18G-70-T-GPO-5VPreliminary2.0 to 18.0 GHz2 GHz18 GHzAbsorptive70 dB min.3.0 dB max.150 ns
P3T-2R9G3R4G-45-R-SFFPreliminary2.9 to 3.4 GHz2.9 GHz3.4 GHzReflective45 dB min.2.0 dB typ., 2.2dB max.100 ns max.
P3T-500M26R5G-30-R-55-292FFPreliminary0.5 to 26.5 GHz0.5 GHz26.5 GHzReflective30 dB min.1.25 dB max.100 ns max
P3T-500M26R5G-30-R-55-292FFOPTION618Active6.0 to 18.0 GHz6 GHz18 GHzReflective30 dB min.2.0 dB max. - Measured 1.95 dB100 ns max - Measured 30 ns
P3T-500M26R5G-30-R-55-SFF-1W-OPT618Preliminary6.0 to 18.0 GHz6 GHz18 GHzReflective30 dB min.1.75 dB max.100 ns max
P3T-500M40G-60-T-55-292FF-OPT1840Preliminary18.0 to 40.0 GHz18 GHz40 GHzAbsorptive60dB min.6.0dB typ.Rise: 15ns typ, Fall: 15ns typ, Delay On: 50ns typ, Delay Off: 50ns typ
P3T-7G18G-50-R-SFFPreliminary7.0 to 18.0 GHz7 GHz18 GHzReflective60 dB min (7.0 to 8.0 GHz), 50 dB min (12.4 to 18.0 GHz)2.2 dB max (7.0 to 8.0 GHz), 3.1 dB max. (12.4 to 18.0 GHz)35 ns max. (50% TTL to 90% RF), 10 ns max. (10% RF to 90% RF)
PMSN-3DT-05-DEC-MP-OPT600M6GActive0.6 to 6.0 GHz0.6 GHz6 GHzAbsorptive60 dB Min - Measured 85 dB2.5 dB Typ, 2.75 dB Max - Measured 2.4 dBRise: 10 ns Typ, 15 ns Max - Measured 5 ns, Fall: 10 ns Typ, 15 ns Max - Measured 8 ns, Delay On: 75 ns Typ, 100 ns Max - Measured 42 ns, Delay Off: 75 ns Typ, 100 ns Max - Measured 32 ns
P3T-8G12G-60-5/5-SFFActive8.0 to 12.0 GHz8 GHz12 GHzReflective60dB min.2.0dB max.50nsec max.
P3T-12G18G-70-T-SFF *Active12.0 to 18.0 GHz12 GHz18 GHzAbsorptive70 dB Min - Measured 73.22 dB3.75 dB Max - Measured 3.0 dB100 ns Max - Measured 49.6 ns
P3T-2G4G-75-T-SFF *Active2.0 to 4.0 GHz2 GHz4 GHzAbsorptive75 dB Typ - Measured 77 dB1.5 dB Max - Measured 1.3 dB100 ns Max - Measured 50 ns
P3T-500M40G-60-R-55-292FF *Active0.5 to 40.0 GHz0.5 GHz40 GHzAbsorptive55 dB min - Measured 57.3 dB5.5 dB typ - Measured 3.64 dBRise: 15 ns typ, Fall: 15 ns typ, Delay On: 50 ns typ - Measured 43 ns, Delay Off: 50 ns typ
P3T-9G10G-45-R-SFFActive9.0 to 10.0 GHz9 GHz10 GHzReflective45 dB Min - Measured 51.07 dB2.5 dB Typ, 2.7 dB Max - Measured 2.56 dB100 ns Max - Measured 98 ns
PMSN-3DR-05-StandardActive1.0 to 18.0 GHz1 GHz18 GHzReflective60 dB @ 1.0-12.4 GHz Min - Measured 84 dB @ 1.0-12.4 GHz, 50 dB @ 12.4-18.0 GHz Min - Measured 72 dB @ 12.4-18.0 GHz1.2 dB @ 1.0-4.0 GHz Max - Measured 1.08 dB @ 1.0-4.0 GHz, 1.5 dB @ 4.0-8.0 GHz Max - Measured 1.47 dB @ 4.0-8.0 GHz, 2.0 dB @ 8.0-12.4 GHz Max - Measured 1.64 dB @ 8.0-12.4 GHz, 2.6 dBRise Time: 10 ns Max - Measured <10 ns, Fall Time:25 ns Max - Measured <25 ns, Off Time: 20 ns Max - Measured <20 ns
P3T-10M1G-60-R-SFF *Active0.010 to 1.0 GHz0.01 GHz1 GHzReflective60 dB min - Measured 80.0 dB1.0 dB typ - Measured 0.49 dB200 ns max - Measured 49.6 ns
P3T-10M1G-60-T-SFF *Active0.010 to 1.0 GHz0.01 GHz1 GHzAbsorptive60 dB min - Measured 62.92 dB1.4 dB max - Measured 1.34 dB200 ns max - Measured 60 ns
P3T-1G2G-60-R-SFF *Active1.0 to 2.0 GHz1 GHz2 GHzReflective60 dB min - Measured 80 dB1.0 dB typ - Measured 0.49 dB100 ns max - Measured 49.6 ns
P3T-1G2G-60-T-SFF *Active1.0 to 2.0 GHz1 GHz2 GHzAbsorptive60 dB min - measured 87 dB1.25 dB max - measured 0.76 dB100 ns max - measured 21 ns
P3T-2G4G-75-R-SFF *Active2.0 to 4.0 GHz2 GHz4 GHzReflective75 dB typ - Measured 89.4 dB1.2 dB typ - Measured 1.19 dB100 ns max - Measured 49.6 ns
P3T-4G8G-75-R-SFF *Active4.0 to 8.0 GHz4 GHz8 GHzReflective75 dB typ - Measured 88 dB2.0 dB typ - Measured 1.4 dB100 ns max - Measured 23 ns
P3T-500M18G-60-T-SFF-LVActive0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive60 dB min – Measured 77.63 dB4.4 dB max - Measured 4.29 dB50 ns max.
P3T-0R5G18G-55-T-SFF-PN-OPT-12Preliminary0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive55 dB Min3.8 dB Max100 ns Max
P3T-1G18G-65-R-SFF *Active1.0 to 18.0 GHz1 GHz18 GHzReflective65 dB typ - Measured 73.66 dB2.75 dB typ - Measured 2.39 dB100 ns max - Measured 27.5 ns
P3T-2G18G-70-T-SFFActive2.0 to 18.0 GHz2 GHz18 GHzAbsorptive70 dB Min3 dB Max150 ns
P3T-0R5G18G-55-T-SFF-PN *Active0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive55 dB Min - Measured 69.4 dB3.8 dB Max - Measured 2.17 dB100 ns Max - Measured 49.6 ns
P3T-2G18G-60-T-SFFActive2.0 to 18.0 GHz2 GHz18 GHzAbsorptive55dB min.3.2dB max.50nsec max. On/Off & 15nsec Max. Rise/Fall
P3T-4G8G-75-T-SFF *Active4.0 to 8.0 GHz4 GHz8 GHzAbsorptive75 dB Typ - Measured 87 dB2.5 dB Max - Measured 1.6 dB100 ns Max - Measured 55 ns
P3T-8G12G-70-R-SFF *Active8.0 to 12.0 GHz8 GHz12 GHzReflective70 dB min - Measured 76.83 dB2.4 dB typ - Measured 1.63 dB100 ns max - Measured 29.4 ns
PEC-20M3G-3T-SFF-LVActive0.02 to 3.0 GHz0.02 GHz3 GHzAbsorptive70 dB min (0.02 to 1.0 GHz), 60 dB min (1.0 to 2.0 GHz), 50 dB min (2.0 to 3.0 GHz)2.0 dB (0.02 to 1.0 GHz), 2.5 dB (1.0 to 2.0 GHz), 4.0 dB (2.0 to 3.0 GHz)
-
P3T-0R5G18G-55-T-SFF-PN-OPT218Active2.0 to 18.0 GHz2 GHz18 GHzAbsorptive55 dB Min3.8 dB Max100 ns Max
P3T-0R5G4G-60-T-SFFActive0.5 to 4.0 GHz0.5 GHz4 GHzAbsorptive60 dB min. - Measured 68.5 dB2.5 dB max. (0.6 - 2.5GHz) - Measured 2.46 dB 3.0 dB max. (0.5 - 4.0GHz) - Measured 2.88 dBOn/Off - 50ns max, Rise/Fall - 15ns max
P3T-0R5G18G-60-R-SFFActive0.5 to 18.0 GHz0.5 GHz18 GHzReflective60 dB min.2.75 dB max.100 nsec max.
P3T-100M18G-80-T-515-SFF-4W-INDActive0.1 to 18.0 GHz0.1 GHz18 GHzAbsorptive80 dB Min4.5 dB Max80 ns Max
P3T-1G18G-65-T-SFF *Active1.0 to 18.0 GHz1 GHz18 GHzAbsorptive65 dB Typ - Measured 64.4 dB3.75 dB Max - Measured 3.17 dB100 ns Max - Measured 49.6 ns
P3T-500M18G-60-T-SFF-LV-SPActive0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive60 dB Min4.4 dB Max50 ms Max
PMSN-3DR-05-STANDARD-OPT26-LVTTL-OPT28Active2.0 to 8.0 GHz2.0 GHz8.0 GHzReflective60 dB min.1.2 dB @ 2.0 to 4.0 GHz max., 1.5 dB @ 4.0 to 8.0 GHz max.Rise/Fall Time: 10 ns max.
On/Off Time: 20 ns max.
PMSN-3DR-05-STANDARD-OPT2G6G-LVTTLActive2.0 to 6.0 GHz2 GHz6 GHzReflective60 dB Min1.2 dB @ 2.0-4.0 GHz Max, 1.5 dB @ 4.0-6.0 GHz Max20 nsec
P3T-2G18G-60-T-SFF-REVB-SPActive2.0 to 18.0 GHz2 GHz18 GHzAbsorptive60 dB Min3.2 dB Max - Measured 3.07 dB50 ns Max On/Off - Measured 48.5 ns 15 ns Max Rise/Fall
P3T-8G12G-70-T-SFF *Active8.0 to 12.0 GHz8 GHz12 GHzAbsorptive70 dB Min - Measured 90 dB2.8 dB Max - Measured 1.9 dB100 ns Max - Measured 23 ns
P3T-500M40G-60-T-55-292FF *Active0.5 to 40.0 GHz0.5 GHz40 GHzAbsorptive60 dB Min - Measured 71.53 dB6.0 dB Typ - Measured 6.83 dBRise: 15 ns Typ
Fall: 15 ns Typ
Delay On: 50 ns Typ
Delay Off: 50 ns Typ
P3T-2G18G-60-T-SFF Rev.BActive2.0 to 18.0 GHz2 GHz18 GHzAbsorptive60 dB min. - Measured 77.39 dB3.2 dB max. - Measured 3.04 dB50 ns max. On/Off & 15 ns max. Rise/Fall - Measured 40 ns
P3T-12G18G-70-T-SFFPreliminary12.0 to 18.0 GHz12 GHz18 GHzAbsorptive80 dB Min3.75 dB Max100 ns Max
P3T-0R5G18G-60-T-SFFPreliminary0.5 to 18.0 GHz0.5 GHz18 GHzAbsorptive60dB min.3.75dB max.100 nsec max.
